When cutting has ended, use a commercially available
5
retractable-blade knife or the like to cut off the piece of
material, taking care not to cut the portion of the backing
paper shown by "-----" in the figure at right. Then peel off
the sheet. Use the commercially available knife to trim
away the peeled backing paper.
Peel off excess portions of the sheet.
6
Flip over the material so the two pieces are face down.
7
Carefully line up the edges of the two pages so that the two
sections match, then use commercially available tape to
tape them together.
Flip the material back so that it is face up, and make sure
8
the edges where the two sections meet are aligned correctly.
Use the same steps described in "12 Applying the Cut
Material" to transfer the sheet to the desired object.
17

Care and cleaning

Cleaning the Blade Tip
Remove any sheet scraps adhering to the blade tip.
Cleaning the Blade Holder
Take off the tip of the blade holder and remove any pieces of
material inside.
Cleaning the Machine
If the machine becomes soiled, wipe it clean with a dry cloth.
Slight scratching of the blade protector poses no problem for operation. However, the blade protector should be replaced if it
becomes so severely damaged that cutting is adversely affected. Consult your vendor or your nearest Roland DG Corp. sales office
for replacement of the blade protector. (Replacement of the blade protector is a charged procedure.)
32
Rotate the tip of the blade holder in the direc-
tion shown in the figure to remove it.
