Page 1: Omniswitch 10K
® OmniSwitch Getting Started Guide 060309-10, Rev. A October 2010... - Page 2 The features and specifications described in this guide are subject to change without notice. Copyright © 2010 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.
-
Page 4: Table Of Contents
Table of Contents OmniSwitch 10K ......1 Installing Chassis Components ....7 Related Documentation . - Page 5 Your First Login Session ....13 Logging In to the Switch ......13 Setting IP Address Information for the EMP .
- Page 6 October 2010...
-
Page 7: Omniswitch 10K
OmniSwitch 10K The Alcatel-Lucent OmniSwitch 10K (OS10K) is a high- capacity, high-performance modular Ethernet LAN switch based on the state-of-the-art Alcatel Operating System (AOS). The OS10K’s class-leading low-power consumption, front-to- back cooling, compact form-factor, and all front-accessible components make it a perfect fit for data center applications, as well as a long-term upgrade for legacy core platforms. -
Page 8: Related Documentation
Related Documentation The following user documentation is provided for the OmniSwitch 10K. • OmniSwitch 10K Getting Started Guide • OmniSwitch AOS Release 7 Network Configuration Guide Describes the procedures for getting an OmniSwitch 10K up and running. Also provides information on... -
Page 9: Installing The Hardware
• Each switch requires one grounded electrical outlet for each power supply installed in the chassis. • Serial cable OmniSwitch 10K switches offer both AC and DC power supply support. Refer to the OmniSwitch 10K Site Preparation Hardware Users Guide for more information. -
Page 10: Unpacking And Installing The Switch
OmniSwitch 10K can weigh up to approximately 200 lbs (90.5 Kgs). Unpack your OmniSwitch 10K chassis as close as possible to the location where it will be installed. Lifting the Chassis Lifting the chassis requires two people. When lifting, use the... -
Page 11: Airflow Considerations
• The chassis has two integral rack-mount flanges that at left and right sides. support standard 19-inch rack mount installations. • Alcatel-Lucent does not provide rack-mount screws. Use the screws supplied by the rack vendor. • To prevent a rack from becoming top heavy, it is recommended that you install the switch at the bottom of the rack whenever possible. -
Page 12: Optional Rack-Mounting Hardware
Optional Rack-Mounting Hardware All OmniSwitch 10K switches are shipped with integral front rack mount flanges. These flanges support standard 19” rack mount installations. If you have non-standard rack mount requirements, contact your Alcatel-Lucent representative for information on optional hardware availability. -
Page 13: Installing Chassis Components
Installing Chassis Components Installing CMM, CFM and NI Modules Before installing modules in the OmniSwitch 10K, locate their slot positions in the chassis. Slot numbers are clearly marked Electrostatic Discharge (ESD) Notice. Be sure to follow proper procedures to eliminate electrostatic discharge on the OmniSwitch 10K front panel. -
Page 14: Installing Transceivers
Installing Transceivers Note. Do not force the module into the slot. If any resistance is encountered, make sure the module is aligned properly in the card guides. For detailed information on installing transceivers, refer to the OmniSwitch AOS Release 7 Transceivers Guide. 2 When the module is nearly seated in the slot, be sure Installing Fan Trays that the two extractor levers—one on top of the module... -
Page 15: Installing Power Supplies
Installing Power Supplies 4 Tighten the captive screw, located at the top-left of the power supply’s front panel. 1 Orient the power supply so that the power cord socket is situated at the right of the power supply. Also, for the 5 Plug the power cord (provided) into the power supply’s power supply to seat properly, make sure that the handle is socket. - Page 16 7 Secure the bracket to the bottom rail of the chassis using the captive screw. The bracket’s prongs should hold the power cord securely in place. 8 Repeat steps 1 though 7 for any additional power supplies being installed. Important. Do not plug any power cords into a power source at this time as this will boot the chassis.
-
Page 17: Connections And Cabling
Serial Connection Default Settings For detailed information on all port types, including console, EMP, Gigabit Ethernet, and 10 Gigabit Ethernet, refer to the 9600 baud rate OmniSwitch 10K Hardware Users Guide. parity none data bits (word size) stop bits For information on modifying these settings, refer to the OmniSwitch AOS Release 7 Switch Management Guide. -
Page 18: Booting The Switch
Customer Support. For information on fan tray LED states, a successful boot, the LEDs on all switch components, refer to the OmniSwitch 10K Hardware Users Guide. including power supplies, should display as follows: Once the switch has completely booted and you have accessed... -
Page 19: Your First Login Session
Important. You must be connected to the switch via the Copyright (c) 1994-2010 Alcatel-Lucent. All console port before initiating your first login session. Rights Reserved. OmniSwitch(tm) is a trademark of Alcatel-Lucent, registered in the United States Patent and Trademark Office. ->... -
Page 20: Setting Ip Address Information For The Emp
More Information On User Accounts. A user account To change the default IP and gateway addresses, use the includes a login name, password, and user privileges. ip interface command. For example: Privileges determine whether the user has read or write ->... -
Page 21: Unlocking Session Types
Unlocking Session Types Unlocking Specified Session Types Security is a key feature on OmniSwitch 10K switches. As You can also unlock session types on a one-by-one basis. For described on page 13, when you access the switch for the first example, to unlock Telnet sessions only, enter the following time, you must use a direct console port connection. -
Page 22: Changing The Login Password
Setting the Date and Time Note. Be sure to remember or securely record all new passwords; overriding configured passwords on OmniSwitch 10K switches is restricted. Set the current time for the switch by entering system time, followed by the current time in hh:mm:ss. -
Page 23: Setting Optional Parameters
Setting Optional Parameters Viewing Your Changes To view your current changes, enter show system at the CLI Specifying an Administrative Contact prompt. An administrative contact is the person or department in Saving Your Changes charge of the switch. If a contact is specified, users can easily find the appropriate network administrator if they have questions or comments about the switch. -
Page 24: Using Webview
Using WebView Navigating WebView OmniSwitch 10K switches can be configured and monitored using WebView, Alcatel-Lucent’s web-based device management tool. After you have successfully logged in, the Chassis Management home page displays. Logging In to WebView Note. Before attempting to establish a WebView session, be sure that you have first unlocked the HTTP session type using the aaa authentication command. -
Page 25: Troubleshooting Webview
Troubleshooting WebView The WebView login screen does not display. This suggests either a physical or network connection issue. Try the following options: • Be sure that there is a good physical Ethernet cable connection to the Ethernet port used for managing the switch (EMP or NI port). - Page 26 Using WebView October 2010...
- Page 27 October 2010 Using WebView...
- Page 28 Using WebView October 2010...
