Specifications - ECS A75F2-M2 User Manual

Specifications

CPU
•
•
Note: Please go to ECS website for the latest CPU support list.
Chipset •
Memory
•
•
•
Note: Please go to ECS website for the latest CPU support list.
Expansion
•
Slots •
•
Storage •
Audio •
•
LAN
•
•
Rear Panel I/O
•
•
•
•
•
•
•
Internal I/O
•
Connectors &
•
Headers
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
2
Socket FM2 for AMD TRINITY processors
Supports CPU up to 100W TDP
AMD A75 Chipset
Dual-channel DDR3 memory architecture
2 x 240-pin DDR3 UDIMM sockets support up to 32 GB
Supports DDR3 1866/1600/1333/1066/800
SDRAM
1 x PCI Express x16 Gen2 slot
2 x PCI Express x1 slots
1 x PCI slot
Supported by AMD A75 (Hudson D3)
- 6 x Serial ATA 6Gb/s connectors
ALC662 6-Ch High Definition audio CODEC
- Compliant with HD audio specification
RTL8111E Gigabit Lan
RTL8105E 10/100 LAN (optional)
1 x PS/2 keyboard and mouse combo connector
1 x D-Sub port (VGA)
1 x HDMI port
1 x DVI port
6 x USB 2.0 ports
2 x USB 3.0 ports
1 x RJ45 LAN connector
1 x Audio port (Line in, Line out, Mic_in Rear)
1 x 24-pin ATX Power Supply connector
1 x 4-pin 12V Power connector
1 x 4-pin CPU_FAN connector
1 x 3-pin SYS_FAN connector
1 x 3-pin PWR_FAN connector
2 x USB 2.0 headers support additional four USB 2.0 ports
(F_USB1 supports EZ Charger function)
1 x USB 3.0 header supports additional two USB 3.0 ports
6 x Serial SATA 6Gb/s connectors
1 x COM header
1 x Case open header
1 x SPDIF out header
1 x TPM header
1 x Front Panel audio header
1 x Front Panel switch/LED header
1 x Speaker header
1 x Parallel port header(LPT)
1 x Clear CMOS jumper
A75F2-M2 USER MANUAL
MHz DDR3
