- Page 1 SwItch uSer Manual Model 156066 INT-156066-UM-0808-01...
- Page 3 IntroDuctIon Thank you for purchasing the INTELLINET NETWORK SOLUTIONS ™ DVI KVM Switch, Model 156066. This convenient device lets you control up to four USB computers with one PS/2 keyboard, PS/2 mouse and DVI-I video monitor. Easy switching can be done using hot keys or logically designed push-button selectors, and setup is relatively simple since no software needs to be installed.
-
Page 4: Connectors And Indicators
Operation is also subject to these two conditions: 1) This device may not cause harmful interference; and 2) This device must accept any interference received, including interference that may cause undesired operation. Shielded interface cables must be used to comply with emission limits, and changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. -
Page 5: Installation
InStallatIon When deciding where to place the DVI KVM Switch, consider the cable lengths required to make all configuration connections, particularly of USB cables, which typically maintain optimal signal strength when limited to about 4.5 m (15 ft.). NOTE: Avoid placing cables near devices that output electrical “noise”... -
Page 6: Connecting Optional Components
ConnECting oPtional CoMPonEnts 1. If desired, connect your speakers (3.5mm rear- panel jack) and headphones/microphone (3.5mm front-panel jacks) as designated by the speaker, headphone and microphone symbols. NOTE: The switch’s front speaker and audio port or the rear panel console speaker and audio port can be used, but using both front and rear speaker / audio ports simultaneously will result in loss of audio. - Page 7 sElECting CoMPutErs using hot kEys You can directly change the DVI KVM Switch focus to any computer using a simple keyboard command sequence: the Scroll Lock key and the switch port number. Each computer is assigned a numeric ID. 1. To activate the Hot Key mode, press the SCROLL LOCK key twice within two seconds.
-
Page 8: Autoscan Mode
and change the switch’s focus to another computer at the same time. Just use the SCROLL LOCK / SCROLL LOCK / X sequence as explained above to switch ports: The selected USB device will remain as it was. NOTE: Not all USB storage devices are suitable for such dynamic port- switching applications. -
Page 9: Specifications
SpecIfIcatIonS general • Computer connections: 4 • Selection buttons with 2-color LEDs: 4 • Port selection: hot key / push button • Resolution: 1600 x 1200 • Flash upgrade port: mini USB A-type Computer Ports • VGA: 4 sets, DVI-I 29-pin female •... - Page 10 NOTES...
- Page 12 INTellINeT NeTWoRK SolUTIoNS offers a complete line ™ of active and passive networking products. Ask your local computer dealer for more information or visit www.intellinet-network.com Copyright © INTELLINET NETWORK SOLUTIONS All products mentioned are trademarks or registered trademarks of their respective owners.
