Roland Stika Plus STX-8 User Manual page 18

Set the cutting range. When using the
3
included sheet material, make sure the
screen at right has the values shown.
Click [Tools].
For information about the STX-8/7's
cutting range, see "3 Loading Material"
- "The cutting range" or the help screens
for the driver.
Setting the tool conditions
When using the included blade, there is no need to change the tool conditions. At this time, simply check the settings to make sure they're
appropriate.
Make sure [Machine Settings] is
1
displayed and click [OK].
When using sheet material other than
the included material and making
changes in the tool conditions, refer to
the help for the driver.
For pen plotting, refer to "14 Draft
Plotting."
Click [OK].
2
16
* Width is a fixed value.
STX-8: 250 mm (9.84")
STX-7: 160 mm (6.29")
390 mm (15.35")
270 mm (10.63")
