Replacement Parts List - Zenith Z52SZ80 Service Manual

For Capacitor & Resistors, the CC, CX, CK, CN : Ceramic
charactors at 2nd and 3rd digit CQ : Polyestor
in the P/No. means as follows; CE : Electrolytic
LOCA. NO PART NO
IC1 0IMCRSH003A GP2S40 4P DIP ST PHOTOINTERRUPTER
IC1 0IPRPTO002A TC7S14F(T5L,T) 5P SCHMITT INVERTER
IC100 0IMCRSS016A S3C44BOX01-EDRO LQFP-160 TRAY CPU
0IPMGON013B MC34063ADR2G SO-8P R
IC100
IC1000 0IMI623200B M62320FP 16P
0IMI623200B M62320FP 16P
IC1001
IC101 0IMCRKE006A KIA278R05PI TO220IS,4P ST 2A
IC102 0IKE780900M KIA7809API TO220 ST 3P 9V
IC103 0IMMRHY001F HY57V641620HGT-H 54P
IC104 0IMMRHY001F HY57V641620HGT-H 54P
0IMCRTI028B TAS5112DFDR TSSOP 56P
IC105
IC105 0IMCRKE005A KIA7029AP KEC TO-92, 3P TP 2.9V
0IPH741400E 74HC14D 14SOP TP SHITTER TRIGGER
IC106
IC107 0IAL242561B AT24C256W-10SI-2.7V 8P
0IMCRPH026B PA9516APW PHILIPS 16P
IC109
IC110 0IFA752700A KA75270Z 3 TP RE-SET IC
IC110 0IPRP00009A ICL3232CBNZ 16P/SOP R/TP RS232
IC1102 0IMMRSS037E K4S643232H-TC60 86P
IC1103 0ICTM00021A 2505962-1003 8P
0IMCRNL001A NSP-6241B 64P
IC111
IC1200 0IPMGKE030A KIA78R05F 5PIN DPAK R/TP 1A,5V
0IMCRSO025A CXA2181Q 48P VIDEO SYNC SELECTOR
IC1201
IC1204 0IPH827150A P82B715T 8SOP R/TP IIC EXTENDER
0IPRPS5006A SIL9021CTU(PB FREE) 144P
IC1601
IC1602 0IMMRAL014B AT24C02N-10SI-2.7 8P
IC1603 0IMMRAL014B AT24C02N-10SI-2.7 8P
IC2 0IMCRSH003A GP2S40 SHARP 4P
IC2 0IMCRKE019A KIA78R33API 4P TO220 ST 3.3V
0ICTMLG009C LGDT1102C HD2.3 LG IC SBGA-432P
IC200
IC200 0ISO206900A CXA2069Q QFP64 BK I2C BUS AV S/W
0IMMR00100A EM638325TS-6G 86PIN TSOP2
IC202
IC203 0IMMR00100A EM638325TS-6G 86PIN TSOP2
0IMCRKE018A KIA78R05API 4P TO220 ST 5V 1A
IC3
IC300 0ILNRMN005A VPX3226E 44 VIDEO PIXEL DECODER
IC301 0IPRPM3002B MST9883C-110 80P
IC314 0IMCRXL004A XC95288XL-10TQG144C 144P
IC315 0ICTMLG013A LGDT1901A LG IC 24P
0IMCRCY002A CY2309SXC-1HT 16P R/TP 3.3V
IC316
IC319 0IPRPFA015A FMS6410CSX-NL(PB-FREE) 8P
0IFA754207A KA75420ZTA 3P,TO-92 TP 4.2V
IC4
IC400 0IMCRSJ001A SC1565IST-1.8 3P SOT223
IC401 0IMCRAG001A A8904SLP 28P/HTSSOP
IC402 0IPMGON013B MC34063ADR2G SO-8P
IC403 0IPRP00539A DAC0800LCM 16PIN R/TP 8BIT DAC
0ILNR00038A TCA0372DM2ELG 16P
IC404
IC404 0IMCRKE006A KIA278R05PI TO220IS,4P ST 2A

REPLACEMENT PARTS LIST

RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RF : Fusible
DESCRIPTION
IC
LOCA. NO PART NO
IC406 0IMCRTH002A
IC409 0IMCRKE003B
0ILNRON009B
IC412
IC413 0IPMGKE031A
0IMCRAL006A
IC5
IC500 0ICB841500B
IC500 0IMCRTH003A
IC501 0ICTM00019A
IC502 0IZZVG0001A
IC503 0IPMGSG018C
IC503 0ITO741570C
0IMCRSG007A
IC504
IC504 0IMCRFA014A
0IMCRSG008B
IC511
IC511 0ISTLON023B
IC511 0IMCRSG008A
IC600 0IMCRMN012A
IC601 0ISS455880A
IC602 0IFA754207A
IC606 0IMCRSJ001A
0ICTMLG019A
IC607
IC700 0IMCRTI011B
IC701 0IMMRAL015C
IC701 0IPMGKE019B
IC702 0IMCRFA003A
IC702 0IMCRKE006B
IC703 0IPMGKE045A
IC704 0IMCRKE006A
IC705 0IMCRAL006A
0IPMG00038A
IC706
IC707 0IMCRKE003B
IC708 0IMCRKE006B
IC709 0IPMGKE045A
IC710 0IMCRKE006A
IC711 0IMCRKE006B
IC800 0IMMRSS053B
0IMCRTI014A
IC801
IC801 0IMCRNE045A
0IPMGSK015B
IC801
IC802 0ISS416162D
IC802 0IMCRSG007A
IC803 0IPMGSG018C
IC803 0IMCRSG008A
IC804 0IPRPFA015A
IC804 0IMCRSG008A
0IMCRMX001A
IC805
IC806 0IMCRSG008B
IC807 0IMCRMX001A
- 22 -
RUN DATE : 2005.5.13
DESCRIPTION
THC63LVD103 64P
KIA78R12API 4P TO-220IS ST 12V/1A
NL17SZ08DFT2G SOT-353/5PIN
KIA78R33F 5PIN DPAK R/TP 1A,3.3V
AT24C16AN-10SI-2.7 ATMEL 8P
CS8415A-CZR 28P 96KHZ DIGITAL AUDIO
THC63LVD104A 64P
2505999-0002 324P
X1272-6403 203PIN DMD HD4 720P 0.55 INCH
LD1086DT15TR 2P DPAK R/TP 1.5V
TC74LCX157FT 16P
74VIT125CTR 5P S0T323-5L
74F04SCX 14P
74LX1G07CTR 5P SOT323-5L
NL17SZ126DFT2G 5P SC70-5
74LX1G14CTR 5P SOT323-5L
MSP4450G QA B8 80P
KA4558D 8SOP OP AMP
KA75420ZTA 3P,TO-92 TP 4.2V
SC1565IST-1.8 3P SOT223
LGDT3303 LG IC 100P
2504886-0002(DDP1011) 529P
AT49BV8192A-90TI 48P
KIA378R33PI KEC 4P TO-220F ST 3.3V
KA2903 FAIRCHILD 8SOP
KIA278R33PI TO-220IS 4P ST 3.3V
KIA278R25PI 2.5V 2A TO220IS 4P
KIA278R05PI TO220IS,4P ST 2A
AT24C16AN-10SI-2.7 8P
KIA378R00PI TO-220 3PIN
KIA78R12API 4P TO-220IS ST 12V/1A
KIA278R33PI TO-220IS 4P ST 3.3V
KIA278R25PI 2.5V 2A TO220IS 4P
KIA278R05PI TO220IS,4P ST 2A
KIA278R33PI TO-220IS 4P ST 3.3V
K4R271669F-TCS8 54P
CDCR83 24P
UPD64011AGM-8ED-A 160P
STR-X6756 7PIN TO3PF-7L
K4S161622H-UC80 50P
74VIT125CTR 5P S0T323-5L
LD1086DT15TR 2P DPAK R/TP 1.5V
74LX1G14CTR 5P SOT323-5L
FMS6410CSX-NL 8P
74LX1G14CTR 5P SOT323-5L
MAX708SCSA MAXIM 8P
74LX1G07CTR 5P SOT323-5L
MAX708SCSA MAXIM 8P
