Programmable Function Keys - Icom IC-F51V Instruction Manual

2
PANEL DESCRIPTION

■ Programmable function keys

The following functions can be assigned to [P0], [P1], [P2], [P3],
[Red], [
Consult your Icom dealer or system operator for details concern-
ing your transceiver's programmed keys and their functions.
CH UP AND DOWN KEYS
➥ Push to select an operating channel.
➥ Push to select a transmit code channel after pushing [TX Code
CH Select].
➥ Push to select a DTMF channel after pushing [DTMF Autodial].
➥ Push to select a scan group after pushing and holding [Scan A
Start/Stop]/[Scan B Start/Stop].
ZONE SELECT KEY
Push this key, then select the desired zone using [CH Up]/[CH
Down].
What is a "zone"?—The desired channels are assigned into a
zone according to the intended use for grouping. For example,
'Staff A' and 'Staff B' are assigned into a "Business" zone, and
'John' and 'Cindy' are assigned into a "Private" zone.
SCAN A START/STOP KEY
➥ This key's operation depends on the Power ON Scan setting.
When the power ON scan function is turned OFF;
Push to start and cancel scanning operation.
When the power ON scan function is turned ON;
Push to pause scanning, then resumes scanning after a speci-
fied time period has passed.
➥ Push and hold this key for 1 sec. to indicate the scan group,
then select the desired scan group using [CH Up]/[CH Down].
8
] and [ ] programmable function keys.
