- Page 1 H3C S9500E Series Routing Switches IRF Command Reference Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Software version: S9500E-CMW520-R1725 Document version: 6W170-20111118...
- Page 2 SecPro, SecPoint, SecEngine, SecPath, Comware, Secware, Storware, NQA, VVG, V G, V G, PSPT, XGbus, N-Bus, TiGem, InnoVision and HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd. All other trademarks that may be mentioned in this manual are the property of their respective owners Notice The information in this document is subject to change without notice.
- Page 3 Preface The H3C S9500E documentation set includes 14 command references, which describe the commands and command syntax options available for the H3C S9500E Series Routing Switches. The IRF Command Reference describes Intelligent Resilient Framework (IRF) configuration commands. This preface includes: •...
- Page 4 Provides a complete guide to hardware installation Installation guide and hardware specifications. H3C N68 Cabinet Guides you through installing and remodeling H3C Installation and Remodel N68 cabinets. Hardware specifications Introduction and installation...
-
Page 5: Obtaining Documentation
Obtaining documentation You can access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the links on the top navigation bar to obtain different categories of product documentation: [Technical Support & Documents > Technical Documents] –... -
Page 6: Table Of Contents
Contents IRF configuration commands ······································································································································· 1 chassis convert mode irf ·········································································································································· 1 display irf ·································································································································································· 2 display irf configuration ··········································································································································· 4 display irf topology ·················································································································································· 5 display mad ······························································································································································ 6 display restricted port ·············································································································································· 8 ... -
Page 7: Irf Configuration Commands
IRF fabric also needs to be managed and maintained, and thus consumes system resources. Therefore, if a switch does not need to form an IRF fabric with other devices, H3C recommends that you configure its operating mode as standalone mode. -
Page 8: Display Irf
Examples # Switch the operating mode of the switch from standalone to IRF mode. <Sysname> system-view [Sysname] chassis convert mode irf The device will switch to IRF mode and reboot. You are recommended to save the current running configuration and specify the configuration file for the next startup. Continue? [Y/N]:y Do you want to convert the content of the next startup configuration file flash:/startup.cfg to make it available in IRF mode? [Y/N]:y... - Page 9 Description Use the display irf command to display information about the IRF fabric. Examples # Display information about the IRF fabric. <Sysname> display irf Switch Slot Role Priority CPU-Mac Description Master 1 00e0-fc0a-15e0 F1Num001 Slave 00e0-fc0f-8c02 F1Num002 ------------------------------------------------------ * indicates the device is the master. + indicates the device through which the user logs in.
-
Page 10: Display Irf Configuration
Field Description Preservation information about the bridge MAC address of the IRF fabri • 6 min—When the master leaves, the bridge MAC address does not change for six minutes. MAC persiste • always—The br idge MAC address remains unchanged even if the master leaves th e IRF fabric. -
Page 11: Display Irf Topology
Ten-GigabitEthernet1/8/0/1 disable Ten-GigabitEthernet1/8/0/2 disable Ten-GigabitEthernet2/12/0/1 Ten-Gigabi tEthernet2/12/0/2 able 2 Outp ut description Field Description Current mMember ID of the switch MemberID If this field is displayed as --, it indicates that the membe r ID of this switch is not set. -
Page 12: Display Mad
------------------------------------------------------------------------- IRF-Port1 IRF-Port2 Switch Link neighbor Link neighbor Belong To 00e0-fc0f-8c0f DOWN 00e0-fc0f-8c0f he abo ve information show s that IRF-po rt 2 of member switch 1 connects with IRF-port 1 of member witch 1. able 3 Ou tput description Field Description Switch... - Page 13 Descripti Use the display mad c ommand to display information about the MAD detection. Examples # Display the enable status of MAD detection. <Sysname> display mad MAD LACP enabled. MAD BFD enabled. # Display the detailed information about the M AD detection.
-
Page 14: Display Restricted Port
Field Description Excluded ports (can not be Ports set by default not to shut down when the IRF fabric transitions to configured) recovery state. MAD enabled aggregation port The aggregate interface where LACP MAD is enabled. MAD BFD enabled interface The aggregate interface where BFD MAD is enabled. -
Page 15: Irf Auto-Merge Enable
Examples # Display the restricted port s on the card in slot 4 of the member switch 1. [Sysname]display restricted port chassis 1 slot 4 Chassis: 1 lot: 4 estricted port: GigabitEthernet1/4/0/1 G igabitEthernet1/4/0/2e Table 5 Output description Field Descri ption Chassis Member ID of the switch... -
Page 16: Irf Auto-Update Enable
irf auto-update enable Syntax irf auto-update enabl o irf auto-update enable View Syst em view Default level 3: Manage level Paramete None Descripti Use the irf auto-update enable command to automatically synchronize the boot file of the master switch to the switch you are adding to the IRF fabric. Use the undo irf auto-update enable command to disable this function. -
Page 17: Irf Link-Delay
undo irf domain View Syst em view Default le 3: Manage level Paramete domain-id: Specifies the domain ID assigned to an IRF fabric, ranging from 0 to 4294967295. Descripti Use the irf domain command to assign a domain ID for an IRF fabric. Use the irf domain comma nd to restore the default. -
Page 18: Irf Link-Status Detect Enable
Use the undo irf link-delay command to restore the default. By default, the delay time for the link layer to report a link-down event of an IRF fabric is 0 milliseconds. This command is available only when the switch is operating in IRF mode. The configuration of this command will be lost when you c hange to the standalone mode, even if you have saved the configuration. -
Page 19: Irf Mac-Address Persistent
View System view Default level 3: Manage level Paramete None Descripti Use the irf link-status auto-recovery en able command to enable IRF link auto-recovery. Use the undo irf link-status auto-recovery enable command to disable IRF link auto-recovery. By default, IRF link auto-recovery is enabled. IRF link auto-recovery enables the switch to automatically recover a failed link that has bee n detected by the I... -
Page 20: Irf Member
By default, the bridge MAC address of the IRF fabric remains unchanged, even if the master leaves the IRF fabric. Preserve for six minutes: When the master leaves, the bridge MAC address does not change • within six minutes. If the master does not come back when the preservation time expires, the IRF fabric uses the bridge MAC address of the newly elected master as its bridge MAC addre •... -
Page 21: Irf Member Description
When the operating mode of the switch changes from standalone to IRF, the member ID of the • switch is needed for the auto-conversion of the configuration file. If the switch has no member ID configured, use the irf member command to set a member ID for it. An IRF fabric uses member IDs to uniqu ely identify and manage members. -
Page 22: Irf Member Priority
irf member priority Syntax irf member memb er-id priority priority o irf member member-id priority View System view Default le 3: M anage level Paramete member-id: Specifies the ID of an IRF member switch, which is in th e range of 1 to 4. priority: Specifies the priority value, which is in the range of 1 to 32. - Page 23 Paramete member-id: Specifies the ID of an IRF member switch, which is in the range of 1 to 4. new-member-id: Specifies the new ID of the member of the IRF fabric, which is in t he range of 1 to 4. Descripti Use the irf member renumber command to set a member ID for a member of an IRF fabric.
-
Page 24: Irf Mode Enhanced
irf mode enhanced Syntax irf mode enhanced undo irf mode enhanced View ystem view Para ete None Descri ption Use the irf mode enhanced command to enable enhanced IRF mode. Use the undo irf mode enhanced command to disable enhanced IRF mode. The enhanced IRF mode enables up to four switches to form an IRF fabric. -
Page 25: Irf Priority
# Enable enhanced IRF mode on a switch in IRF mode where both Layer-3 Ethernet ports and VPLS instances exist. <Sysname> system-view [Sysname] irf mode enhanced Mode switch failed because the enhanced IRF mode does not support the L ayer 3 E thernet interface. -
Page 26: Irf Switch-To
Use the undo irf priority command to restore the default. By default, the priority of a member switch is 1. Member priority is used for role election . The greater the priority value, the higher the priority. A ember with a higher priority is more likely to be a master. To specify a priority for the switch: Use the irf priority command w hen the switch operates in standalone mode. -
Page 27: Irf-Port Member-Id/Port-Number
debugging • terminal debugging • • terminal logging terminal monitor • terminal trapping • To return to the console of the active MPU of the IRF fabric, execute the quit command. The active MPU of the IRF fabric is reactivated and ready for outputting information. However, you cannot redirect to the active MPU of the IRF fabric with the irf switch-to command. -
Page 28: Irf-Port Port-Number
[Sysname] irf-port 2/2 [Sysname-irf -port 2/2] quit irf-port p ort-number Syntax irf-port port-number o irf-port port-number View System view Default le 3: Manage level Paramete rt-number: Specifies the IRF port number. The value can be either 1 or 2. Descripti Use the irf-port port-numbe r command to create an IRF port and enter IRF port view when the switch operates in standalone m... -
Page 29: Mad Bfd Enable
By default, ARP MAD is disabled. When executing the mad arp enable command, you are required to input the IRF domain ID to avoid the situation that the MAD detection p ackets of this IRF fabric are sent to a neighbor IRF fabric. Examples # Enable ARP MAD on VLAN-interface 3. -
Page 30: Mad Enable
mad enable Syntax mad enabl o mad enable View Aggregate interface view Default level 3: Manage level Paramete None Descripti se the mad enable command to enable LACP MAD to detect the IRF fabric for multi-active collisions. Use the undo mad enable command to disable LACP MAD. By default, LACP MAD is d isabled. -
Page 31: Mad Ip Address
If a port must be kept in up state for special purposes such as a telnet connection, you can exclude it from the shut down action. To avoid problems, H3C recommends that you keep all ports down but the one used for telnet for the management purpose. The ports shut do wn come up when the member switches reboot to join the recovered IRF fabric. -
Page 32: Mad Restore
member member-id: Specifies the ID of an IRF member switch, which is in the range of 1 to 4. Descripti Use the mad ip address command to configure the MAD IP address for the specified member switch. Use the undo mad ip address command to delete the configured MAD IP address. By default, no MAD IP address is configured for any interface. -
Page 33: Port Group Interface
<Sysname> system-view [Sysname] mad restore This command will restore the device from multi-active conflict state. Continue? [Y/N]:Y Restoring from multi-active conflict state, p lease wait... port g roup interface Syntax port group interface interface-type interface-number undo port group inter face interface-name View IRF port view Default level... -
Page 34: Set Irf Slot Member-Id
Examples # Bind physical IRF port T en-GigabitEthernet 2/0/1 on the switch operating in standalone mode to IRF port 1. <Sysname> system-view [Sysname] irf-port 1 [Sysname-irf-port 1] port group interface t en-gigabitethernet 2/0/1 # When the switch operates in IRF mode, bind physical IRF port Ten-GigabitEthern et 2/2/0/1 on member 2 to IRF port 1. - Page 35 # Set the me mber ID of the MPU in slot 1 of switch 2 to 1 when the switch operates in IRF mode. <Sysname> set irf chassis 2 slot 1 member-id 1 CAUTION: IRF Conf iguration Guide For more information about this function, see •...
-
Page 36: Index
Index C D I M P S irf member priority,16 irf member renumber,16 chassis convert mode irf,1 irf mode enhanced,18 priority,19 switch-to,20 display irf,2 irf-port member-id/port-number,21 display irf configuration,4 irf-port port-number,22 display irf topology,5 display mad,6 display restricted port,8 mad arp enable,22 mad bfd enable,23...
