Zenith Z52SZ80 Service Manual page 26

LOCA. NO PART NO
C1690 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1691 0CK104CF56A
0CK104CF56A 0.1UF 1608 16V 10%
C1692
C1693 0CK104CF56A 0.1UF 1608 16V 10%
C1696 0CK104CF56A 0.1UF 1608 16V 10%
C1697 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C1698
C172 0CK105DF64A 1UF 2012 16V 20%
C1800 0CK104CF56A 0.1UF 1608 16V 10%
C1801 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C1802 0CK104CF56A
C1918 0CE476SF6DC 47UF MVG 16V 20%
C1919 0CE476SF6DC 47UF MVG 16V 20%
C1921 0CE476SF6DC 47UF MVG 16V 20%
47UF MVG 16V 20%
C1922 0CE476SF6DC
0CK103CK56A 0.01UF 1608 50V 10%
C1924
C1925 0CE106SF6DC 10UF MVG 16V 20%
C2 0CN1030F679 10000PF D 16V 20% X5R
100UF STD 25V M
C20 0CE107DH618
0CK105DF64A 1UF 2012 16V 20%
C200
C201 0CK105DF64A 1UF 2012 16V 20%
C203 0CK105DF64A 1UF 2012 16V 20%
C204 0CK105DF64A 1UF 2012 16V 20%
1UF 2012 16V 20%
C205 0CK105DF64A
C206 0CE226SF6DC 22UF MVG 16V 20%
C207 0CK105DF64A 1UF 2012 16V 20%
C207 0CE106DF618 10UF STD 16V M
1UF 2012 16V 20%
C208 0CK105DF64A
0CE106DF618 10UF STD 16V M
C208
C209 0CK105DF64A 1UF 2012 16V 20%
C211 0CK105DF64A 1UF 2012 16V 20%
10UF STD 16V M
C211 0CE106DF618
0CK105DF64A 1UF 2012 16V 20%
C212
C212 0CE476DF618 47UF STD 16V M
C213 0CK105DF64A 1UF 2012 16V 20%
C214 0CK104CF56A 0.1UF 1608 16V 10%
1UF 2012 16V 20%
C214 0CK105DF64A
C215 0CK105DF64A 1UF 2012 16V 20%
C217 0CK104CF56A 0.1UF 1608 16V 10%
C218 0CK104CF56A 0.1UF 1608 16V 10%
0.01UF 1608 50V 10%
C219 0CK103CK56A
0CK104CF56A 0.1UF 1608 16V 10%
C221
C223 0CE108DJ618 1000UF STD 35V M
C223 0CE475DK618 4.7UF STD 50V 20%
4.7UF STD 50V 20%
C225 0CE475DK618
0CK104CF56A 0.1UF 1608 16V 10%
C226
C226 0CE477DJ618 470UF STD 35V 20%
C226 0CE227DF618 220UF STD 16V M
C227 0CK104CF56A 0.1UF 1608 16V 10%
1UF 2012 16V 20%
C227 0CK105DF64A
C228 0CK104CF56A 0.1UF 1608 16V 10%
REPLACEMENT PARTS LIST
DESCRIPTION
- 26 -
LOCA. NO PART NO
C229 0CK104CF56A 0.1UF 1608 16V 10%
22UF STD 16V M
C229 0CE226DF618
0CE107DF618 100UF STD 16V M
C23
C230 0CK104CF56A 0.1UF 1608 16V 10%
C231 0CK104CF56A 0.1UF 1608 16V 10%
C231 0CE107DF618 100UF STD 16V M
0CK104CF56A 0.1UF 1608 16V 10%
C232
C233 0CK104CF56A 0.1UF 1608 16V 10%
C236 0CK105DF64A 1UF 2012 16V 20%
C24 0CE476DF618 47UF STD 16V M
0.1UF 1608 16V 10%
C242 0CK104CF56A
C246 0CK104CF56A 0.1UF 1608 16V 10%
C247 0CK104CF56A 0.1UF 1608 16V 10%
C248 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C249 0CK104CF56A
0CE106SF6DC 10UF MVG 16V 20%
C2604
C2605 0CE106SF6DC 10UF MVG 16V 20%
C27 0CE476DF618 47UF STD 16V M
100PF D 50V 10%
C3 0CN1010K519
0CK104CF56A 0.1UF 1608 16V 10%
C301
C302 0CE226SF6DC 22UF MVG 16V 20%
C3102 0CK104CF56A 0.1UF 1608 16V 10%
C3103 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C3105 0CK104CF56A
C3106 0CK104CF56A 0.1UF 1608 16V 10%
C3108 0CE105SK6DC 1UF MVG 50V 20%
C312 0CE106SF6DC 10UF MVG 16V 20%
0.047UF 1608 25V 10%
C313 0CK473CH56A
0CK473CH56A 0.047UF 1608 25V 10%
C314
C315 0CK473CH56A 0.047UF 1608 25V 10%
C331 0CK104CF56A 0.1UF 1608 16V 10%
82NF 1608 16V 10%
C339 0CK823CF56A
0CK822CK46A 8.2NF 1608 50V 5%
C340
C349 0CK104CF56A 0.1UF 1608 16V 10%
C370 0CK104CF56A 0.1UF 1608 16V 10%
C371 0CE106SF6DC 10UF MVG 16V 20%
10UF MVG 16V 20%
C384 0CE106SF6DC
C385 0CK104CF56A 0.1UF 1608 16V 10%
C386 0CE106SF6DC 10UF MVG 16V 20%
C393 0CE226SF6DC 22UF MVG 16V 20%
10UF MVG 16V 20%
C394 0CE106SF6DC
0CN1010K519 100PF D 50V 10%
C4
C400 0CE226SF6DC 22UF MVG 16V 20%
C402 0CE476SF6DC 47UF MVG 16V 20%
220PF 1608 50V 5%
C403 0CC221CK41A
0CE476SF6DC 47UF MVG 16V 20%
C404
C405 0CE226SF6DC 22UF MVG 16V 20%
C405 0CE476SF6DC 47UF MVG 16V 20%
C406 0CE107SF6DC 100UF MVG 16V 20%
10UF MVG 16V 20%
C406 0CE106SF6DC
C407 0CK104CF56A 0.1UF 1608 16V 10%
DESCRIPTION
