Sensor Electronics SEC 3100 Instruction And Operation Manual page 25

Field Wiring Port (2
Power
4-20 mA
RS485 (MODBUS)
Alarm Relays
Magnetic Switch (3)
Alarm LED
Green OK
Yellow Low Alarm
Orange Mid Alarm
Red High Alarm
SENSOR ELECTRONICS CORPORATION
5500 LINCOLN DRIVE
MINNEAPOLIS, MINNESOTA 55436 USA
(T) 952.938.9486 (F) 952.938.9617
sales@sensorelectronic.com
Memory Data Card
)
x ¾ h
Gas Sensor Port (1
SEC 3000
SEC Millenium
Slot
)
x ¾ h
FIGURE 1
SEC 3100 OVERVIEW
LCD Display:
Real Time Status
Gas Type
Gas Concentration
Fault Identification
Range
ID Number
Memory Card Status
Interactive Menus
Calibration
Relay Programming
ID & Zone Number
Mounting holes (2)
Fault LED
Green OK
Red Fault
