SECTION 501-18: Convertible Top
DIAGNOSIS AND TESTING
Convertible Top
Refer to Wiring Diagrams Cell 102, Convertible Top for schematic and connector information.
Special Tool(s)
73 III Automotive Meter
105-R0057 or equivalent
Principles of Operation
The convertible top will only operate with the parking brake engaged and the ignition switch in the RUN position. When the parking brake is engaged, the raise and
lower relay coils are grounded through the parking brake switch. The convertible top switch supplies power to the raise or lower relay coil when raise or lower is
selected. This power energizes the coil causing the relay contacts to close which supplies battery power to the convertible top motor/pump assembly. The normal state
of the relay is connected to ground. When the raise or lower relay is operating, the other relay remains in its normal state supplying the motor/pump ground.
Convertible Top Adjustment
The convertible top adjustments must be made by a qualified technician.
Inspection and Verification
1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical or electrical damage.
Visual Inspection Chart
Mechanical
Convertible top brackets and frame
Hydraulic motor and pump
Hydraulic lift cylinders
Door and quarter window glass adjustment
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom and refer to the Symptom Chart.
Symptom Chart
SYMPTOM CHART
Condition
The convertible top does not raise/lower
The convertible top hesitates/comes up uneven
The convertible top does not raise or does not go up all the
way
The convertible top hydraulic system
PINPOINT TEST A: THE CONVERTIBLE TOP DOES NOT RAISE/LOWER
CONDITIONS
http://www.fordtechservice.dealerconnection.com/pubs/content/~WS1B/~MUS~LEN/19/S...
Electrical
Central junction box (CJB) Fuse 20 (15A)
Battery junction box (BJB) circuit breaker CONV TOP (30A)
Wiring harness
Loose or corroded connections
Raise or lower relays
Parking brake switch
Convertible top switch
Possible Sources
Convertible top switch.
Central junction box (CJB) Fuse 20
(15A).
Parking brake switch.
Lower relay.
Raise relay.
Circuitry.
Convertible top adjustment.
Hydraulic lift cylinders.
Hydraulic system.
Convertible top adjustment.
Hydraulic lift cylinders.
Hydraulic system.
Convertible top adjustment.
Hydraulic lift cylinders.
Hydraulic motor/pump assembly.
Hydraulic system.
DETAILS/RESULTS/ACTIONS
Page 1 of 10
2001 Mustang Workshop Manual
Procedure revision date: 03/01/2002
Action
GO to
Pinpoint Test
A.
GO to
Pinpoint Test
B.
GO to
Pinpoint Test
C.
GO to
Pinpoint Test
D.
