4
Click . This encloses the "SALE"
text in a rectangle so that only the area
of the sheet around what is cut is peeled
off.
5
Click and save the data you've
made to a file.
11

Perform cutting

Before performing cutting, make sure the STX-8/7 has been prepared as described in the sections "3 Adjusting the Amount of
Blade Extension" to "6 Perform Test Cutting."
1
Click , then click [OK] in the
dialog box that appears.
If you wish to make the settings for the
cutting conditions again, please refer to
"10 Creating Data with Dr. STIKA
PLUS" - "Setting the cutting range" -
"Setting the tool conditions."
18
Drag
1. Click
2. Select where the
file is to be saved.
3. Type in the file name. Files
created with Dr.STIKA PLUS
have ".stx" as the extension.
4. Click
1. Click
2. Click
