Roland Stika Plus STX-8 User Manual page 28

Using symbols
Dr. STIKA PLUS is provided with a set of symbols. These symbols can be added to any file being edited with Dr. STIKA PLUS.
Frequently used objects in Dr. STIKA PLUS can also be registered and added to the set of symbols.
Importing a symbol
From the [Object] menu, click [Symbol].
1
The [Symbol] dialog box appears.
Select the symbol to be used, and click [Insert].
2
The imported symbol appears. You can adjust its size and
3
position.
Registering a symbol
Select the object to be registered as a symbol.
1
From the [Object] menu, click [Add Symbol].
2
The [Add Symbol] dialog box appears.
Symbols being registered can be grouped according to use
3
or shape. To create a new group, click [New Group] and
enter a name for the group. To add the object to an existing
group, select the group name with [Group Name].
26
