Getting Started with the NI 17xx Smart Camera
The NI 17xx smart camera combines an image sensor and a high-performance processor to return
inspection results instead of images. While a typical industrial camera acquires and transmits images
through a standard camera bus for processing on another device, the NI 17xx performs both acquisition
and processing operations directly on the smart camera.
This document describes how to set up and configure the NI 17xx smart camera hardware, configure the
IP address, install software, and acquire an initial image.
Refer to the NI 17xx Smart Camera User Manual for additional information about specific features
of the smart camera. Select Start»All Programs»National Instruments»Vision»Documentation»
NI-IMAQ to access the NI 17xx Smart Camera User Manual after configuring the NI 17xx using the
procedures described in this document.
Contents
Safety Information ............................................................................................................................... 1
Unpack and Verify Components.......................................................................................................... 3
Connect the Lens and Lighting............................................................................................................ 4
Connect the Power Supply and I/O...................................................................................................... 5
Connect to the Development Computer............................................................................................... 7
Software Options ................................................................................................................................. 10
Configuring the NI 17xx with Vision Builder AI ................................................................................ 11
Configuring the NI 17xx with LabVIEW ............................................................................................ 13
Specifications....................................................................................................................................... 15
Where to Go for Support ..................................................................................................................... 20

Safety Information

Caution
The following paragraphs contain important safety information you must follow when
installing and operating the NI 17xx.
Do not operate the device in a manner not specified in the documentation. Misuse of the device may
result in a hazard and may compromise the safety protection built into the device. If the device is
damaged, turn it off and do not use it until service-trained personnel can check its safety. If necessary,
return the device to National Instruments for repair.
Keep away from live circuits. Do not remove equipment covers or shields unless you are trained to do
so. If signal wires are connected to the device, hazardous voltages can exist even when the equipment is
turned off. To avoid a shock hazard, do not perform procedures involving cover or shield removal unless
you are qualified to do so. Disconnect all field power prior to removing covers or shields.
If the device is rated for use with hazardous voltages (>30 V
safety earth-ground connection wire. Refer to the device specifications for maximum voltage ratings.
Because of the danger of introducing additional hazards, do not install unauthorized parts or modify
the device. Use the device only with the chassis, modules, accessories, and cables specified in the
installation instructions. All covers and filler panels must be installed while operating the device.
, 42.4 V
, or 60 V
), it may require a
rms
pk
dc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NI 17 xx and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for National Instruments NI 17 xx

  • Page 1: Table Of Contents

    Refer to the NI 17xx Smart Camera User Manual for additional information about specific features of the smart camera. Select Start»All Programs»National Instruments»Vision»Documentation» NI-IMAQ to access the NI 17xx Smart Camera User Manual after configuring the NI 17xx using the procedures described in this document.
  • Page 2 Remove power from signal lines before connection to or disconnection from the device. Caution National Instruments measurement products may be classified as either Measurement Category I or II. Operate products at or below the Measurement Category level specified in the hardware specifications.
  • Page 3: Unpack And Verify Components

    15-pin D-SUB to 15-pin D-SUB cable, 2 m (part number 197817-02) or 5 m (part number 197817-05), and a 15-pin D-SUB terminal block ❑ Standard C-mount lens ❑ Development computer running Windows Vista/XP/2000 © National Instruments Corporation Getting Started with the NI 17xx Smart Camera...
  • Page 4: Connect The Lens And Lighting

    – NI Vision Development Module 8.5 or later – NI Vision Acquisition Software 8.5.1 or later (included) Optional Components National Instruments offers a variety of accessories for use with the NI 17xx, including the following items: • Lenses – 8 mm (part number 780024-01) –...
  • Page 5: Connect The Power Supply And I/O

    The POWER LED then lights green when power is correctly wired to the NI 17xx. Third-Party Power Supply and I/O National Instruments provides the following two cable options for connecting a third-party power supply and I/O to the NI 17xx.
  • Page 6 NI 17xx Smart Camera Optional Terminal Block 15-Pin D-SUB to 15-Pin D-SUB Cable Power Supply Figure 2. Connecting the NI 17xx to a Third-Party Power Supply Connect and secure the 15-pin D-SUB connector on your cable to the POWER-I/O connector on the NI 17xx.
  • Page 7: Connect To The Development Computer

    Caution To prevent data loss and to maintain the integrity of your Ethernet installation, do not use a cable longer than 100 m. National Instruments recommends using a shielded twisted pair Ethernet cable for maximum signal integrity. © National Instruments Corporation...
  • Page 8: Direct Connection

    Direct Connection To connect the NI 17xx directly to the development computer, refer to Figure 4 and complete the following steps. Connecting an Ethernet Cable to Port 1 on the NI 17xx Connecting an Ethernet Cable to an Ethernet Port on the Development Computer Figure 4.
  • Page 9: Network Connection

    NI 17xx on the same subnet as the development computer. Next, physically move the NI 17xx to the other subnet. Contact your network administrator for assistance in setting up the development computer and NI 17xx on the same subnet. © National Instruments Corporation Getting Started with the NI 17xx Smart Camera...
  • Page 10: Software Options

    Software Options National Instruments provides two options for developing applications for the NI 17xx. LabVIEW Vision Builder LabVIEW Real-Time Module NI Vision Development Module Automated Inspection NI Vision Acquisition Software • NI Vision Builder for Automated Inspection (Vision Builder AI)—Interactive, menu-driven configuration software for developing, benchmarking and deploying machine vision applications.
  • Page 11: Configuring The Ni 17Xx With Vision Builder Ai

    Device names are limited to 15 characters with no spaces or special characters, except hyphens. The first and last characters must be alphanumeric. © National Instruments Corporation Getting Started with the NI 17xx Smart Camera...
  • Page 12 Click the Browse button next to the Software Image to Install on the Target control. Navigate to the Vision Builder AI software image you want to use, and click OK. Software images provided by National Instruments are installed to the <Vision Builder AI>\RT Images directory, where is the location where Vision Builder AI is installed.
  • Page 13: Configuring The Ni 17Xx With Labview

    Configure the IP Address Complete the following steps to configure an IP address for the NI 17xx. Launch Measurement & Automation Explorer (MAX), the National Instruments configuration utility, by double-clicking the Measurement & Automation icon on the desktop, or selecting Start»All Programs»National Instruments»Measurement &...
  • Page 14 Documentation for LabVIEW and the LabVIEW Real-Time Module is available from the Help menu on the LabVIEW toolbar. You can access documentation for the NI Vision Development Module by selecting Start»All Programs»National Instruments»Vision»Documentation»NI Vision. Examples of image acquisitions and common machine vision inspections are installed to the directories, where <LabVIEW>\Examples\IMAQ...
  • Page 15: Specifications

    Minimum exposure time ........36.28 µs Exposure time increment ........31.2 µs Refer to the NI 17xx Smart Camera User Manual for more information about calculating the maximum frame rate for your application. © National Instruments Corporation Getting Started with the NI 17xx Smart Camera...
  • Page 16 Spectral Characteristics..........Refer to Figure 8 1000 Wavelength (nm) Figure 8. NI 1722 and NI 1742 Spectral Response Curve Gamma..............1.0 fixed Lighting Direct Drive lighting controller Maximum current ..........500 mA continuous; 1 A strobed Minimum current ...........50 mA Default turn-on time........156 µs Light requirements Maximum voltage drop across LED+/LED–...
  • Page 17 Input current...........0 mA to 0.1 mA Input voltage ..........0 V to 1 V ON state Input current...........3 mA to 5.4 mA Input voltage ..........20 V to 30 V Minimum pulse width..........1 ms © National Instruments Corporation Getting Started with the NI 17xx Smart Camera...
  • Page 18 Isolated Outputs Channels..............2 Output type ............Sinking/sourcing, independently configurable External load power supply range......19 V to 30 V Output current ............100 mA, maximum per channel Quadrature Encoder Encoder type ............Differential, RS-422; phase A/phase B, no index Physical Characteristics Lens mount ............C-mount Camera housing .............Painted die-cast aluminium Dimensions ............11.77 cm ×...
  • Page 19 Certification column. Environmental Management National Instruments is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial not only to the environment but also to NI customers.
  • Page 20: Where To Go For Support

    National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United States, create your service request at ni.com/...
