models 965ss, 1065ss,
1065sse, 1075sse
OPERATING INSTRUCTIONS AND PARTS MANUAL
Thank you for purchasing a Hotsy Pressure Washer. This manual covers the operation and mainte-
nance of your pressure washer. All information in this manual is based on the latest product infor-
mation available at the time of printing. Hotsy, Inc. reserves the right to make changes at any time
without incurring any obligation.
Read instructions carefully before attempting to assemble, install, operate or service this pressure
washer. Failure to comply with instructions could result in personal injury and/or property damage!
c
®
®
serial number:
date purchased:
for sales and service, please contact:
97-6554
