Hitachi C 9SA2 Technical And Service Manual page 23

PARTS
ITEM
CODE NO.
NO.
44 947-859 LOCK SPRING
45 302-469
SLOTTED HD. SET SCREW (SEAL LOCK) M6X6
46 326-805 BASE ASS'Y
47 317-333 MACHINE SCREW (W/SP. WASHER) M4X6
48 324-659 GUIDE PIECE
49 302-457 BOLT (SQUARE) M8X30
50 308-481 BEVEL PLATE
51 308-482 RIVET D6X24
52 308-480 RIVET D6X17
53 303-800 DIAGONAL BOLT M8
54 949-425 WASHER M6 (10 PCS.)
55 302-438 WING BOLT (A) M6X20
56 938-477 HEX. SOCKET SET SCREW M5X8
57 983-362 BRUSH HOLDER
58 999-038 CARBON BRUSH (1 PAIR)
59 961-781 BRUSH CAP
60 303-796
MACHINE SCREW (W/WASHERS) M5X40 (BLACK)
61 301-653
TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
62 NAME PLATE
* 63 325-363 HOUSING ASS'Y
* 63 325-362 HOUSING ASS'Y
* 64 325-358 SAFETY LOCK BUTTON
* 65 325-359 SPRING
66 325-357 SWITCH (1P SCREW TYPE)
67 305-720 TAPPING SCREW (W/FLANGE) D4X12
68 946-362 BEARING LOCK
69 325-351 HANDLE COVER
* 70 980-063 TERMINAL
71 938-307 PILLAR TERMINAL
* 72 980-063 TERMINAL
* 72 930-804 TERMINAL M4.0 (10 PCS.)
73 937-631 CORD CLIP
74 984-750 TAPPING SCREW (W/FLANGE) D4X16
* 75 930-039 NOISE SUPPRESSOR
* 76 958-049 CORD ARMOR D8.2
* 76 940-778 CORD ARMOR D10.7
* 77 500-234Z CORD
* 77 500-423Z CORD
* 77 500-439Z CORD
* 77 500-447Z CORD
* 77 500-461Z CORD
* 77 500-474Z CORD
* 77 500-214Z CORD
11 -- 06
DESCRIPTION
* ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
1 INCLUD. 41, 42, 47-52, 54, 55
1
1
1
1
1
1
1
1
1
2
2
2
2
3
5
1
1 INCLUD. 56, 57
1 INCLUD. 56, 57 FOR AUS, NZL
1 FOR AUS, NZL
1 FOR AUS, NZL
1
1
1
1
1 FOR AUS, NZL, TPE
1
1 FOR CORD
1 FOR CORD FOR TPE
1
2
1 FOR AUS, NZL, TPE
1
1
1 (CORD ARMOR D8.2)
1 (CORD ARMOR D8.2) FOR SIN, KUW
1 (CORD ARMOR D8.2) FOR AUS, NZL
1 (CORD ARMOR D8.2) FOR SYR
1 (CORD ARMOR D8.2) FOR HKG
1 (CORD ARMOR D10.7) FOR TPE
1 (CORD ARMOR D10.7) FOR VEN
C 9BA2
--- 3 -- -
