You can use the camera's built-in monitor screen to view
images after you record them.
Basic Playback Operation
Use the following procedure to scroll through files stored in
the camera's memory.
Press the power button
to turn on the camera.
• This causes an image or a
message to appear on the
monitor screen.
Align the mode selector
with "
" (PLAY).
• This enters the PLAY
Use [ ] (forward) or [ ] (back) to scroll
through files on the monitor screen.
Power button
Mode selector
• Holding down [ ] or [ ] scrolls images at high
• In order to allow for faster playback image scrolling,
the image that initially appears on the monitor screen
is a preview image, which is of somewhat lower
quality than the actual display image. The actual
display image appears a short while after the preview
image. This does not apply to images copied from
another digital camera.


   Summary of Contents for CASIO EX-M20 - 2

  • Page 1

    PLAYBACK PLAYBACK You can use the camera’s built-in monitor screen to view Use [ ] (forward) or [ ] (back) to scroll images after you record them. through files on the monitor screen. Basic Playback Operation Use the following procedure to scroll through files stored in the camera’s memory.

  • Page 2

    PLAYBACK Playing an Audio Snapshot (EX-M20 Only) IMPORTANT! • Audio volume can be adjusted only when playback is Perform the steps below to display an audio snapshot being performed or is paused. (indicated by a indicator) and play its audio. •...

  • Page 3

    PLAYBACK In the PLAY mode, use [ ] and [ ] to scroll Flipping the Display through images on the monitor screen and The following procedure flips the image 180 degrees. This display the one you want. comes in handy when you want to show someone standing in front of you an image on the monitor screen.

  • Page 4

    PLAYBACK To scroll the image Zooming the Display Image on the display, press Perform the following procedure to zoom the image [SET], and then press currently on the monitor screen up to four times its normal [ ], [ ], [ ], or [ ]. size.

  • Page 5: Resizing An Image

    PLAYBACK Use [ ] and [ ] to select the setting you Resizing an Image want, and then press [SET]. You can use the following procedure to change a snapshot image to either SXGA size (1280 x 960 pixels) or VGA size To do this: Select this: (640 x 480 pixels).

  • Page 6

    PLAYBACK When the cropping Cropping an Image boundary is the size Use the following procedure when you want to crop a you want, press [DISP] portion of an enlarged image and use the remaining part of to lock it. the image as an e-mail attachment, Web page image, etc. •...

  • Page 7: Playing A Movie

    PLAYBACK IMPORTANT! Playing a Movie • Cropping an image creates a new file that contains Use the following procedure to play back a movie that was the cropped image. The file with the original image recorded in the movie mode. also remains in memory.

  • Page 8

    PLAYBACK • You can perform the following operations while a IMPORTANT! movie is playing. • You cannot repeat play a movie. To play a movie more than once, repeat the steps of the above To do this: Do this: procedure. Fast forward or fast reverse Hold down [ ] or •...

  • Page 9: Displaying The Calendar Screen

    PLAYBACK • Pressing [ ] while the date selection cursor is Displaying the Calendar Screen located anywhere in the top line of the calendar Use the following procedure to display a 1-month calendar. causes the previous month to appear. While the calendar is on the display, you can select a date, •...

  • Page 10

    PLAYBACK Configure the slideshow settings. Playing a Slide Show • See the pages indicated below for more information. Slide Show automatically plays back images in sequence at a fixed interval. For information about Go here: configuring this setting: “To specify the slideshow Images images”...

  • Page 11: To Specify The Slideshow Images

    PLAYBACK IMPORTANT! To specify the slideshow images • Note that all buttons are disabled while an image change is in progress. Wait until an image is stopped Use [ ] and [ ] to select “Images”, and then on the monitor screen before performing a button press [ ].

  • Page 12: To Specify The Slideshow Time

    PLAYBACK I Selecting a Particular Image for a Slideshow To specify the slideshow time When you select “One image” as the slideshow type, the slide show displays only one image, without changing it. Use [ ] and [ ] to select “Time”. Use this setting when you want a particular image to remain on the display while the camera is on the USB Use [ ] and [ ] to specify the time setting...

  • Page 13: To Set The Slideshow Interval

    PLAYBACK To set the slideshow interval Using the Photo Stand Feature The “Photo Stand” feature lets you specify what should Use [ ] and [ ] to select “Interval”. appear on the camera’s monitor screen while the camera is on its USB cradle. You can play a Phot Stand slideshow Use [ ] and [ ] to specify the interval setting without worrying about remaining battery power, or you can you want, and then press [SET].

  • Page 14: Rotating The Display Image

    PLAYBACK • Pressing [MENU] displays a screen for configuring Rotating the Display Image slideshow settings. To restart the slideshow, press Use the following procedure to rotate the image 90 degrees [MENU] while the menu screen is displayed, or and register the rotation information along with the image. select “Start”...

  • Page 15

    PLAYBACK Use [ ] and [ ] to Using Image Roulette select “Rotate”, and Image Roulette cycles images like a slot machine on the then press [SET]. display, before stopping at one of them. When you start an • This rotates the image Image Roulette operation, images scroll randomly on the 90 degrees to the right.

  • Page 16

    PLAYBACK IMPORTANT! Adding Audio to a Snapshot (EX-M20 Only) • Image Roulette does not play movie files or display The “after-recording” feature lets you add audio to voice recording images (EX-M20 only). snapshots after they are recorded. You can also re-record •...

  • Page 17

    PLAYBACK In the PLAY mode, use [ ] and [ ] to scroll To re-record audio through snapshots until the one to which you want to add audio is displayed. In the PLAY mode, use [ ] and [ ] to scroll through snapshots until the one whose audio Press [MENU].

  • Page 18

    PLAYBACK IMPORTANT! Playing Back a Voice Recording File (EX-M20 Only) • Keep the microphone on the front of the camera pointed at Perform the following steps to play back a voice recording the subject. file. • Take care that you do not block the microphone with In the PLAY mode, use [ ] and [ ] to display your fingers.

  • Page 19

    PLAYBACK IMPORTANT! • Audio volume can be adjusted only when playback is being performed or is paused. • If your recording has index marks (page 69) inside it, you can jump to the index mark before or after the current playback location by pausing playback and then pressing [ ] or [ ].

  • Page 20: Deleting Files

    DELETING FILES DELETING FILES You can delete a single file, or you can delete all files Deleting a Single File currently in memory. Perform the following steps when you want to delete a single file. IMPORTANT! • Note that file deletion cannot be undone. Once you In the PLAY mode, delete a file, it is gone.

  • Page 21

    DELETING FILES IMPORTANT! Deleting All Files • If a file cannot be deleted for some reason, the The following procedure deletes all unprotected files message “This function is not supported for this file.” currently in memory. appears when you try to delete it. In the PLAY mode, press [ ] ( Use [ ] and [ ] to select “All Files Delete”, and then press [SET].
