Installing LecNet2

This Graphical User Interface (GUI) is designed to allow
easy setup and monitoring of DM components using a
computer system running under the Windows
XP operating system.
Installing LecNet2 ™ Software
1. Use the computer control panel to remove
any previously installed versions of LecNet2
software. (This will ensure you are using the
latest release.)
2. Insert the LecNet2 program disk supplied
with the Venue Receiver into the CD-ROM
drive on the computer system that will be
used to set up and control the Venue
Receiver.
3. The CD should automatically start the
installation procedure. If it doesn't, click
"Start" on the WIndows Task Bar then click
"Run..." Enter the Drive number followed by
"Setup.exe" as shown below.
4. Follow the on-screen instructions to install the
LecNet2 software.
Installing the LecNet2 ™
There are two methods of connecting a Windows
based computer system to the DM component, either
via a USB cable or an RS-232 cable. Although the USB
port offers significantly increased speed and conve-
nience over standard RS-232 links, it does require the
installation of a LecNet2™ USB driver.
The LecNet2 USB driver is not part of the standard
Windows ® 2000 and XP driver libraries. As a result,
connecting a computer system to the DM for the first
time is different than subsequent installations. There
are a few minor differences between installing the
LecNet2 USB drivers on a Windows 2000 versus a
Windows XP system.
USB driver installation Windows XP
When the DM is connected to a Windows XP computer
system for the very first time, the Windows
Hardware Found Wizard" automatically opens.
® 2000 or
USB Driver
®
® "New
Rio Rancho, NM
™
Software and USB Driver
First time installation
When a Lecnet2 device is connected to the PC for the
very first time, the Windows Found New Hardware
Wizard automatically opens. Use the following proce-
dure to install the Lecnet2 USB driver using the Wizard.
1. Place the Lecnet2 Installation Disk in the
PC's CD-ROM drive.
2. On the first page of the Wizard, select the
option Install from a list or specific
location (Advanced) and click Next> to
continue to the next page.
3. Select "Search for the best driver in these
locations", then check the box for "Search
-
removable media (floppy, CD-ROM...)" and
click Next> to continue to the next page..
4. Windows will search the CD for the driver and
when it has found it, it is likely that a dialog
will open warning you that the driver has not
passed Windows Logo Testing. This is OK,
click Continue Anyway.
