InfoPrint Solutions Company Asia Pacific Hardware Announcement
InfoPrint 4247 Model Z03 printer features increased durability
and faster print speed for demanding applications
Table of contents
2
2
2
8
8
9
At a glance
The new InfoPrint® 4247 Model Z03 printer is built on the strengths of previous models of the
InfoPrint 4247 family.
• Print speed of up to 1100 characters per second (cps) in Fast Draft mode
• Rugged design with metal covers for demanding transaction applications
• Remote printer management capabilities when LAN attached
• Parallel, Ethernet, Serial, and USB 2.0 optional integrated attachments
• Auto forms loading, auto thickness adjustment, and auto eject to enhance operator
productivity
• Workload capacity of up to 64,000 pages per month
• Multiple data stream emulations to provide easy replacement of older printers
• Forms width from 3 to 17 in (76 to 432 mm)
• Maximum print width of 13.6 in (348 mm)
• One or two continuous forms front tractors for maximum forms-feeding reliability
• Easy-to-use operator panel
• Fast Draft, DP, DP Text, NLQ Gothic, NLQ Courier, OCR-A, and OCR-B resident fonts
Overview
A fast and reliable printer for harsh conditions
The InfoPrint 4247 Model Z03 is a professional industrial impact matrix printer capable of printing
at speeds of up to 1100 cps in Fast Draft mode.
InfoPrint Solutions Company Asia Pacific
Hardware Announcement AG08-0532
AG08-0532, dated July 22, 2008
9
11
16
17
17
InfoPrint is a registered trademark of Ricoh Co., Ltd.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for InfoPrint 4247
Summary of Contents for InfoPrint 4247
-
Page 1: Table Of Contents
Technical description At a glance The new InfoPrint® 4247 Model Z03 printer is built on the strengths of previous models of the InfoPrint 4247 family. • Print speed of up to 1100 characters per second (cps) in Fast Draft mode •... -
Page 2: Key Prerequisites
• Thailand Description Print speed Print speeds in characters per second (cps) of the 4247-Z03 at 10 cpi are up to: • 1100 cps in Fast Draft mode • 800 cps in DP mode • 480 cps in DP Text •... - Page 3 Print modes include Fast Draft, Data Processing (DP), Data Processing Text (DP Text), Near Letter Quality (NLQ), OCR-A, and OCR-B. Print qualities on the 4247-Z03 are equivalent in character size, shape, and resolution to the print qualities available on the previous 4247 printers.
- Page 4 Model Z03. Submit RPQ requests if an RPQ is needed. Bulk order for optional features Since the 4247-Z03 features are all customer installable, in some cases it is desirable to bulk order certain features so that machines can be easily reconfigured by Business Partners and end users.
- Page 5 • Limitations: Not with any other controller card feature; each printer can have only one of the following (feature number 5350, 5351, 5352, 5353, 5356, 5357, or 9300) on an initial order • Field installation: Yes; feature number 5353 InfoPrint Solutions Company Asia Pacific InfoPrint is a registered trademark of Ricoh Co., Ltd. Hardware Announcement AG08-0532...
- Page 6 • Maximum order quantity: One • Corequisites: None • Prerequisites: 4247-Z03 • Limitations: Either feature number 5250 or 5251 must be ordered with each 4247-Z03 printer; refer to ordering quantity limitation above • Field installation: No, this feature is only applicable to initial orders •...
- Page 7 Air freight shipping - Initial (#5251) This feature specifies that the 4247-Z03 printer being ordered is to be shipped by air freight. This is a chargeable feature. • Maximum per 4247-Z03 printer: One • Minimum per 4247-Z03 printer: Zero • Maximum order quantity: One •...
-
Page 8: Product Positioning
• Footprint with output tray attached: 726 mm (W) x 792 mm (D) or 28.6 in wide x 31.2 in deep Product positioning The InfoPrint 4247-Z03 is a professional industrial printer for the most demanding printing applications, including high-level print quality and graphic capabilities. -
Page 9: Technical Description
– RS-232 9-pin Serial – USB 2.0 port – Centronics-compatible 36-pin PC Parallel Port • 4247 native and IBM 4202 Proprinter III XL, IBM Personal Printer 2381, and Epson FX series emulation modes for all attachments • IPDS only for Ethernet LAN attach •... - Page 10 The following 4247 Model Z03 publications are shipped with each printer. • Model Z03: Quick Setup Guide (hardcopy) • 4247 Model Z03: Safety Information (hardcopy) • 4247 Model Z03: Statement of Limited Warranty (hardcopy when required by country law) • A CD-ROM that contains softcopy of the following publications: –...
-
Page 11: Technical Information
Paper handling: • Continuous forms The 4247-Z03 will handle up to 8-part continuous forms in either front paper path. For the tractor paths: – Form weight can range from 56 grams per square meter (gsm) (15 lb) to 150 gsm (40 lb). - Page 12 Input voltage required Input voltages required for 4247-Z03 Universal Power Supply: 100 - 127 V ac single-phase grounded 50/60 Hz 200 - 240 V ac single-phase grounded 50/60 Hz Printer heat output Maximum estimated heat output: 115 volt, 60 Hz: 500 BTU/hr or 147 Watts...
- Page 13 PSF OS400 Release V5R2 and higher PSF for Z/OS Release 4.1 and higher In PSF for Z/OS, the 4247 is only supported in 4247 native and 4247 emulation modes. In PSF/MVS the 4230 was supported in 4224 emulation mode only, and not in native mode.
- Page 14 Attachment connector type RJ-45 Network traffic led Yes (green) Network speed led Yes(yellow) Firmware upgrade Firmware upgrade over network Firmware upgrade over parallel interf InfoPrint Solutions Company Asia Pacific InfoPrint is a registered trademark of Ricoh Co., Ltd. Hardware Announcement AG08-0532...
- Page 15 • The front continuous forms paper path will handle up to 8-part forms. Forms greater than 4- part should be tested for readability prior to use. • The following ASCII restrictions apply when using 4247 native escape commands to print bar code: –...
-
Page 16: Terms And Conditions
Supplies Ordering supplies End users can contact Priority Fulfillment Services (PFS) for the name of an InfoPrint Solutions Company Reseller in their area where 4247 supplies can be purchased. Resellers can order ribbons for the 4247 through PFS. To contact PFS, please call 1-972-881-0733 (extension 3234) in the United States. -
Page 17: Pricing
Field-installable features Model conversions Machine installation Customer setup. Customers are responsible for installation according to the instructions InfoPrint Solutions Company provides with the machine. Graduated program license charges apply Licensed internal code and licensed machine code This product does not contain Licensed Internal Code or Licensed Machine Code. - Page 18 Trademarks IPDS is a trademark of Ricoh Co., Ltd. in the United States, other countries, or both. InfoPrint is a registered trademark of Ricoh Co., Ltd. in the United States, other countries, or both. Ricoh is a registered trademark of Ricoh Co., Ltd. and its affiliated companies.
