Hitachi C 9SA2 Technical And Service Manual page 22

PARTS
ITEM
CODE NO.
NO.
1 673-002 NEEDLE BEARING (HK1212)
2 303-789 SPINDLE AND GEAR SET
3 303-790 BEARING HOLDER
4 303-797 SEAL LOCK FLAT HD. SCREW M6X14
5 998-887 LINER
6 620-3VV BALL BEARING 6203VVCMPS2L
7 326-803 SAFETY COVER
8 303-906 RETURN SPRING
9 303-804 BEARING COVER
10 992-013 SEAL LOCK FLAT HD. SCREW M5X14
* 11 326-802 WASHER (A)
* 11 303-365 WASHER (A)
* 12 326-830 TCT SAW BLADE 235MM-D25.4 HOLE-NT40
* 12 326-829 TCT SAW BLADE 235MM-D25 HOLE-NT40
13 325-354 SAW COVER
14 HITACHI LABEL
15 NAME PLATE (BRAKE)
16 324-139 SPECIAL BOLT
17 302-464 KNOB
18 304-043
MACHINE SCREW (W/WASHERS) M4X10 (BLACK)
19 302-423 WASHER (B)
20 324-662 HEX. SOCKET HD. BOLT M8X15.5
21 305-691
MACHINE SCREW (W/WASHERS) M4X14 (BLACK)
22 937-623 BRUSH TERMINAL
* 23 340-692C STATOR ASS'Y 110V
* 23 340-661C STATOR ASS'Y 110V
* 23 340-692E STATOR ASS'Y 220V-230V
* 23 340-692F STATOR ASS'Y 240V
* 23 340-661F STATOR ASS'Y 240V
24 325-352 FAN GUIDE
* 25 360-778C ARMATURE 110V
* 25 360-778E ARMATURE 230V
* 25 360-778F ARMATURE 240V
26 303-793 LOCK LEVER
27 949-884 ROLL PIN D8X50 (10 PCS.)
28 325-350 GEAR COVER
29 961-729 CUSHION
30 949-794 FLAT HD. SCREW M6X20 (10 PCS.)
31 325-356 RUBBER BUSHING
32 325-355 BEARING BUSHING
33 600-0VV BALL BEARING 6000VVCMPS2L
34 960-251 HEX. HD. TAPPING SCREW D5X65
35 620-2VV BALL BEARING 6202VVCMPS2L
36 303-792 RUBBER RING
37 324-660 KNOB
38 676-531 O-RING (P-7)
39 303-801 SLEEVE
40 961-436 WASHER (B)
41 324-658 WING NUT M8
42 949-433 BOLT WASHER M8 (10 PCS.)
43 301-806 WING BOLT M6X15
--- 2 ---
DESCRIPTION
* ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
1
2
1
1
1
1
1
2
1
1 FOR AUS, NZL
1
1 FOR AUS, NZL
1
1
1
1
1
1
1
1
4
1
1 INCLUD. 22
1 INCLUD. 22 FOR TPE
1 INCLUD. 22
1 INCLUD. 22
1 INCLUD. 22 FOR AUS, NZL
1
1
1
1
1
1
1 INCLUD. 1, 29, 30, 36
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
C 9BA2
11 -- 06
