Zenith Z52SZ80 Service Manual page 23

LOCA. NO PART NO
IC808 0IMCRSG008A 74LX1G14CTR 5P SOT323-5L
SC1565IST-1.8 SEMTECH 3P SOT223
IC810 0IMCRSJ001A
0ILI817000G LTV817M-VB 4P
IC830
IC850 0IPMG00029A KIA78R00API TO-220IS 4P
IC851 0IMCRFA007A KA431Z FAIRCHILD 3DIP,TO-92
IC900 0IMCRTI012B 2503253-0003(DAD1000-3) 80P
0ISTLON023B NL17SZ126DFT2G 5P SC70-5
IC906
IC906 0IMCRSG007A 74VIT125CTR 5P S0T323-5L
IC907 0IMCRSG008A 74LX1G14CTR 5P SOT323-5L
IC908 0IMCRSG008A 74LX1G14CTR 5P SOT323-5L
74VIT125CTR 5P S0T323-5L
IC910 0IMCRSG007A
IC913 0IMCRSG007A 74VIT125CTR 5P S0T323-5L
TRANSISTOR
KRA102S SOT23 -50V -0.1A
Q100 0TR102008AB
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q1000
Q1001 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q1002 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q1003 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q1004
Q1005 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q101 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1201 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
KTC3875SY(ALY) SOT23 60V 30A
Q1202 0TR387500AC
Q1203 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1204 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1205 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
KTC3875SY(ALY) SOT23 60V 30A
Q1206 0TR387500AC
0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q1208
Q1209 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1210 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q1211 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1213
Q1218 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q1219 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1222 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
KTC3875SY(ALY) SOT23 60V 30A
Q1223 0TR387500AC
Q1224 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q1225 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
Q2 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
CHIP 2SC3875S(ALY) BK KEC
Q200 0TR387500AA
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q201
Q202 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q203 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q204 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q205
Q206 0TR102008AB KRA102S SOT23 -50V -0.1A
Q207 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q208 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
CHIP 2SC3875S(ALY) BK KEC
Q209 0TR387500AA
Q210 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
REPLACEMENT PARTS LIST
DESCRIPTION
- 23 -
LOCA. NO PART NO
Q211 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
CHIP 2SC3875S(ALY) BK KEC
Q212 0TR387500AA
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q216
Q400 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q401 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q402 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q600
Q601 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q602 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q602 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
BSS83
Q603 0TR830009BA
Q603 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q604 0TR830009BA BSS83
Q604 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
BSS83
Q605 0TR830009BA
0TR830009BA BSS83
Q606
Q607 0TR830009BA BSS83
Q608 0TR830009BA BSS83
Q702 0TR387500AC KTC3875SY(ALY) SOT23 60V 30A
0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q800
Q801 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
Q801 0TR150400BB 2SA1504SY(ASY) SOT23 -50V -30A
Q802 0TR387500AA CHIP 2SC3875S(ALY) BK KEC
KTC4370A-Y TO-220IS BK KEC
Q802 0TR437000BA
Q852 0TR945009AA KSC945C-Y TO92
KDS184 TP KEC - 85V 300MA
D1 0DD184009AA
0DLLT0260AA LED,LTL-30EWJ
D1
D100 0DRDI00148A B140A 40V 1A 30A .SEC 0.5MA
D100 0DD184009AA KDS184 TP KEC - 85V 300MA
D100 0DD184009AA KDS184 TP KEC - 85V 300MA
0DLLT0260AA LED,LTL-30EWJ
D2
D201 0DSPT00029A 1N4148M DO34 100V 75VA
D3 0DD226239AA KDS226 TP KEC
D3 0DLLT0260AA LED,LTL-30EWJ
KDS184 TP KEC - 85V 300MA
D4 0DD184009AA
D401 0DRDI00148A B140A 40V 1A 30A .SEC 0.5MA
D5 0DD184009AA KDS184 TP KEC - 85V 300MA
D6 0DD184009AA KDS184 TP KEC - 85V 300MA
KDS184 TP KEC - 85V 300MA
D601 0DD184009AA
0DD184009AA KDS184 TP KEC - 85V 300MA
D602
D611 0DZ848209AA ZENERS,BZX84C8V2
D700 0DS113379BA 1SS133 T-72 DO34 90V
D701 0DS113379BA 1SS133 T-72 DO34 90V
0DS113379BA 1SS133 T-72 DO34 90V
D702
D703 0DS113379BA 1SS133 T-72 DO34 90V
D704 0DS113379BA 1SS133 T-72 DO34 90V
D705 0DS113379BA 1SS133 T-72 DO34 90V
1SS133 T-72 DO34 90V
D706 0DS113379BA
D707 0DS113379BA 1SS133 T-72 DO34 90V
DESCRIPTION
DIODE
