Sensor Electronics SEC 3100 Instruction And Operation Manual page 14

Alarm Menu
CALIBRATION
* ALARM
RELAY
* LOW
MID
HI
EXIT
Select the Alarm Relay (LOW, MID, HI) using the down arrow. Once the cursor is on the alarm relay you
wish to configure, hold the magnet over Enter. The example LOW will be used. The same operations can
be used to set the MID or HI relays.
* ALARM LOW 4
LATCH
ACTIVE
EXIT
Selecting Enter will display the following screen allowing the alarm set point to be
programmed. Using the Up and Down arrows will change the set point. Once the correct set point is
displayed select Enter and the new value will be accepted.
* ALARM LOW 2
LATCH
ACTIVE
EXIT
* ALARM LOW 2
LATCH
ACTIVE
EXIT
Arrow Down
ALARM LOW
* LATCH
ACTIVE
EXIT
Selecting Enter will allow the operator to change the operation of the relay operation from Non-Latching
(NO) to Latching (YES).
Enter
Enter
*
CONFIGURING PROCESS
------ WAIT -------
NO
