Zenith Z52SZ80 Service Manual page 24

LOCA. NO PART NO
D717 0DD184009AA KDS184 TP KEC - 85V 300MA
D801 0DRSD00050B D25XB60-4000 600V 25A 350A
0DR010009AA EG01C 1000V 0.5A 10A
D802
D803 0DD100009AM EU1ZV(1) 200V 0.25A 15A
D805 0DD100009AM EU1ZV(1) 200V 0.25A 15A
D806 0DD100009AM EU1ZV(1) 200V 0.25A 15A
FMB-36M FM80 18W 0.62V
D831 0DR360000BA
D835 0DD414809ED 1N4148 TP GRANDE
D871 0DRSD00091A SF20JC10 FTO220(4115) 100V
D881 0DD120000BB FML-G12S SANKEN
FML-24S TO220 400V 10A
D891 0DR240000BA
D909 0DRGS00328A SS26 DO-214AC 60V 2A
D910 0DRGS00328A SS26 DO-214AC 60V 2A
D912 0DRON00088A BAT54SWT1 60V 3A 4A .SEC .A
D913 0DRON00088A BAT54SWT1 60V 3A 4A .SEC .A
0DRON00088A BAT54SWT1 60V 3A 4A .SEC .A
D914
D915 0DRON00088A BAT54SWT1 60V 3A 4A .SEC .A
LED600 0DL233309AC LED,SAM2333
ZD01 0DR050008AA SD05.TC SOD323 5V 5A 15A
ZENERS,MTZJ6.2B
ZD1 0DZ620009BB
ZD10 0DZ620009BB ZENERS,MTZJ6.2B
ZD100 0DRSE00038A SDC15 TVS SOT23 12.8V
ZD101 0DRSE00038A SDC15 TVS SOT23 12.8V
ZENERS,MTZJ6.2B
ZD2 0DZ620009BB
0DZPT56009A ZENERS,UZ-5.6BSB
ZD201
ZD202 0DZPT56009A ZENERS,UZ-5.6BSB
ZD203 0DZPT56009A ZENERS,UZ-5.6BSB
ZD204 0DZPT56009A ZENERS,UZ-5.6BSB
0DZ620009BB ZENERS,MTZJ6.2B
ZD3
ZD4 0DZ620009BB ZENERS,MTZJ6.2B
ZD5 0DZ620009BB ZENERS,MTZJ6.2B
ZD6 0DZ620009BB ZENERS,MTZJ6.2B
ZENERS,UZ-5.6BSB
ZD600 0DZPT56009A
ZD601 0DZPT56009A ZENERS,UZ-5.6BSB
ZD802 0DZ200009AF ZENERS,MTZJ22B
ZD9 0DZ620009BB ZENERS,MTZJ6.2B
CAPACITOR
C1 0CE476DF618 47UF STD 16V M
C1 0CE226DF618 22UF STD 16V M
C10 0CE107DF618 100UF STD 16V M
0CE476DD618 47UF STD 10V 20%
C108
C109 0CE476DD618 47UF STD 10V 20%
C110 0CE476DK618 47UF STD 50V M
C1100 0CE335SK6DC 3.3UF MVG 50V 20%
10UF MVG 16V 20%
C1101 0CE106SF6DC
C1102 0CK104CF56A 0.1UF 1608 16V 10%
C1103 0CK104CF56A 0.1UF 1608 16V 10%
C1104 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1105 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1106
REPLACEMENT PARTS LIST
DESCRIPTION
- 24 -
LOCA. NO PART NO
C1107 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1108 0CK104CF56A
0CE106SF6DC 10UF MVG 16V 20%
C1109
C111 0CE476DD618 47UF STD 10V 20%
C1110 0CE106SF6DC 10UF MVG 16V 20%
C1111 0CK103CK56A 0.01UF 1608 50V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C1112
C1113 0CK104CF56A 0.1UF 1608 16V 10%
C1114 0CK103CK56A 0.01UF 1608 50V 10%
C1115 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1116 0CK104CF56A
C112 0CE107DF618 100UF STD 16V M
C1120 0CE106SF6DC 10UF MVG 16V 20%
C1121 0CE106SF6DC 10UF MVG 16V 20%
0.1UF 1608 16V 10%
C1122 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1123
C1124 0CK104CF56A 0.1UF 1608 16V 10%
C1125 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1126 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1127
C1128 0CK104CF56A 0.1UF 1608 16V 10%
C1129 0CK104CF56A 0.1UF 1608 16V 10%
C113 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1130 0CK104CF56A
C1131 0CK104CF56A 0.1UF 1608 16V 10%
C1132 0CK104CF56A 0.1UF 1608 16V 10%
C1133 0CK104CF56A 0.1UF 1608 16V 10%
0.01UF 1608 50V 10%
C1134 0CK103CK56A
0CK103CK56A 0.01UF 1608 50V 10%
C1135
C1136 0CK103CK56A 0.01UF 1608 50V 10%
C1137 0CK103CK56A 0.01UF 1608 50V 10%
10UF MVG 16V 20%
C1138 0CE106SF6DC
0CE106SF6DC 10UF MVG 16V 20%
C1139
C114 0CK104CF56A 0.1UF 1608 16V 10%
C1140 0CE226SF6DC 22UF MVG 16V 20%
C1141 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1142 0CK104CF56A
C1143 0CK104CF56A 0.1UF 1608 16V 10%
C1144 0CK104CF56A 0.1UF 1608 16V 10%
C1145 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1146 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1147
C1148 0CK104CF56A 0.1UF 1608 16V 10%
C1149 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1150 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1151
C1152 0CK104CF56A 0.1UF 1608 16V 10%
C1153 0CK104CF56A 0.1UF 1608 16V 10%
C1154 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1155 0CK104CF56A
C1156 0CK104CF56A 0.1UF 1608 16V 10%
DESCRIPTION
