WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency, or the gas supplier.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- Installation must be performed by a qualified installer, service agency or the gas supplier
IF YOU SMELL GAS
¥ Do not try to light any appliance.
¥ Do not touch any electrical switch; do not use any phone in your building.
¥ Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
¥ If you cannot reach your gas supplier, call the fire department.
AVANTI B-V
Installer: After installation give this manual
to the homeowner and explain
operation of this heater.
B-Vent Gas Stove
Fireplace Insert
¥ Freestanding Stove
¥ Masonry Fireplace Insert
¥ Factory Built (Z.C.) Fireplace
ENT
- September, 1995 -
By Avalon
and
Insert
Listed
G
H
AS
10850 117th Place N.E. Kirkland, WA 98033
EATER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avalon B-VENT
Summary of Contents for Avalon B-VENT
-
Page 1: Introduction & Important Information
By Avalon B-Vent Gas Stove Fireplace Insert ¥ Freestanding Stove ¥ Masonry Fireplace Insert ¥ Factory Built (Z.C.) Fireplace Insert Listed WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult a qualified installer, service agency, or the gas supplier. -
Page 2: Safety Precautions
AFETY RECAUTIONS ¥ IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department ¥... - Page 3 AFETY RECAUTIONS ONTINUED ¥ Do not place clothing or ¥ Light the heater using the other flammable items on built-in piezo igniter. Do or near the heater. not use matches or any Because this heater can be other external device to controlled by a thermostat light your heater.
-
Page 4: Table Of Contents
Steps for Finalizing the Installation ....23 Avanti Gold Trim ........... 38 1 Removing the Door ......23 Avanti LP (Propane) Burner Pan ....39 2 Accessing the Firebox ......23 45° Flue Adapter ........... 41 3 Installing the Logs and Coals ....24 4 Glass Sealing ........ -
Page 5: Features & Specifications
EATURES AND PECIFICATIONS Installation Options: Features: ¥ Works During Power Outages (millivolt system) ¥ Freestanding ¥ High Efficiency; 80% Natural Gas, 82% LP (Steady State) ¥ Masonry Fireplace Insert ¥ Optional Thermostat or Remote Control ¥ Realistic "Wood Fire" Look ¥... -
Page 6: Stove Installation
Items Packed with the Heater Items Packed with the Stove Panel Kit ¥ Avanti Gas Heater (with gold door) ¥ Top, Left, Right, and Rear Stove Panels ¥ On/Off Switch (with jumper wire attached) ¥... -
Page 7: Stove Panel Assembly
.) - TOVE NSTALLATION For qualified installers only! Stove Panel Assembly 1 Remove the strain relief that holds the power cord in place. It can be found on the convection panel at the rear right of the stove. TO REMOVE THE STRAIN RELIEF Compress the strain relief from the top and bottom with a pair of slip joint... - Page 8 .) - TOVE NSTALLATION CONT For qualified installers only! 3 Direct the two red wires for the on/off switch and the molex connector for the blower out the back right of the heater (there are also two red wires leading to the spill switch Ð leave these wires in place). 4 Place the top panel upside down against a non-scratching surface.
- Page 9 .) - TOVE NSTALLATION For qualified installers only! 6 Slide the nine U-Nuts into place (see the illustration below). 7 Install the on/off switch (see the illustration below). ? If installing a thermostat or remote control, do so now. 8 Disconnect the power cord at the molex connector. Then insert the power cord through the rear panel and re-attach to the molex connector leading from the heater (see the illustration below).
-
Page 10: Installing The Gas Inlet
.) - TOVE NSTALLATION CONT For qualified installers only! Pull gently on the power cord to take out any extra slack. Replace the strain relief and push it into the hole in the rear panel (see the instructions under step 1 above). 11 Attach the control cover by sliding it over the attachment hooks. -
Page 11: Floor Protection
.) - TOVE NSTALLATION For qualified installers only! Floor Protection ¥ When the stove is installed directly on carpeting, vinyl or other combustible material other than wood flooring, the stove must be installed on a metal or wood protection panel extending the full width and depth of the pedestal (Minimum 24-1/2"... -
Page 12: Gas Line Install
.) - TOVE NSTALLATION CONT For qualified installers only! Gas Line Install The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI Z223.1 and the requirements listed below. The heater and gas control valve must be disconnected from the gas supply piping during any pressure testing of that system at test pressures in excess of 1/2 psig. -
Page 13: Gas Inlet Pressure
.) - TOVE NSTALLATION For qualified installers only! Gas Inlet Pressure ¥ With the heater off, the inlet pressure must meet the requirements listed in the table below ? If the pressure is not sufficient, make sure the piping used is large enough and the total gas load for the residence does not exceed the amount supplied. -
Page 14: Vent Requirements
.) - TOVE NSTALLATION CONT For qualified installers only! Vent Requirements Always maintain the required 1" clearance (air space) to combustible materials to prevent a fire hazard. Do not fill air spaces with insulation. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. -
Page 15: Vent Termination Requirements
.) - TOVE NSTALLATION For qualified installers only! Vent Termination Requirements ¥ Vent termination must have an approved cap (to prevent water from entering) ¥ Vent termination must not be located where it will become plugged by snow or other material ¥... -
Page 16: Installation Preparation
The order of installation is not rigid Ð the qualified installer should follow the procedure best suited for the installation. Items Packed with the Heater Items Packed with the Insert Panel Kit ¥ Avanti Gas Heater (with Faceplate) ¥ Top, Left, and Right Surround Panels ¥ On/Off Switch (with jumper wire attached) ¥... -
Page 17: Switching The Power Cord To The Left Side
.) - NSERT NSTALLATION For qualified installers only! Switching the Power Cord to the Left Side + The power cord may be routed to the left side. To do this, follow the directions below. 1 Remove the strain relief on the right side of the heater (see the illustration below). . 2 Use a 7/16"... -
Page 18: Floor Protection
.) - NSERT NSTALLATION For qualified installers only! Insert Placement (continued) ¥ Insert must be placed so no combustibles are within, or can swing within 36" of the front of the heater (e.g. drapes, doors) ¥ The insert may be placed inside a masonry fireplace or listed zero-clearance (metal) fireplace ¥... - Page 19 .) - NSERT NSTALLATION For qualified installers only! Gas Line Install (continued) Fuel ¥ This heater is designed either for natural gas or for propane (but not for both). Check the sticker on the top of the gas control valve to make sure the correct fuel is used. Gas Inlet Pressure ¥...
-
Page 20: Vent Requirements
.) - NSERT NSTALLATION For qualified installers only! Vent Requirements Always maintain the required 1" clearance (air space) to combustible materials to prevent a fire hazard. Do not fill air spaces with insulation. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. -
Page 21: Surround Panel Installation
.) - NSERT NSTALLATION For qualified installers only! Surround Panel Installation + The surround panels come in the variety of sizes and colors listed below COLOR PANEL SIZE WIDTH HEIGHT PART # Black (Paint) 8" x 10" 40-1/4" 28-3/4" 99300410 Black (Paint) 10"... -
Page 22: Insert Shell Installation
.) - NSERT NSTALLATION For qualified installers only! Surround Panel Installation (continued) 5 Thread the red wires for the on/off switch Upper Right of Trim through the hole in the upper right of the Attach the red wires to the top posts of the on/off panels and trim (thread the wires from the switch. -
Page 23: Finalizing The Installation
INALIZING THE NSTALLATION Steps for Finalizing the Installation Turn the gas control valve to "OFF" prior to conducting any service. 1 Remove the gold door by lifting it off its hangers. Hooks on Side of Heater Bracket (on back side of door) Door The door hangs on a pair of hooks on both sides. -
Page 24: Installing The Logs And Coals
INALIZING THE NSTALLATION CONT 3 Install the log set and ember strip. Rear Log (largest) The rear log has a flat portion that rests on this ledge Front Log The front log has two slots that straddle the clips on both sides (push the log all the way back). -
Page 25: Glass Sealing
INALIZING THE NSTALLATION 4 Slide the glass Cross Section of Glass Attachment back into place and tighten the Glass Clip Attachment Studs glass clip nuts. Face of Heater Make sure the Glass Clip Nuts (use a 5/16" nutdriver gasket remains in to remove) place and is not Make sure the gasket is not... -
Page 26: Check The Draft
INALIZING THE NSTALLATION CONT 7 Check for proper draft. ON STOVES: Vent Collar Draft Hood TO TEST THE DRAFT: Remove the back panel. Start the heater and check the perimeter of the draft hood with a gas detector or smoke. If combustion products leak out the draft hood, the vent may need to be taller to improve draft. -
Page 27: Operating Your Heater
PERATING EATER Before You Begin Read this entire manual before you use your new heater (especially the section "Safety Precautions" on pages 2 & 3). Failure to follow the instructions may result in property damage, bodily injury, or even death. Location of Controls - See explanation below ON/OFF Switch... -
Page 28: Starting The Pilot
PERATING EATER ONTINUED Starting The Pilot Flame The pilot flame is required to ignite the main burners (it also plays a safety role). It should be left on once lit. It will stay lit unless the gas control valve is turned to "OFF". However, the pilot will go out if the gas is shut off or if the heater malfunctions. -
Page 29: Starting The Heater For The First Time
PERATING EATER ONTINUED Starting the Heater for the First Time ¥ Painted Stoves require the paint to be cured. Start the heater and burn on low for 20 minutes. Turn off and let cool. Repeat twice to fully cure the paint. + Fumes and smoke from the paint curing and oil burning off the steel may occur the first time you start your heater. -
Page 30: Adjusting The Blower Speed
PERATING EATER ONTINUED Adjusting the Blower Speed + The blower helps transfer the heat from the heater into the room. It will not turn on until the heater is up to temperature (approximately 10 minutes after starting). See the illustration below for instructions on adjusting the blower speed. -
Page 31: Maintaining Your Heater
AINTAINING EATER Maintaining Your Stove's Appearance The enameled surfaces may chip if struck. Damaged surfaces may be repaired using the enamel touch-up paint available from Travis Industries. Fingerprints or other marks left on the gold surface may become etched in place if they are not wiped clean prior to turning the stove on. -
Page 32: Troubleshooting
ROUBLESHOOTING Problem: Possible Cause: Don't Call for Service Until You: Pilot Will Not Light A gas shut off valve is turned off Check all gas shut off valves See "Starting the Pilot Light" Step C The valve control knob isn't turned to "PILOT" See "Starting the Pilot Light"... -
Page 33: How This Heater Works
ROUBLESHOOTING ONTINUED How this Heater Works This heater is designed with safety as the primary concern. Many of the internal components are for safety purposes. Therefore, only certified gas service technicians should service this heater. What Turns the Main Burners On and Off This heater uses a millivolt system to control its operation (a millivolt is a very small amount of electricity). -
Page 34: Why Nothing Should Be Placed Against The Heater
ROUBLESHOOTING ONTINUED Why Nothing Should Be Placed Against the Heater Your heater has a grill on the sides, bottom, and top that must not be blocked. The grill area around the control cover allows air into the firebox. If it is blocked the combustion inside the firebox will not burn normally. -
Page 35: Warranty
In some states, the exclusion of incidental or consequential damage may not apply. This warranty does not cover any loss or damage incurred by the use or removal of any component or apparatus to or from the AVANTI unit without the express written permission of TRAVIS INDUSTRIES, INC. and bearing a TRAVIS INDUSTRIES, INC. label of approval. -
Page 37: Optional Equipment
PTIONAL QUIPMENT Remote Control (Part # 99300651) Do not connect 110-120 VAC to the gas control valve or wiring system of this unit. 1 The rear panel must be removed and the on/off switch installed prior to installing the remote control (see page 11 for details). -
Page 38: Thermostat
Remove the black grill and replace with the gold grill (Do not pry the grill out Ð this may damage the enamel surface). Avanti Gold Trim (Part # 99200116) 1 Install the stove shell prior to installing the gold trim. -
Page 39: Avanti Lp (Propane) Burner Pan
PTIONAL QUIPMENT ONTINUED Avanti LP (Propane) Burner Pan (Part # 98900736) The LP burner pan should be installed prior to installing the heater. Turn off the gas leading to the heater (if attached). 1 Remove the LP burner pan from the packaging and remove the two screws holding the boxing brackets in place with a 5/16"... - Page 40 PTIONAL QUIPMENT ONTINUED 9 Replace the side glass but do not tighten it in place. Insert the center glass into position and center it. Tighten the center glass clip nuts until the gasket starts to flatten, making sure the gasket remains in place and is not pinched underneath the glass clip (use a 5/16" nutdriver). Slide the side glass towards the center until the edge butts up against the center glass.
-
Page 41: 45° Flue Adapter
PTIONAL QUIPMENT ONTINUED 45° Flue Adapter (Part # 98900118) The 45° flue adapter is designed for insert installations requiring a more flexible flue outlet. 1 Install the flue adapter prior to inserting the insert into the fireplace. 2 Use a phillips-head screwdriver to unscrew the two screws holding the spill switch bracket in place. -
Page 42: Index
NDEX B Vent (insert) .............. 20 Operating the Heater ............ 27 B vent (stove) ............... 14 Paint Curing..............29 Blower Speed ............... 30 Parts List ..............34 BTU Input ..............5 Pedestal (installation) ........... 6 Cap (vent termination - insert)........21 Pilot (starting) ...............
