Sensor Electronics SEC 3100 Instruction And Operation Manual page 17

Select Enter
ON DLY LOW
* OFF DLY
ENERGIZED
EXIT
Select Enter
ON DLY LOW
* OFF DLY
EXIT
Using the Up and Down arrows the operator can change the OFF delay time for the relay to turn OFF after
the reading has decreased below the alarm point threshold. The time is measured in seconds (0-255).
Once the correct time is displayed select Enter to accept the new value. Then Exit the menu and proceed
on to the next selection.
In this example the Low alarm relay will stay energized for 60 seconds after the alarm has cleared.
ON DLY LOW
* OFF DLY
ENERGIZED
EXIT
Arrow Down
ON DLY LOW
OFF DLY
* ENERGIZED NO
EXIT
Selecting Enter will allow the operator to change the operation of the relay coil from normally de-energized
(ENERGIZED NO) to normally energized (ENERGIZED YES). Once the correct operation is selected, use
the Down arrow to advance to the EXIT menu. Select Enter to go back to the Relay Menu
* LOW
MID
HI
This menu will allow the operator to select another relay to program. Or select Exit and the next display will
be:
* FAULT
EXIT
Arrow Down to Exit
FAULT
* EXIT
Enter
* EXIT
Selecting Enter will return the SEC 3100 into normal operation.
