WARNINGS
If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or
loss of life.
–
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
–
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
This appliance may be installed in an
a f t e r m a r k e t , p e r m a n e n t l y l o c a t e d ,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
Unvented Gas Log Heater
or
Vented Decorative Appliance
Installation Instructions
Model: NBST27
This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is
installed. Provisions for adequate combustion
and ventilation air must be provided.
Refer to Page 6.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NBST27
cover
81D3032 8/10 Rev. 3
Advertisement
Table of Contents
Related Manuals for MHSC NBST27
Summary of Contents for MHSC NBST27
-
Page 1: Installation Instructions
Unvented Gas Log Heater Vented Decorative Appliance Installation Instructions Model: NBST27 WARNINGS If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 2: Table Of Contents
NBST27 Unvented Gas Log Set CONTENTS Important Safety Information ......3 Electrical Wiring (Millivolt) ........14 Codes .............4 Optional Wall Switch or Thermostat .....14 Remote Receiver ..........15 Getting Started .............5 Checking System Operation ......15 Product Features and Specifications ....5 Log Placement ...........16 Gas Pressures ..........5... -
Page 3: Important Safety Information
NBST27 Unvented Gas Log Set IMPORTANT SAFETY INFORMATION OWNER INSTALLER Please retain these instructions for future reference. Please leave these instructions with the appliance. IMPORTANT Read these instructions carefully before installing or trying to operate this vent-free gas heater. •... -
Page 4: Codes
NBST27 Unvented Gas Log Set IMPORTANT SAFETY INFORMATION 19. During manufacturing, fabricating and shipping, various components of this appliance are treated with certain Never connect unit to private (non-utility) oils, films or bonding agents. These chemicals are not gas wells. This gas is commonly known harmful but may produce annoying smoke and smells as wellhead gas. -
Page 5: Getting Started
NBST27 Unvented Gas Log Set GETTING STARTED - FEATURES and SPECIFICATIONS GAS PRESSURES Gloves are recommended when handling ceramic fiber logs to prevent skin irritation Natural *Propane (LP) from loose fibers. Inlet Minimum 5.0” w.c. 11.0” w.c. Logs are fragile - handle with care. -
Page 6: General Installation Information
NBST27 Unvented Gas Log Set GENERAL INSTALLATION INFORMATION ADEQUATE COMBUSTION AND VENTILATION AIR This heater shall not be installed in a confined space or unusually tight construction unless provi- sions are provided for adequate combustion and ventilation air. The National Fuel Gas Code, (ANSI Z223.1/NFPA 54), defines a confined space as a space whose volume is less than 50 cubic feet per 1,000 BTU per hour (4.8 m... -
Page 7: Fireplace And Hearth Dimensions
INSTALLATION OF THIS GAS LOG SET ance requirements as defined in their manual. PLACEMENT IN A FIREPLACE WITH A The NBST27 unvented room heater is approved for instal- RESTRICTIVE BARRIER lation into the following unvented fireplaces: The following are guidelines for placing a gas log set in... -
Page 8: Clearances And Height Requirements
NBST27 Unvented Gas Log Set CLEARANCE and HEIGHT REQUIREMENTS The dimensions shown in Figures 4 through 10 and defined in the fireplace manufacturer's instructions are minimum clearances to maintain when installing this heater. Left and right clearances are determined when facing the front of the heater. - Page 9 NBST27 Unvented Gas Log Set CLEARANCE and HEIGHT REQUIREMENTS Heat resistant material (minimum requirements) with Figure 7 - 10” or Less Minimum Mantel Clearance wooden mantel or other combustible projection: with No Hood To install the heater with a wooden mantel, shelf or other combustible projection above, first measure the heat resis- 28”...
-
Page 10: Floor Clearance
NBST27 Unvented Gas Log Set FLOOR CLEARANCES The gas log heater must be installed at least 3/4" above any combustible flooring material, such as carpeting or tile, which is closer than 14" to the base of the fireplace. The minimum distance must be maintained from the top surface of carpeting, tile, etc. -
Page 11: Fireplace Preparation
NBST27 Unvented Gas Log Set FIREPLACE PREPARATION Before installing in a solid fuel burning fireplace, The chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. This appliance is for installation only in a solid fuel burning fireplace (masonry fireplace or manufactured fireplace) with a working flue and constructed of noncombustible material. - Page 12 NBST27 Unvented Gas Log Set VENTED APPLICATION INSTALLATION / SECURE APPLIANCE The fireplace and gas logs function as a system. If the fireplace is spilling into the room (check with a match or a smoke stick), reposi- tion the damper clamp until a positive draft is obtained by opening the damper.
-
Page 13: Gas Line Connection
NBST27 Unvented Gas Log Set GAS LINE CONNECTION Use new black iron or steel pipe. Internally tinned copper or copper tubing can be used per National Fuel Code, section 2.6.3, providing gas meets hydrogen sulfide limits, and where permitted by local codes. Gas piping system must be sized to provide minimum inlet pressure (Listed on Data Plate) at the maximum flow rate (BTU/hr). -
Page 14: Electrical Wiring (Millivolt)
NBST27 Unvented Gas Log Set ELECTRICAL WIRING - MILLIVOLT Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. The Millivolt valve is a self-powered combination gas con- trol THAT DOES NOT REQUIRE 110VAC TO OPERATE. -
Page 15: Remote Receiver
ELECTRICAL WIRING - MILLIVOLT NBST27 Unvented Gas Log Set A. Complete Millivolt System Check CONNECT REMOTE RECEIVER (“A” Reading - Thermostat contacts CLOSED - Control 1. Set remote receiver. Refer to instructions included in knob “ON” - Main burner should turn ON) the receiver kit. -
Page 16: Log Placement
NBST27 Unvented Gas Log Set LOG PLACEMENT The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance. Never add additional logs or embellishments such as pine cones, vermiculite or rock wool to the heater. -
Page 17: Log Placement
LOG PLACEMENT NBST27 Unvented Gas Log Set Log 1 LOG PLACEMENT Figure 19 - Begin on Side A, valve on left as Place Log #1 you face the fireplace. 1. Place log #1 on burner by aligning two (2) holes on bot-... - Page 18 NBST27 Unvented Gas Log Set LOG PLACEMENT Log #5 5. Place log #5 by placing rectangular notch on bottom of log onto matching rectangu- lar protrusion on log #2. Make sure ember or ‘burnt’ portion of log is facing center of burner.
- Page 19 NBST27 Unvented Gas Log Set LOG PLACEMENT 8. Place log #8 by aligning ‘V’ notch in bottom of log with the horizontal grate bar between tines as shown in Figure 17. Place the rect- angular notch on bottom of log onto rectangular protrusion on middle of log #1.
-
Page 20: Flame Appearance
NBST27 Unvented Gas Log Set FLAME APPEARANCE Flames from the pilot, front and rear burner should be visually checked as soon as the heater is installed. In addition, periodically check the flames visually during operation. CHECk THE PILOT FLAME The pilot flame must always be present when the heater is in operation. It should just touch the top of the thermocouple tip for natural. -
Page 21: Operating Instructions
NBST27 Unvented Gas Log Set OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Avoid any drafts that alter burner flame patterns. Do not allow fans to blow directly into the fireplace. Do not place a blower inside the burn area of the firebox. Ceiling fans may create drafts that alter flame patterns. -
Page 22: Millivolt Control Lighting Instructions
NBST27 Unvented Gas Log Set OPERATING INSTRUCTIONS MILLIVOLT CONTROL LIGHTING INSTRUCTIONS 1. STOP! Read the safety information label. 2. Make sure the manual shutoff valve is fully open. 3. This gas log set is equipped with an ignition device (piezo) which automatically lights the pilot. If piezo ignitor does not light the pilot, refer to instructions for Match lighting instructions, Page 23. -
Page 23: Match Lighting Instructions
NBST27 Unvented Gas Log Set OPERATING INSTRUCTIONS and MAINTENANCE MATCH LIGHTING INSTRUCTIONS 1. Remove any items necessary for easy access to the pilot (for example: logs, screens, etc.). 2. Follow appropriate lighting instructions found previously. Instead of pushing and releasing the piezo button, light a match and hold the flame to the end of the pilot and ignite the pilot. -
Page 24: Troubleshooting
NBST27 Unvented Gas Log Set TROUBLESHOOTING NOTE: All troubleshooting items are listed in order of Turn off heater and allow to cool before operation. cleaning. Disconnect electrical power before cleaning or servicing. Problem Possible Cause Solution When ignitor button is 1. - Page 25 NBST27 Unvented Gas Log Set TROUBLESHOOTING Problem Solution Possible Cause ODS/pilot lights, but flame 1. Press in control knob fully. 1. Control knob not fully pressed in. goes out when control 2. After ODS/pilot lights, keep control 2. Control knob not pressed in long knob is released.
-
Page 26: Replacement Parts
NBST27 Unvented Gas Log Set REPLACEMENT PARTS Ref. Description Qty. NBST27NV NBST27PV Complete Log Set 81D3033 81D3033 Log #1 81D3034 81D3034 Log #2 81D3035 81D3035 Log #3 81D3036 81D3036 Log #4 81D3037 81D3037 Log #5 81D3038 81D3038 Log #6 81D3039... -
Page 27: Accessories
NBST27 Unvented Gas Log Set ACCESSORIES Description Part Number Flex Connector Flexcon 30 Wall Switch and Wire MVWS Wall Thermostat Kit On/Off Remote RCB, RCMT, TLM, WMTD Thermostat Remote RCST, RCT, TLT, WWTD Remote Receiver Cover Ember RRCE Remote Receiver Cover Metal... - Page 28 NBST27 Unvented Gas Log Set 81D3032...
- Page 29 NBST27 Unvented Gas Log Set 81D3032...
-
Page 30: Requirements In Massachusetts
Massachusetts Residents Only — Please read and follow these special requirements 2. Approved Carbon Monoxide Detectors. Each carbon NOTE REGARDING VENTED PRODUCTS monoxide detector as required in accordance with the above This product must be installed by a licensed plumber or gas fitter provisions shall comply with NFPA 720 and be ANSI/UL 2034 when installed within the Commonwealth of Massachusetts. -
Page 31: Warranty
After installation, if any of the components manufactured by MHSC in the appliance are found to be defective in materials or workmanship, MHSC will, at its option, replace or repair the defective components at no charge to the original owner. - Page 32 MHSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
