Sensor Electronics SEC 3100 Instruction And Operation Manual page 22

Diagnostics Menu
* DIAGNOSTICS
REST RELAYS
EXIT
The Diagnostics Menu will allow the operator to enter the Locator Mode and Toggle Relays on and off to
verify operation.
Selecting Enter will display the following:
* LOCATOR OFF
TOGGLE RELAYS
EXIT
The Locator function is normally generated by the SEC 3500 operator interface. It can be used at the SEC
3100 to function as a lamp test. Selecting Enter will turn the Locator on.
* LOCATOR ON
TOGGLE RELAYS
EXIT
The Alarm and Fault LEDs will flash red and green alternately.
Selecting Enter again will turn the Locator function off.
Arrow Down to Toggle Relays (manual relay control)
LOCATOR
* TOGGLE RELAYS
EXIT
Selecting Enter will display the following:
* LOW
MID
HI
Select the Alarm Relay (LOW, MID, HI, FAULT) that is to be configured using the down arrow. Once the
cursor is on the correct alarm relay, hold the magnet over Enter. The example LOW will be used. The
same operations can be used to manually control the MID, HI, or FAULT relays.
* LOW OFF
MID
HI
Selecting Enter will manually turn on the relay, selecting Enter again will turn off the relay.
* FAULT
EXIT
