Hitachi C 9SA2 Technical And Service Manual page 19

PARTS
ITEM
CODE NO.
NO.
43 947-859 LOCK SPRING
44 302-469
SLOTTED HD. SET SCREW (SEAL LOCK) M6X6
45 326-804 BASE ASS'Y
46 317-333 MACHINE SCREW (W/SP. WASHER) M4X6
47 324-659 GUIDE PIECE
48 302-457 BOLT (SQUARE) M8X30
49 308-481 BEVEL PLATE
50 308-482 RIVET D6X24
51 308-480 RIVET D6X17
52 303-800 DIAGONAL BOLT M8
53 949-425 WASHER M6 (10 PCS.)
54 302-438 WING BOLT (A) M6X20
55 938-477 HEX. SOCKET SET SCREW M5X8
56 983-362 BRUSH HOLDER
57 999-038 CARBON BRUSH (1 PAIR)
58 961-781 BRUSH CAP
59 303-796
MACHINE SCREW (W/WASHERS) M5X40 (BLACK)
60 301-653
TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
61 NAME PLATE
* 62 325-363 HOUSING ASS'Y
* 62 325-362 HOUSING ASS'Y
* 63 325-358 SAFETY LOCK BUTTON
* 64 325-359 SPRING
65 325-357 SWITCH (1P SCREW TYPE)
66 305-720 TAPPING SCREW (W/FLANGE) D4X12
67 946-362 BEARING LOCK
68 325-351 HANDLE COVER
* 69 980-063 TERMINAL
70 938-307 PILLAR TERMINAL
* 71 980-063 TERMINAL
* 71 930-804 TERMINAL M4.0 (10 PCS.)
72 937-631 CORD CLIP
73 984-750 TAPPING SCREW (W/FLANGE) D4X16
* 74 930-039 NOISE SUPPRESSOR
* 75 958-049 CORD ARMOR D8.2
* 75 940-778 CORD ARMOR D10.7
* 76 500-234Z CORD
* 76 500-423Z CORD
* 76 500-439Z CORD
* 76 500-447Z CORD
* 76 500-435Z CORD
* 76 500-474Z CORD
* 76 500-455Z CORD
* 76 500-214Z CORD
11 -- 06
DESCRIPTION
* ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
1 INCLUD. 40, 41, 46-51, 53, 54
1
1
1
1
1
1
1
1
1
2
2
2
2
3
5
1
1 INCLUD. 55, 56
1 INCLUD. 55, 56 FOR AUS, NZL
1 FOR AUS, NZL
1 FOR AUS, NZL
1
1
1
1
1 FOR AUS, NZL, TPE, KOR
1
1 FOR CORD
1 FOR CORD FOR TPE
1
2
1 FOR AUS, NZL, TPE, KOR
1
1
1 (CORD ARMOR D8.2)
1 (CORD ARMOR D8.2) FOR SIN, KUW
1 (CORD ARMOR D8.2) FOR AUS, NZL
1 (CORD ARMOR D8.2) FOR SYR
1 (CORD ARMOR D8.2) FOR HKG
1 (CORD ARMOR D10.7) FOR TPE
1 (CORD ARMOR D8.2) FOR THA
1 (CORD ARMOR D10.7) FOR VEN
C 9SA2
--- 3 -- -
