JL Audio Stealthbox SB-F-EXPED2/10W3v3 Installation Manual page 3

Page 3 • JL Audio, Inc 2007
S T E P 1 2
Pop out the circle cover that is located in the upper portion
of the c-pillar plastic cover.
With an 8mm socket, remove the bolt.
S T E P 1 3
Remove the upper c-pillar plastic cover.
S T E P 1 4
Remove the driver's rear door sill plate.
S T E P 1 5
Remove the tailgate's upper sill plate.
Remove the upper d-pillar plastic cover.
SB-F-EXPED2/10W3v3_INSTR_SKU#011237 SB-F-EXPED2/10W3v3_INSTR_SKU#011237
S T E P 1 6
With an 8mm socket, remove the bolt that secures the side
panel metal bracket to the floor.
S T E P 1 7
Pull the rear portion of the side panel from location. Feed the
third row seat belt through the opening of the side panel.
S T E P 1 8
Pull the front portion of the side panel from location. Feed
the second row seat belt through the opening of the side
panel.
S T E P 1 9
Remove the side panel from the SUV.
Continued on Next Page
