NOTE: How to uninstall the USB driver for the USB test mode
• Connect the camera while in the USB test mode to the computer so that the computer recognises the
camera.
• Right-click "My computer", select "Property" and open "Device manager".
• Select "USB device for UUSBD" , and then "Universal USB Driver (VMEM manufacturer's name)".
• Press "Delete" button and delete the driver.
• When using Windows98/98SE/Me, delete the following three files;
(NOTE! Do NOT delete "usbd. inf" and "usbd.sys", whose names are much alike the following.)
C:windows / inf / uusbd.inf
C:windows / inf / other / KashiwanoUUSBD.inf
C:windows / system32 / drivers / uusbd.sys
• The driver has been successfully deleted.
1-4. Use the USB ADJ Tool
(1) Prepare ADJ data read/write tool "adj331e.exe".
(2) Copy the common DLL for USB test to the same directory as that of the ADJ data read/write tool
"adj331e.exe" or under "c:windows / system".
(3) Turn the camera power on which is set in the USB test mode and let it enter the USB test mode (the test
menu appears right after the power is turned on).
Connect the camera to the computer by the USB cable.
(4) Boot "adj331e.exe." and use it as follows;
• Read ADJ data from the camera.
• Write ADJ data into the camera.
• Save ADJ data which is read.
• Open ADJ data which is saved.
Press "read from the camera".
Press "write into the camera".
Press "File" and "Save", and save it with an appropriate name.
Press "File" and "Open", and open the necessary file.
