INSTRUCTION MANUAL SC-X80 VACUUM CLEANER SC-X90 Contents IMPORTANT SAFETY INSTRUCTIONS NAMES OF EACH PART PREPARATIONS BEFORE USE USING THE VACUUM CLEANER USING THE ATTACHMENTS EMPTYING THE DUST COMPARTMENT CLEANING THE FILTERS CLEANING THE SECONDARY FILTERS CLEARING BLOCKAGES AND CLEANING THE AGITATOR ASSEMBLY... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following. READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER WARNING To reduce the risk of fire, electric shock or injury: 1. Do not leave the vacuum cleaner when plugged in. Unplug it from the outlet when not in use and before servicing. -
Page 3: Save These Instructions
16. Do not touch the agitator while it is spinning. 17. Do not place any heavy items on top of the vacuum cleaner. 18. Do not step on the hose or pull it too strongly. 19. Do not pick up items such as pieces of waste paper or cloth which look as though they may cause the hose to become blocked. -
Page 4: Names Of Each Part
NAMES OF EACH PART FRONT REAR Handle Cord Storage Power Cord Hooks Power Cord Plug Plug shown in Suction Hose figure may differ Hose from actual plug Release Button Holder attached to unit for your area. Carrying Handle ON/OFF Switch Crevice Tool Dust Compartment... -
Page 5: Preparations Before Use
PREPARATIONS BEFORE USE Caution: Do not connect the power cord plug to the wall outlet until assembly is completed. Attaching the handle Insert the screw that you Set the vacuum cleaner The handle screw has removed.Be sure screw to the upright position. been installed for is tightened,but not shipping purposes. -
Page 6: Winding The Power Cord
PREPARATIONS BEFORE USE WINDING THE POWER CORD Wind the power cord around the cord Hook the power cord over storage hooks. the clip which is located on the upper cord storage hook as shown. Cord Storage Hooks Plug Side Hose Holder Plug shown in figure may differ from actual plug... -
Page 7: Using The Vacuum Cleaner
USING THE VACUUM CLEANER ON/OFF SWITCH Start or stop vacuum cleaner by pushing on the switch. ON/OFF Switch ADJUSTING THE HANDLE The handle of this vacuum cleaner can be set to one of three positions-Upright,Normal,Parallel.Place your foot on either one of the handle release points as shown and pull back on the handle until it releases from its upright position. -
Page 8: Using The Attachments
USING THE ATTACHMENTS Caution: When using the attachments during cleaning, set the vacuum cleaner to the upright position. Disconnect the hose from the vacuum cleaner. Hose Pull the hose gently in the direction of the arrow to disconnect it. Hook the hose holder onto the holder mount. -
Page 9: Emptying The Dust Compartment
EMPTYING THE DUST COMPARTMENT Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before cleaning. Empty the dust compartment when Push the release button to remove the dust compartment. contents reach the MAX mark. -
Page 10: Cleaning The Filters
CLEANING THE FILTERS Remove the dust compartment.(refer to page 8) Release Button B Set the dust compartment to the parallel position. Open the trapdoor, then push the release button B and pull out the main filter. The main filter and prefilter will be removed at the same time. -
Page 11: Cleaning The Secondary Filters
CLEANING THE AIR OUTLET FILTER The secondary filters consist of a general filter and a sub-filter. Only use genuine Sanyo replacement filters. Filter Cover Remove the filter cover. Remove the air outlet filter from the filter cover. -
Page 12: Cleaning The Agitator Assembly
CLEARING BLOCKAGES IN THE SUCTION HOSE AND CLEANING THE AGITATOR ASSEMBLY Caution: Be sure to turn the ON/OFF switch to the" OFF " position and disconnect the power cord from the wall outlet before clearing any blockages in the suction hose and cleaning the agitator assembly. Clearing blockages in the suction hose Set the vacuum cleaner to the upright position. -
Page 13: Replacement Instructions
REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the "OFF " position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE FLAT BELT Remove the bottom plate. (refer to page 14) Lift out the agitator assembly,and then remove the flat belt from the motor shaft and the agitator pulley. - Page 14 REPLACEMENT INSTRUCTIONS Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the power cord from the wall outlet before replacing any of the parts below. REPLACING THE AGITATOR Remove the bottom plate. (refer to page 14) Lift out the agitator assembly,and then remove the agitator assembly as shown.
-
Page 15: Reattaching The Bottom Plate
REPLACEMENT INSTRUCTIONS REMOVING THE BOTTOM PLATE Set the vacuum cleaner to the Pull here parallel position and turn it over. Latch PULL Slide the latch in the direction shown. Bottom Plate Remove the bottom plate by pulling the tabs as illustrated. REATTACHING THE BOTTOM PLATE Insert the projection on the Push the bottom plate as shown. -
Page 16: Troubleshooting
Turn the ON/OFF switch to the "OFF" position, disconnect the power cord from the wall outlet, and contact the place of purchase or your nearest Sanyo Service Center.
