Getting Started with the
NI 17xx Smart Camera
The National Instruments 17xx Smart Camera combines an image
sensor and a high-performance processor to return either
inspection results or images. While a typical industrial camera
acquires and transmits images through a standard camera bus for
processing on another device, the smart camera performs both
acquisition and processing operations directly on the smart camera.
This document describes how to set up and configure the smart
camera hardware, configure the IP address, install software, and
acquire an initial image.
Refer to the NI 17xx Smart Camera User Manual for information
about specific features and specifications of the smart camera.
Select Start»All Programs»National Instruments»Vision»
Documentation»NI-IMAQ to access the NI 17xx Smart Camera
User Manual after configuring the smart camera using the
procedures described in this document.
Unpack and Verify Components
Remove the NI Smart Camera from the package and inspect the
device for any sign of damage. Notify National Instruments if the
device appears damaged in any way. Do not use a damaged device.
For safety and compliance information, refer to the specifications
in the NI 17xx Smart Camera User Manual.
Required Components
This section describes the hardware and software components
necessary to set up and use the NI Smart Camera.
Hardware
The following hardware components are included in the NI Smart
Camera kit:
❑
NI 17xx Smart Camera
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for National Instruments NI 17xx Smart
Summary of Contents for National Instruments NI 17xx Smart
-
Page 1: Unpack And Verify Components
This document describes how to set up and configure the smart camera hardware, configure the IP address, install software, and acquire an initial image. Refer to the NI 17xx Smart Camera User Manual for information about specific features and specifications of the smart camera. Select Start»All Programs»National Instruments»Vision»... - Page 2 ❑ 5-position lighting connector (additional/replacement plugs for use with the lighting connector are available from NI, part number 780260-01) In addition to the items included in the smart camera kit, the following components are necessary to set up and configure the smart camera: ❑...
-
Page 3: Optional Components
NI 1762 NI 1764 Optional Components National Instruments offers a variety of accessories for use with the NI Smart Camera, including the following items: • Lenses – 8 mm (part number 780024-01) –... -
Page 4: Connect The Lens And Lighting
Direct Drive internal lighting controller, or 5 V TTL or 24 V external strobe generation for use with a third-party lighting controller. Refer to the NI 17xx Smart Camera User Manual for information about using the smart camera with a light. -
Page 5: Connect The Power Supply And I/O
When power is first applied to the smart camera, the POWER LED flashes red for one second while internal systems power up. The POWER LED then lights green when power is correctly wired to the smart camera. © National Instruments Corp. Getting Started with the NI 17xx... -
Page 6: Power With Additional I/O
Power with Additional I/O National Instruments provides the following two cable options for connecting a third-party power supply and I/O to the NI Smart Camera. • Terminal block with a 15-pin D-SUB connector, such as the NI Smart Camera I/O Accessory, and a 15-pin D-SUB to 15-pin D-SUB cable •... - Page 7 When power is first applied to the smart camera, the POWER LED flashes red for one second while internal systems power up. The POWER LED then lights green when power is correctly wired to the smart camera. © National Instruments Corp. Getting Started with the NI 17xx...
-
Page 8: Connect To The Development Computer
Firewall Configuration If your firewall is controlled remotely or you are unsure about configuring the firewall, contact your network administrator. Refer to Appendix B, Troubleshooting, of the NI 17xx Smart Camera User Manual to troubleshoot network configuration issues. Direct Connection To connect the NI Smart Camera directly to the development computer, refer to Figure 3 and complete the following steps. -
Page 9: Network Connection
The smart camera is now connected directly to the development computer. Network Connection To connect the NI Smart Camera to the development computer through a network, refer to Figure 4 and complete the following steps. © National Instruments Corp. Getting Started with the NI 17xx... -
Page 10: Subnet Considerations
1 Connecting an Ethernet Cable to Port 1 on the NI Smart Camera 2 Ethernet Hub or Other Network Port 3 Connecting an Ethernet Cable to an Ethernet Port on the Development Computer Figure 4. Connecting the NI Smart Camera to the Development Computer Through a Network 1. -
Page 11: Software Options
Software Options National Instruments provides two options for developing applications for the NI Smart Camera. LabVIEW Vision Builder LabVIEW Real-Time Module NI Vision Development Module Automated Inspection NI Vision Acquisition Software • NI Vision Builder for Automated Inspection (Vision Builder AI)—Interactive, menu-driven configuration software for developing, benchmarking, and deploying machine vision applications. -
Page 12: Configuring The Ni Smart Camera With Vision Builder Ai
If the NI Smart Camera does not appear in the list of targets, refer to the Subnet Considerations section of this document and Appendix B, Troubleshooting, of the NI 17xx Smart Camera User Manual for information about subnets and troubleshooting smart camera configuration issues. 4. Click Install Software. The Remote Target Configuration Wizard launches in a new window. -
Page 13: Install Software On The Ni Smart Camera
Refer to the Where to Go from Here section for a list of documentation and other resources to help you set up and use the smart camera in an application. © National Instruments Corp. Getting Started with the NI 17xx... -
Page 14: Configuring The Ni Smart Camera With Labview
NI-IMAQ driver. Documentation for the NI-IMAQ driver software is available by selecting Start»All Programs»National Instruments» Vision»Documentation»NI-IMAQ. 4. NI Vision Development Module—Refer to the NI Vision Development Module Readme on the NI Vision Development Module installation media for system requirements and installation instructions. - Page 15 Refer to the Subnet Considerations section of this document and Appendix B, Troubleshooting, of the NI 17xx Smart Camera User Manual for information about subnets and troubleshooting smart camera configuration issues. 3. In the Name field, enter a name for the device. Use the Comment field to enter any additional information or a brief description of the device.
- Page 16 6. If you want to prevent other users from resetting the smart camera, click the Lock button on the MAX toolbar to set up password protection for the smart camera. To require users to enter the password before restarting the smart camera, enable the Password-protect Resets checkbox.
-
Page 17: Where To Go From Here
The following documents and resources contain information you may find helpful as you set up and use the NI Smart Camera in an application. Refer to the NI 17xx Smart Camera User Manual for detailed information about: • Power and I/O requirements •... -
Page 18: Additional Resources For Vision Builder For Automated Inspection Users
Vision Builder AI. You can access the NI Vision Builder for Automated Inspection Tutorial and other documentation by selecting Start»All Programs»National Instruments»Vision Builder AI»Documentation. You can also access context help within Vision Builder AI by clicking the Show Context Help button on the Vision Builder AI toolbar. -
Page 19: Safety Information
If necessary, return the device to National Instruments for repair. Keep away from live circuits. Do not remove equipment covers or shields unless you are trained to do so. If signal wires are connected to the device, hazardous voltages can exist even when the equipment is turned off. - Page 20 Do not exceed the maximum ratings for the device. Remove power from signal lines before connection to or disconnection from the device. National Instruments measurement products Caution may be classified as either Measurement Category I or II.
-
Page 21: Where To Go For Support
Examples include electricity meters and measurements on primary overcurrent protection devices and on ripple control units. Where to Go for Support The National Instruments Web site is your complete resource for technical support. At you have access to ni.com/support everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. - Page 22 Netherlands 31 (0) 348 433 466, New Zealand 0800 553 322, Norway 47 (0) 66 90 76 60, Poland 48 22 328 90 10, Portugal 351 210 311 210, Russia 7 495 783 6851, Singapore 1800 226 5886, Slovenia 386 3 425 42 00, South Africa 27 0 11 805 8197, Spain 34 91 640 0085, Sweden 46 (0) 8 587 895 00, Switzerland 41 56 2005151, Taiwan 886 02 2377 2222, Thailand 662 278 6777,...
- Page 23 LabVIEW, National Instruments, NI, ni.com, the National Instruments corporate logo, and the Eagle logo are trademarks of National Instruments Corporation. Refer to the Trademark Information at ni.com/trademarks for other National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies.
