Festool C 12 Li Instruction Manual page 12

WH-CE
CENTROTEC
®
5-1
Attaching the CENTROTEC
Pull the release ring
Attach the tool chuck to the drill spindle
[5-4].
Release the ring [5-3].
Detaching the CENTROTEC
Pull the release ring
Remove the tool chuck.
Changing tools
Pull back the green release ring
attach or detach tools with a CENTROTEC
shank.
When attaching the tool, rotate until the
hexagon shank
hexagon holder on the drill spindle.
Release the ring [5-2].
Chuck BF-FX
The chuck BF-FX is used for clamping drill
and screwdriver bits.
BF-FX
6-1 6-2
Attaching the chuck BF-FX
Attach the chuck to the drill spindle [6-5].
Pull the release ring
Turn until the hexagon pin
chuck engages in the hexagon socket
holder in the drill spindle.
Push the chuck all the way onto the drill
spindle.
Release the ring [6-4].
Detaching the chuck BF-FX
Pull the release ring
Remove the chuck.
12
5-2 5-3 5-4
[5-3] forwards.
[5-3] forwards.
[5-1] engages in the
6-3 6-4
6-5
[6-3] forwards.
[6-4]
[6-4] forwards.
Changing tools
Turn the clamping sleeve
wise to open the clamping jaws [6-1].
The arrow on the spindle indicates the
opening direction.
Insert the tool into the chuck.
Risk of injury
Clamp the tool centrally in the chuck!
Turn the clamping sleeve
to clamp the tool.
Angle attachment DD-AS
The angle attachment DD-AS (partly acces-
sories) allows you to work (drill, fasten) ver-
tically in relation to the longitudinal axis on
the machine.
[5-2] to
DD-AS
Fitting the angle attachment DD-AS
Fit the angle attachment to the drill spin-
dle.
Turn the attachment until is engages in
the required position.
You can engage the angle attachment in
16 different positions.
Turn the securing ring
wise to lock the angle attachment.
Removing the angle attachment DD-AS
Turn the securing ring
on the
all the way.
Remove the angle attachment.
Attaching/Detaching the chuck
The chuck is secured to the shaft
angle attachment and the drill spindle on the
machine in the same way.
Eccentric attachment DD-ES
The eccentric attachment (partly accesso-
ries) enables you to fasten close to abutting
CAUTION
7 - 2
7 - 1
[7-2]
[7-2]
[6-2] anticlock-
[6-2] clockwise
firmly clock-
anticlockwise
[7-1] of the
