Replacement Parts List - Zenith Z52SZ80 Service Manual

For Capacitor & Resistors, the CC, CX, CK, CN : Ceramic
charactors at 2nd and 3rd digit CQ : Polyestor
in the P/No. means as follows; CE : Electrolytic
LOCA. NO PART NO
0IMCRSH003A
IC1
IC1 0IPRPTO002A
IC100 0IMCRSS016A
IC100 0IPMGON013B
0IMI623200B
IC1000
IC1001 0IMI623200B
IC101 0IMCRKE006A
IC102 0IKE780900M
0IMMRHY001F
IC103
0IMMRHY001F
IC104
IC105 0IMCRTI028B
IC105 0IMCRKE005A
IC106 0IPH741400E
0IAL242561B
IC107
IC109 0IMCRPH026B
IC110 0IFA752700A
IC110 0IPRP00009A
0IMMRSS037E
IC1102
IC1103 0ICTM00021A
IC111 0IMCRNL001A
IC1200 0IPMGKE030A
0IMCRSO025A
IC1201
0IPH827150A
IC1204
IC1601 0IPRPS5006A
IC1602 0IMMRAL014B
IC1603 0IMMRAL014B
0IMCRSH003A
IC2
IC2 0IMCRKE019A
IC200 0ICTMLG009C
IC200 0ISO206900A
0IMMR00100A
IC202
IC203 0IMMR00100A
IC3 0IMCRKE018A
IC300 0ILNRMN005A
0IPRPM3002B
IC301
0IMCRXL004A
IC314
IC315 0ICTMLG013A
IC316 0IMCRCY002A
IC319 0IPRPFA015A
0IFA754207A
IC4
IC400 0IMCRSJ001A
IC401 0IMCRAG001A
IC402 0IPMGON013B
0IPRP00539A
IC403
IC404 0ILNR00038A
IC404 0IMCRKE006A

REPLACEMENT PARTS LIST

RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
DESCRIPTION
IC
GP2S40 4P DIP ST PHOTOINTERRUPTER
TC7S14F(T5L,T) 5P SCHMITT INVERTER
S3C44BOX01-EDRO LQFP-160 TRAY CPU
MC34063ADR2G SO-8P R
M62320FP 16P
M62320FP 16P
KIA278R05PI TO220IS,4P ST 2A
KIA7809API TO220 ST 3P 9V
HY57V641620HGT-H 54P
HY57V641620HGT-H 54P
TAS5112DFDR TSSOP 56P
KIA7029AP KEC TO-92, 3P TP 2.9V
74HC14D 14SOP TP SHITTER TRIGGER
AT24C256W-10SI-2.7V 8P
PA9516APW PHILIPS 16P
KA75270Z 3 TP RE-SET IC
ICL3232CBNZ 16P/SOP R/TP RS232
K4S643232H-TC60 86P
2505962-1003 8P
NSP-6241B 64P
KIA78R05F 5PIN DPAK R/TP 1A,5V
CXA2181Q 48P VIDEO SYNC SELECTOR
P82B715T 8SOP R/TP IIC EXTENDER
SIL9021CTU(PB FREE) 144P
AT24C02N-10SI-2.7 8P
AT24C02N-10SI-2.7 8P
GP2S40 SHARP 4P
KIA78R33API 4P TO220 ST 3.3V
LGDT1102C HD2.3 LG IC SBGA-432P
CXA2069Q QFP64 BK I2C BUS AV S/W
EM638325TS-6G 86PIN TSOP2
EM638325TS-6G 86PIN TSOP2
KIA78R05API 4P TO220 ST 5V 1A
VPX3226E 44 VIDEO PIXEL DECODER
MST9883C-110 80P
XC95288XL-10TQG144C 144P
LGDT1901A LG IC 24P
CY2309SXC-1HT 16P R/TP 3.3V
FMS6410CSX-NL(PB-FREE) 8P
KA75420ZTA 3P,TO-92 TP 4.2V
SC1565IST-1.8 3P SOT223
A8904SLP 28P/HTSSOP
MC34063ADR2G SO-8P
DAC0800LCM 16PIN R/TP 8BIT DAC
TCA0372DM2ELG 16P
KIA278R05PI TO220IS,4P ST 2A
LOCA. NO PART NO
IC406 0IMCRTH002A
IC409 0IMCRKE003B
IC412 0ILNRON009B
IC413 0IPMGKE031A
0IMCRAL006A
IC5
IC500 0ICB841500B
IC500 0IMCRTH003A
IC501 0ICTM00019A
0IZZVG0001A
IC502
IC503 0IPMGSG018C
IC503 0ITO741570C
IC504 0IMCRSG007A
IC504 0IMCRFA014A
IC511 0IMCRSG008B
IC511 0ISTLON023B
IC511 0IMCRSG008A
IC600 0IMCRMN012A
0ISS455880A
IC601
IC602 0IFA754207A
IC606 0IMCRSJ001A
IC607 0ICTMLG019A
0IMCRTI011B
IC700
IC701 0IMMRAL015C
IC701 0IPMGKE019B
IC702 0IMCRFA003A
IC702 0IMCRKE006B
IC703 0IPMGKE045A
IC704 0IMCRKE006A
IC705 0IMCRAL006A
IC706 0IPMG00038A
0IMCRKE003B
IC707
IC708 0IMCRKE006B
IC709 0IPMGKE045A
IC710 0IMCRKE006A
0IMCRKE006B
IC711
IC800 0IMMRSS053B
IC801 0IMCRTI014A
IC801 0IMCRNE045A
0IPMGSK015B
IC801
IC802 0ISS416162D
IC802 0IMCRSG007A
IC803 0IPMGSG018C
IC803 0IMCRSG008A
0IPRPFA015A
IC804
IC804 0IMCRSG008A
IC805 0IMCRMX001A
IC806 0IMCRSG008B
0IMCRMX001A
IC807
- 22 -
RUN DATE : 2005.5.13
DESCRIPTION
THC63LVD103 64P
KIA78R12API 4P TO-220IS ST 12V/1A
NL17SZ08DFT2G SOT-353/5PIN
KIA78R33F 5PIN DPAK R/TP 1A,3.3V
AT24C16AN-10SI-2.7 ATMEL 8P
CS8415A-CZR 28P 96KHZ DIGITAL AUDIO
THC63LVD104A 64P
2505999-0002 324P
X1272-6403 203PIN DMD HD4 720P 0.55 INCH
LD1086DT15TR 2P DPAK R/TP 1.5V
TC74LCX157FT 16P
74VIT125CTR 5P S0T323-5L
74F04SCX 14P
74LX1G07CTR 5P SOT323-5L
NL17SZ126DFT2G 5P SC70-5
74LX1G14CTR 5P SOT323-5L
MSP4450G QA B8 80P
KA4558D 8SOP OP AMP
KA75420ZTA 3P,TO-92 TP 4.2V
SC1565IST-1.8 3P SOT223
LGDT3303 LG IC 100P
2504886-0002(DDP1011) 529P
AT49BV8192A-90TI 48P
KIA378R33PI KEC 4P TO-220F ST 3.3V
KA2903 FAIRCHILD 8SOP
KIA278R33PI TO-220IS 4P ST 3.3V
KIA278R25PI 2.5V 2A TO220IS 4P
KIA278R05PI TO220IS,4P ST 2A
AT24C16AN-10SI-2.7 8P
KIA378R00PI TO-220 3PIN
KIA78R12API 4P TO-220IS ST 12V/1A
KIA278R33PI TO-220IS 4P ST 3.3V
KIA278R25PI 2.5V 2A TO220IS 4P
KIA278R05PI TO220IS,4P ST 2A
KIA278R33PI TO-220IS 4P ST 3.3V
K4R271669F-TCS8 54P
CDCR83 24P
UPD64011AGM-8ED-A 160P
STR-X6756 7PIN TO3PF-7L
K4S161622H-UC80 50P
74VIT125CTR 5P S0T323-5L
LD1086DT15TR 2P DPAK R/TP 1.5V
74LX1G14CTR 5P SOT323-5L
FMS6410CSX-NL 8P
74LX1G14CTR 5P SOT323-5L
MAX708SCSA MAXIM 8P
74LX1G07CTR 5P SOT323-5L
MAX708SCSA MAXIM 8P
