35W COB LED Work Light w/Telescopic Stand
Features:
Super bright 35 Wa COB LED
Heavy-duty industrial design with diecast aluminum housing
16 . water-resistant power cord remains exible in cold weather
Quick fastening light head for easier adjustment
160 degree horizontal rota on on base
Rota ng telescopic stand easily folds for storage and extends from 25" to 72"
IP67 rated for dust and water resistance
CSA outdoor cer
cate
Long beam distance
Power Cord: 18/3 SJTW
Lumens: 2800-3000
Lux: 900-1200
ATD-80335
Instruction Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Saber Compact ATD-80335
Summary of Contents for Saber Compact ATD-80335
- Page 1 ATD-80335 35W COB LED Work Light w/Telescopic Stand Instruction Manual Features: Super bright 35 Wa COB LED Heavy-duty industrial design with diecast aluminum housing 16 . water-resistant power cord remains exible in cold weather Quick fastening light head for easier adjustment 160 degree horizontal rota on on base Rota ng telescopic stand easily folds for storage and extends from 25”...
- Page 2 California Prop 65 WARNING: This product contains chemicals including lead, known to the State of California to cause cancer, birth defects, or other reproductive harm. Wash hands after handling. General Safety Warnings: WARNING: The instructions and warnings contained in this manual should be read and understood before using or operating this light.
- Page 3 WARNING: Before connecting a light to a power supply, always check to ensure the power supply corresponds to the voltage on the nameplate of the light. A power supply with a voltage greater than that specified for the light can result in serious injury to the user, as well as damage to the light.
- Page 4 the motor of your tool. If in doubt, always use a larger gauge cord. Be sure to check the voltage requirements of the light to your incoming power source. NOTE : The table below shows the correct size to use according to cord length and the amperage draw of the light (specified on the nameplate).
- Page 5 ATD 80335 Assembly Instructions: Illustration A: Ref# Description Light head Bolt 1/4" Flat washer Spring washer Bracket Light head bracket 1) Insert bolt (02) through the light head bracket (06) slide spring washer (04) and flat washer (03) to the bolt (02) and then thread bolt (02) to the tripod stand as shown illustration above.
- Page 6 ATD-80335 CREW PRT80335-14 O RING Visit us at www.atdtools.com...
