Daisy-Chaining the DKVM-16

Please closely follow the steps below to daisy-chain your DKVM-16 units. You
can daisy chain up to 8 DKVM-16s.
Connect your keyboard, mouse, and monitor to the console port (white color
block) of the master KVM bank (bank1).
Use the 3-in-one Cable Kit to connect the daisy-chain port of bank 1 to the
console port (white color block) of the 2nd KVM switch.
Please repeat step 2 to daisy-chain up to as many as 8 DKVM-16s.
Please use the attached 3 feet 3in-one
Cable Kit to daisy chain the KVM
Switches.
MASTER (Bank 1)
Slave (Bank 2)
Slave (Bank 3)
Slave (Bank 8)
16
