Parts Catalog
Issued: Apr 9, 2007
Lynx L-3 & Lynx L-4
Yes, you can.© ™

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lynx L-4 and is the answer not in the manual?

Questions and answers

Bonnie Greer
May 20, 2025

I am looking for a lynx l-4 battery charger.

0
1 comments:
Mr. Anderson
May 24, 2025

You can find an Invacare Lynx L-4 battery charger at SpinLife for $125.00.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Invacare Lynx L-4

Summary of Contents for Invacare Lynx L-4

  • Page 1 Parts Catalog Issued: Apr 9, 2007 Lynx L-3 & Lynx L-4 Yes, you can.© ™...
  • Page 2 For your convenience, we have supplied an area for you to list your Invacare Representatives. Name Phone Numbers ©2007 Invacare Corporation. Elyria, Ohio. Invacare, the Medallion Design and Yes, you can. are registered trademarks and Lynx is a trademark of Invacare Corporation. Form No. 06-109...
  • Page 3 Lower Tiller Assembly ......................Motor & Transaxle ........................Packaging & Touch-Up Paint ....................Rear Wheels & Anti-Tips ......................Seat & Arms ..........................Shrouds, Main & Rear ......................Tiller Maintenance ........................Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 4 Part Number Kit Contains: (I ea.) Carton, (1 ea.) Insert, 1148170 (1 ea.) Foam Pad, and (2 ea.) Foam Block. 1149226 Touch-Up Paint - Blue 1149227 Touch-Up Paint - Red Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...

  • Page 5: Tiller Maintenance

    Tiller Maintenance Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 6 1144792 Pkg, Speed Control Knobs (Pkg of 10) 1144793 Ignition Switch w/Key 1144794 Pkg, Ignition Keys (Pkg of 10) 1144795 Throttle Pot & Lever Assembly 1144796 Throttle Lever w/Hardware Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...

  • Page 7: Lower Tiller Assembly

    Lower Tiller Assembly Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 8 (2) ea. Spacer, (1) ea. Bolt, and (1) ea. Front Wheel 1144832 Kit, Front Wheel (L-4) Includes: (1) ea. Bolt, (1) ea. Plain Washer, and (1) ea. Front Wheel Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 9 (6) ea. Push Rivets 1144816 Pkg, Push Rivets (Pkg of 25) 1144838 Basket (Lynx L3 & L4) 1143205 Owner's Manual (Lynx L-3 & L-4) NOTE: A - Not Shown Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 10 Main & Rear Shrouds Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 11 Shroud, Rear w/ Hardware & Decals - Blue (L-4) 1144820 Shroud, Rear w/ Hardware & Decals - Red (L-3) 1144821 Shroud, Rear w/ Hardware & Decals - Blue (L-3) 1144817 Handle, Rear w/ Hardware Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...

  • Page 12: Footplate And Battery Box Door

    Footplate and Battery Box Door Quantity Per Item Number Note Description Package Assembly Part Number 1146449 Door, Battery Box 1146447 Pad, Foot - Black Plastic (Right) 1146448 Pad, Foot - Black Plastic (Left) Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 13 Seat & Arms Quantity Per Item Number Note Description Package Assembly Part Number 1146610 Seat and Arm Assembly (Lynx L-3 & L-4) Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 14 (2) ea. Bolts, (2) ea. Nuts, and Decals, Warnings, & Logos 1144812 Spring, Seat Lever 1144811 Kit, Seat Guide Bracket Includes: (1) ea. Seat Guide Bracket, and (2) ea. Bolts Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 15 Rear Wheel Assembly (L-4) - Single Wheel 1144823 Rear Wheel Assembly (L-3) - Wheel Pair 1144824 Kit, Anti-Tip Wheels Includes: (2) ea. Nylon Nut, (4) ea. Bearings, (2) ea. Bolts, and (2) ea. Anti-Tip Wheels Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 16 Battery Box, Charger, Controller & Harnesses Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 17 (1) ea. Battery Wire, and (1) ea. Rear Wiring Group 1144836 Fuse, 5 AMP 1144790 Controller, Rhino 70 AMP 1144837 Batteries, 12 Volt (A2SH) - pair NOTE: A - Not Shown Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 18 1144787 Kit, Transaxle Includes: (1) ea. Differential, 2 ea. Keys, 2 ea. E Rings, 2 ea. Plain Washers, 2 ea. Bolts (M8 x 20L), & 2 ea. Flat Washer Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...

  • Page 19: Bracket, Accessory

    Bracket, Accessory Quantity Per Item Number Note Description Package Assembly Part Number 1148158 Bracket, Accessory (Lynx L-3 & Lynx L-4) Form No. 06-109 To order call toll free 1-800-333-6900, or www.invacare.com...
  • Page 20 Invacare Corporation www.invacare.com ©2007 Invacare Corporation. Elyria, Ohio. All rights reserved. Trademarks are One Invacare Way Technical Support Customer Service identified by the symbols ™ and ®. All trademarks are owned by or licensed to Elyria, Oh USA 800-832-4707 800-333-6900...

This manual is also suitable for:

Lynx l-3
