Saber Compact ATD?80352 User Manual page 5

ITEM# ORDERING PART# PART DESCRIPTION
1 PRT80351-01
2 PRT80351-02
3 PRT80352-03
4 PRT80351-03
5 PRT80351-04
6 PRT80351-05
7 PRT80352-07
8 PRT80351-07
9 PRT80351-08
10 PRT80351-09
11 PRT80351-10
12 PRT80351-11
PULL ROD
SCREW M5X9
LI-ION BATTERY
LEFT HANDLE SET
SCREW M3X5
PROTECTING COVER
LED PCB
CLEAR TUBE LOWER
SCREW 2.9 X16
BATTERY INDICATE COVER
RIGHT HANDLE SET
ON/OFF SWITCH
Visit us at www.atdtools.com
Copyright (C) 2013 ATD Tools, Inc. All rights reserved.
ATD-80352
ITEM# ORDERING PART# PART DESCRIPTION
13 PRT80352-13
14 PRT80352-14
15 PRT80352-15
16 PRT80351-14
17 PRT80351-15
18 PRT80351-16
19 PRT80351-17
20 PRT80352-20
21 PRT80351-19
22 PRT80351-20
23 PRT80351-21
24 PRT80352-24
BATTERY CAPACITY INDICATE
DC OUTLET
CHARGING WIRE
SWIVEL SHAFT
POSITION BLOCK
LAMP HOLDER
PRESSURE SPRING
PCBA
ALUMINUM TUBE UPPER
ELASTIC BAND
BLOCK
CHARGER
