I N S T A L L A T I O N G U I D E
for the
SB-GM-TRLBLZR/10W3v3
2002-Up Chevrolet Trailblazer
2002-Up GMC Envoy
2003-Up Buick Rainier
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 2 years if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
SB-GM-TRLBLZR/10W3v3_INSTR_SKU#011184
INSTALLATION
D I F F I C U LT Y :
2
S T E P 1
Remove all contents from the cargo area.
S T E P 2
With a 7mm socket, remove the two bolts that are located
at the rear of the passenger's side rear wheel well.
S T E P 3
With a flat bald screw driver, remove the two push/pull
tabs that are located behind the passenger's side rear tire.
Continued on Next Page
