User's Manual - Operating Guide
User's Manual - Operating Guide
Thank you for purchasing this projector.
WARNING
Safety Guide" and related manuals to ensure the proper use of this product.
After reading them, store them in a safe place for future reference.
NOTE
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual.
• The reproduction, transfer or copy of all or any part of this document is not permitted without
express written consent.
TRADEMARK ACKNOWLEDGMENT :
• VGA and XGA are registered trademarks of International Business Machines Corporation.
• Apple and Mac are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
• Internet Explorer is a trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.
Before using the product, please read the "User's Manual -
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV 880 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Liesegang DV 880

Summary of Contents for Liesegang DV 880

  • Page 1 Projector User's Manual - Operating Guide User's Manual - Operating Guide Thank you for purchasing this projector. WARNING Before using the product, please read the "User's Manual - Safety Guide" and related manuals to ensure the proper use of this product. After reading them, store them in a safe place for future reference.

  • Page 2: Projector Features

    Projector Features Projector Features This multimedia projector is used to project various computer signals as well as NTSC/PAL/SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. ● Ultra High Brightness Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly efficient optical system.

  • Page 3: Table Of Contents

    Content Content Projector Features Multifunctional Settings Preparation Using The Menu Functions Part Names MAIN Menu Projector PICTURE-1 Menu Control Buttons PICTURE-2 Menu Remote control INPUT Menu Setting Up AUTO Menu Arrangement SCREEN Menu Adjusting The Projector’s OPTION Menu Elevator NETWORK Menu Using The Lens shift Buttons Network Setting Up Connecting Your Devices...

  • Page 4: Part Names

    Part Names Part Names Projector Elevator button Elevator foot Remote sensor Lens cap Lens The picture is projected from here. Filter cover An air filter is inside. Projector (Front/Right) RGB port M1-D port BNC port AUDIO IN 1 port AUDIO IN 2 port CONTROL port NETWORK port AUDIO IN R/L port...

  • Page 5: Control Buttons

    Part Names (continued) Part Names (continued) Control Buttons STANDBY/ON button and STANDBY/ON indicator TEMP indicator LAMP indicator LENS SHIFT buttons INPUT dial SEARCH button M1-D indicator RGB indicator BNC indicator COMPONENT indicator S-VIDEO indicator VIDEO indicator ZOOM buttons FOCUS buttons KEYSTONE button MENU button Control Panel...

  • Page 6: Setting Up

    Setting Up Setting Up Arrangement WARNING • Before installation, make sure that the projector is turned off and the power code is disconnected. • Do not set up and move the projector, while it is hot. • Install the projector in a suitable environment according to instructions of the “User’s Manual –...

  • Page 7: Adjusting The Projector's Elevator

    Setting Up (continued) Setting Up (continued) Adjusting The Projector's Elevator WARNING • Do not touch about the lens and ventilation openings during use or immediately after use to prevent a burn. CAUTION • Do not incline the projector rightward or leftward. Also do not incline it backward or forward exceeding 9 degrees.

  • Page 8: Connecting Your Devices

    Setting Up (continued) Setting Up (continued) Connecting Your Devices WARNING • Whenever attempting to connect other devices to the projector, read thoroughly the "User's Manual - Safety Guide", this manual and the manual of each device to be connected. Incorrect connecting could result in fire or electrical shock. CAUTION •...

  • Page 9: Examples Of Connection With A Computer

    Setting Up (continued) Setting Up (continued) Please refer to the following (for example) for connecting your devices. See the rear of the projector. You can see the ports. Examples of connection with a computer Computer Projector RGB out RGB cable Audio out Stereo Mini cable AUDIO IN 2...
  • Page 10 Setting Up (continued) Setting Up (continued) Examples of connection with a VCR/DVD Player VCR/DVD Player Projector CONTROL NETWORK REMOTE CONTROL AUDIO IN1 R-AUDIO IN-L VIDEO Audio out (R) AUDIO OUT R-AUDIO IN AUDIO IN2 CR/PR Ca/Pa RGB OUT Audio out (L) AUDIO IN-L R-AUDIO IN-L VIDEO...

  • Page 11: Connecting The Power Supply

    Setting Up (continued) Setting Up (continued) Connecting to a monitor CONTROL NETWORK REMOTE CONTROL AUDIO IN1 AUDIO OUT AUDIO IN2 CR/PR Ca/Pa RGB OUT Monitor Projector R-AUDIO IN-L VIDEO S-VIDEO RGB in RGB cable RGB OUT Connecting to a speaker (with amplifier) CONTROL NETWORK REMOTE CONTROL...

  • Page 12: Remote Control

    Remote Control Remote Control About The Laser Pointer WARNING • The laser pointer of the remote control is used in place of a finger or rod. Never look directly into the laser beam outlet or point the laser beam at other people.

  • Page 13: Operating The Remote Control

    Remote Control (continued) Remote Control (continued) Operating The Remote Control CAUTION • Do not disassemble the remote control. • Do not place the remote control near the projector’s lens, fan, or vents. • Do not drop or otherwise expose the remote control to physical impact. •...

  • Page 14: Using The Mouse/Keyboard Control Function

    Remote Control (continued) Remote Control (continued) Using The Mouse/Keyboard Control Function CAUTION • Before connecting, read the manuals of the device you will connect. Mistaken use of the mouse/keyboard control could damage your equipment. • Only connect to a PC or an USB Hub connected PC. •...

  • Page 15: Power On/Off

    Power ON/OFF Power ON/OFF WARNING • When the power is ON, a strong light is emitted. Do not look into the lens or vents of the projector. NOTE • Turn the power on/off in right order. Please power on the projector before the connected devices.

  • Page 16: Operating

    Operating Operating Selecting An Input Signal Select an input signal. ■ Using the INPUT dial SEARCH button Turn the INPUT dial of the projector. Turning the dial cycles through the input ports as shown below. Select the signal you wish to project. M1-D VIDEO S-VIDEO...

  • Page 17: Selecting The Aspect Ratio

    Operating (continued) Operating (continued) Selecting The Aspect Ratio LASER INDICATOR STANDBY/ON VIDEO Press the Aspect button to toggle between the modes for LENS SHIFT FOCUS ZOOM – – – ASPECT aspect ratio. BLANK ASPECT LASER button ■ For an RGB signal PREVIOUS NEXT MOUSE...

  • Page 18: Adjusting The Picture Position

    Operating (continued) Operating (continued) Adjusting The Picture Position This function is not available for M1-D signals. memo Press the POSITION button. LASER INDICATOR As illustrated on the right, a STANDBY/ON VIDEO dialog will appear on the LENS SHIFT FOCUS ZOOM screen to aid you in adjusting –...

  • Page 19: Adjusting The Volume

    Operating (continued) Operating (continued) Adjusting The Volume Press the VOLUME button. VOLUME LASER INDICATOR As illustrated on the right, a dialog STANDBY/ON VIDEO will appear on the screen to aid you LENS SHIFT FOCUS ZOOM in adjusting the volume. – –...

  • Page 20: Freezing The Screen

    Operating (continued) Operating (continued) Freezing The Screen Press the FREEZE button. As illustrated on the right, a LASER INDICATOR STANDBY/ON VIDEO dialog will appear on the screen, and the screen will LENS SHIFT FOCUS ZOOM – – – FREEZE BLANK ASPECT LASER freeze at the current image.

  • Page 21: Displaying The Child Window

    Operating (continued) Operating (continued) Displaying The Child Window This feature called "PinP (Picture in Picture)" is available only when a RGB signal is selected memo to main screen. And this feature does not work when UXGA (1600 x 1200) or higher signal is input. Press the PinP button.

  • Page 22: Multifunctional Settings

    Multifunctional Settings Multifunctional Settings Using The Menu Functions This projector has the following menus: MAIN, PICTURE-1, PICTURE-2, INPUT, AUTO, SCREEN, OPTION and NETWORK. Each of these menus is operated using the same methods. The basic operations of these menus are as follows. ex.

  • Page 23: Main Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU MAIN Menu MAIN BRIGHT PICTURE-1 CONTRAST PICTURE-2 ASPECT INPUT WHISPER NORMAL With the MAIN menu, the items shown in the table below can be AUTO MIRROR NORMAL SCREEN LANGUAGE ENGLISH performed. Perform each operation in accordance with the OPTION [Language] NETWORK...

  • Page 24: Picture-1 Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU PICTURE-1 Menu MAIN GAMMA NORMAL PICTURE-1 COLOR BAL R PICTURE-2 COLOR BAL G INPUT COLOR BAL B With the PICTURE-1 menu, the items shown in the table below can AUTO SHARPNESS SCREEN COLOR be performed.
  • Page 25 Multifunctional Settings (continued) Multifunctional Settings (continued) PICTURE-1 Menu (continued) Item Description Select a command to load or save using the buttons, and then press (or the ENTER) button to perform the function.: LOAD1 LOAD2 LOAD3 LOAD4 SAVE1 SAVE2 SAVE3 SAVE4 This projector has 4 numbered memories for adjustment data.

  • Page 26: Picture-2 Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU PICTURE-2 Menu MAIN V POSITION PICTURE-1 H POSITION PICTURE-2 H PHASE INPUT H SIZE 1344 With the PICTURE-2 menu, the items shown in the table below can AUTO OVER SCAN SCREEN RESET be performed. Perform each operation in accordance with the OPTION instructions in the table below.

  • Page 27: Input Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU INPUT Menu MAIN COLOR SPACE AUTO PICTURE-1 COMPONENT COMPONENT PICTURE-2 VIDEO AUTO INPUT 3D-YCS TURN OFF With the INPUT menu, the items shown in the table below can be AUTO VIDEO NR SCREEN P.
  • Page 28 Multifunctional Settings (continued) Multifunctional Settings (continued) INPUT Menu (continued) Item Description Select a signal input port for the child window using the buttons. : VIDEO S-VIDEO P.IN P. INPUT memo About the child window, please refer to the section “Displaying the Child Window”.

  • Page 29: Auto Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU AUTO Menu MAIN ADJUST PICTURE-1 POWER OFF 0 min PICTURE-2 SEARCH TURN ON INPUT RESET With the AUTO menu, the items shown in the table below can be AUTO performed. Perform each operation in accordance with the SCREEN OPTION instructions in the table below.
  • Page 30 Multifunctional Settings (continued) Multifunctional Settings (continued) AUTO Menu (continued) Item Description Select the TURN ON or the TURN OFF using the buttons. : TURN ON TURN OFF When the TURN ON is selected, detecting no signal cycles through input ports and displays the picture of retrieved signal.

  • Page 31: Screen Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU SCREEN Menu MAIN BLANK BLACK PICTURE-1 START UP ORIGINAL PICTURE-2 MyScreen INPUT MyScreen LOCK TURN OFF With the SCREEN menu, the items shown in the table below can be AUTO MENU POSITION SCREEN MESSAGE TURN ON performed.
  • Page 32 Multifunctional Settings (continued) Multifunctional Settings (continued) SCREEN Menu (continued) Item Description Select the TURN ON or the TURN OFF using the buttons. : TURN ON TURN OFF When the TURN ON is selected, the following message function works. The message of the “AUTO IN PROGRESS” for the auto adjustment. The message of the “NO INPUT IS DETECTED”...

  • Page 33: Option Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU OPTION Menu MAIN VOLUME PICTURE-1 SPEAKER TURN ON PICTURE-2 IR REMOTE 1: 2: 3: INPUT IR REMOTE ID With the OPTION menu, the items shown in the table below can be AUTO LAMP TIME 1234 h SCREEN FILTER TIME...
  • Page 34 Multifunctional Settings (continued) Multifunctional Settings (continued) OPTION Menu (continued) Item Description Pressing the (or the ENTER) button calls the SERVICE menu. SERVICE FANSPEED NORMAL SERVICE Menu AUTO ADJUST ENABLE Select an item using the buttons, and press the (or the LENS TYPE AUTO LENS LOCK...

  • Page 35: Network Menu

    Multifunctional Settings (continued) Multifunctional Settings (continued) MENU NETWORK Menu MAIN SETUP PICTURE-1 DHCP TURN OFF PICTURE-2 INFORMATION INPUT RESET This projector provides the NETWORK function. If you use this AUTO SCREEN function, please set up the projector according to the Network OPTION environment in which you use it.

  • Page 36: Network Setting Up

    Network Setting Up Network Setting Up This projector provides the NETWORK function. When you start to use this function, please consult your dealer for further information. To start, connect the NETWORK port to a gateway device via a CAT-5 cable, then set up the projector according to the Network environment in which you use it.

  • Page 37: Lamp

    Lamp Lamp WARNING HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.

  • Page 38: Replacing The Lamp

    Lamp (continued) Lamp (continued) Replacing The Lamp If the indicators or a message prompts you to replace the lamp, replace the lamp as soon as possible. Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at least 45 minutes.

  • Page 39: Air Filter

    Air Filter Air Filter WARNING • Please carefully read the “User’s Manual - Safety Guide. • Before caring, make sure the power switch is off and the power cable is not plugged in, then wait at least 45 minutes for the lamp to cool sufficiently. •...

  • Page 40: Other Care

    Other Care Other Care WARNING • Please carefully read the “User’s Manual - Safety Guide”. • Before caring, make sure the power switch is off and the power cable is not plugged in. • Be cautious of high temperature. Do not touch about the lens and ventilation openings during use or immediately after use prevent a burn.

  • Page 41: Troubleshooting

    roubleshooting roubleshooting Related Messages When the unit's power is on, messages such as those shown below may be displayed. When any such message is displayed on the screen, please respond as described below. If the same message is displayed after the treatment, or if a message other than the following appears, please contact your dealer or service company.
  • Page 42 roubleshooting (continued) roubleshooting (continued) Related Messages (continued) Message Description REMINDER The time the filter timer has counted has reached the *** HRS PASSED AFTER THE LAST interval time set by the "FILER MESSAGE" of FILTER CHECK "SERVICE" item in the OPTION menu. FILTER MAINTENANCE IS Please clear or change the air filter by referring to the section ESSENTIAL TO REMOVE WARNING...

  • Page 43: Regarding The Indicator Lamps

    roubleshooting (continued) roubleshooting (continued) Regarding The Indicator Lamps Lighting and flashing of the STANDBY/ON indicator, the LAMP indicator, and the TEMP indicator have the meanings as described in the table below. Please respond in accordance with the instructions within the table. If the same indication is displayed after the treatment, or if an indication other than the following is displayed, please contact your dealer or service company.
  • Page 44 roubleshooting (continued) roubleshooting (continued) Regarding The Indicator Lamps (continued) STANDBY/ON LAMP TEMP Description indicator indicator indicator Either there is no lamp and/or lamp cover, or either of these has not been properly fixed. Please turn the power off, and allow the unit to cool down at Lighting Blinking Turned...

  • Page 45: Phenomena That May Easily Be Mistaken For Machine Defects

    roubleshooting (continued) roubleshooting (continued) Phenomena That May Easily Be Mistaken For Machine Defects WARNING • Never use the projector if abnormal operations such as smoke, strange odor, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. should occur. In such cases, immediately turn off the power switch and then disconnect the power plug from the power outlet After making sure that the smoke or odor has stopped, contact your dealer or service company.

  • Page 46: The Signal Cables Are Not Correctly Connected

    roubleshooting (continued) roubleshooting (continued) Phenomena That May Easily Be Mistaken For Machine Defects (continued) Reference Phenomenon Cases not involving a machine defect pages The signal cables are not correctly connected. 8, 9 Correctly connect the connection cables. The volume is adjusted to an extremely low level. 19, 33 Pictures are Adjust the VOLUME to a higher level.

  • Page 47: Warranty And After-Service

    arranty And After-Service arranty And After-Service If a problem occurs with the equipment, first refer to the “Troubleshooting” and run through the suggested checks. If this does not resolve the problem, please contact your dealer or service company. They will tell you what warranty condition is applied. Specifications Specifications NOTE...
