Remote control

Remote control operation
1. Operation mode: Cold, Heat (Only
for the models with cold/heat), DRY,
FAN, and AUTO (Automatic).
2. Timer 24 hrs.
3. Internal temperature range selection:
17º - 30º.
4. LCD
5. Night light operation mode.
ESPECIFICACIONES DEL CONTROL REMOTO
Rated voltage
Lowest of voltage of CPU emiting signal
Transmission distance
Environment
* With 3 V, reaches 11m
Attention
1. The air conditioner will not operate when curtains, doors our other materials
block the signals between the remote control and the indoor unit.
2. Avoid spilling any liquid in the remote control. Do not expose to sunlight or any
heat source.
3. If the infrared signal receiver in the indoor unit is exposed to sunlight, the air
conditioner unit might not work properly. Use curtains or shades to avoid
having sunlight directly to the receiver.
4. If other electrical equipment react to the signals sent by the remote control,
change the position or consult with you local sales department.
Remote control battery To use the remote control, it is necessary to install
two (R03/Ir03x2) alkaline AAA batteries.
Remote control
33
When should the batteries be
replaced
1. When there is not a "beep"
anymore from the indoor unit
when using the control remote or
the signal light indicator does not
lit.
2. The indoor unit does not respond
to the remote control commands to
activate the programs.
To replace batteries
1. Slide out the battery
compartment cover ( located in
the back part of the remote
control).
3 V
2. Install the two AAA batteries in
the compartment (indicated in the
2,4 V
drawing located inside the
8 m*
compartment).
-5ºC ~ 60ºC
3. Slide in the cover.
4. If the remote control is not
operated for long period of times,
batteries should be discarded.
Remote control instructions
1. The signal reach distance of the
remote control to the receiver that
is inside the main unit of the air
conditioner is 8 meters. Any
obstruction placed between the
receiver and the remote control
can cause interference, limiting
the capacity of the programming.
2. Any time that a button is pressed
in the remote control, the air
conditioner emits a "beep" that
indicates that a command has
been received and transmitted in
the indoor unit.
3. When selecting the function of
timer, the remote control sends
(automatically) a signal to the indoor
unit at the specific moment. If the
control remote is left in a position
that the signal is blocked, a 15
minute delay can be produced.
Attention
1. When replacing batteries, do not
use old batteries or a different
type battery. This may cause the
remote control to malfunction.
2. If you do not use the remote
controller for several weeks
remove the batteries. Otherwise
battery leakage may damage the
remote controller.
3. The average battery life under
normal use is about 6 months.
4. Replace the batteries when there
is no answering beep from the
indoor unit or if the Transmission
Indicator light fails to light.
Remote control
