Specification

Main unit Specification
Max. cutting area
Acceptable sheet size
Cutting speed
Acceptable material
Control keys
LED
Interface
Power consumption
Acoustic noise level
External dimensions
Weight (unit only)
Operation temperature
Operation humidity
Accessories
Interface Specification
[ Parallel ]
Standard
Input signal
Output signal
I/O signal level
Transmission method

Option Lists

T y p e
Cemented Carbide Blades
Adjustable Depth Blade Holder
Pressurized Oil Based
Ball-point Pen
Thick Water-based
Fiber Tipped Pens
(Line Thickness : 2.0 mm)
34
STX-8
250 mm (X) x 1000 mm (Y)
(9-13/16" (X) x 39-5/16" (Y) )
Width: 280—305 mm (11"—12")
Length: 1100 mm (43-1/4") or less
12—40 mm/sec. (7/16"/sec.—1-9/16"/sec.)
PVC sheet (0.1 mm (0.00394") or less in thickness, 0.3 mm (0.0118") or less in thickness
including the backing board).
STANDBY key
STANDBY LED
Parallel (in compliance with the specification of Centronics)
Exclusive AC adapter (DC+12V 1.5 A)
Cutting mode: 50 dB (A) or less
419 mm (W) x 147 mm (D) x 95.5 mm (H)
(16-1/2" (W) x 5-13/16" (D)) x 3-13/16" (H))
2 kg (4.4 lb.)
5—40°C (41—104°F)
35—80 % (no condensation)
Roland Software Package, Blade holder, Blade, AC adapter, Material for test cuts,
Applicationtape for test cuts, * Sheet setup guide, * Water based fiber tipped pen, * Paper,
STX-8/7 User's Manual
* Included only with the STX-8.
In compliance with the specification of Centronics
STROBE (1BIT), DATA (8BIT)
BUSY (1BIT), ACK (1BIT)
TTL level
Asynchronous
Model Nbr.
ZEC-U1002
XD-CH3
XD-BPHG
XD-3M-BLK
XD-3M-RED
XD-3M-BLU
XD-3M-GRN
XD-4SPA-WBG
XD-4SPB-WBG
XD-4SPC-WBG
XD-4SPD-WBG
XD-4SPE-WBG
XD-4SPF-WBG
XD-4SPG-WBG
XD-4SPH-WBG
XD-4SPI-WBG
XD-4SPJ-WBG
160 mm (X) x 1000 mm (Y)
(6-1/4" (X) x 39-5/16" (Y) )
Width: 200—215 mm (7-13/16"—8-7/16")
Length: 1100 mm (43-1/4") or less
Cutting mode: 47 dB (A) or less
(According to ISO 7779)
317 mm (W) x 147 mm (D) x 95.5 mm (H)
(12-1/2" (W) x 5-13/16" (D)) x 3-13/16" (H))
1.6 kg (3.5 lb.)
Contents
2 pcs./pkg
1 pcs./pkg
Holder (with one black refill for test)
Replaceable Refill 3 pcs./pkg, All Black
Replaceable Refill
3 pcs./pkg, All Red
Replaceable Refill
3 pcs./pkg, All Blue
Replaceable Refill
3 pcs./pkg, All Green
4 pcs./pkg, All Black
4 pcs./pkg, 1 Each Black, Red, Blue, Green
4 pcs./pkg, 1 Each Brown, Purple, Pink, Orange
4 pcs./pkg, All Red
4 pcs./pkg, All Blue
4 pcs./pkg, All Green
4 pcs./pkg, All Orange
4 pcs./pkg, All Pink
4 pcs./pkg, All Brown
4 pcs./pkg, All Purple
STX-7
