- Page 1 Avaya IP Key Expansion Module (KEM) User Guide Avaya Business Communications Manager Release 2.0 Document Status: Standard Document Number: NN40050-103 Document Version: 04.02 Date: October 2010...
- Page 2 Avaya customers and other parties through the Avaya Support Web site: http://www.avaya.com/support Please note that if you acquired the product from an authorized reseller, the warranty is provided to you by said reseller and not by Avaya. Licenses THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE, HTTP://SUPPORT.AVAYA.COM/LICENSEINFO/...
-
Page 3: About The Key Expansion Module
Liquid Crystal Display (LCD). Up to four Avaya IP Deskphone KEMs can be attached to an Avaya 2002 IP Deskphone or Avaya 2004 IP Deskphone. With four Avaya IP Deskphone KEMs attached, the IP Phone can have up to 96 programmable keys. -
Page 4: Adjusting The Display
Adjusting the display The Avaya IP Deskphone KEM (see Figure 1 on page 4) has one LCD between two rows of 12 programmable keys for a total of 24 keys. Each key has a 10-character display label that is set automatically. -
Page 5: Setup And Assembly
The Avaya IP Deskphone KEM mounts on the right side of an Avaya 2002 IP Deskphone or Avaya 2004 IP Deskphone as shown in Figure 2. It is secured by snapping into a receptacle on the back of the IP Phone using the desk-mount bracket and structural baseplate supplied with the Avaya IP Deskphone KEM. -
Page 6: Using The Wall-Mount Option
Avaya IP Deskphone KEM. Adjusting the tilt base The tilt base for the Avaya 2002 IP Deskphone cannot be adjusted; however, the tilt base on the Avaya IP Deskphone KEM can be adjusted to match the fixed angle of the Avaya 2002 IP Deskphone. -
Page 7: Cold Start
IP Phone KEMs will reboot when you connect a new module. Coldstart You can press a sequence of keys (on the KEM) to trigger a cold start of a single Avaya IP Deskphone KEM, or all Avaya IP Deskphone KEMs attached to the same IP Phone. The sequence must be performed while the icons are flashing. -
Page 8: Controls And Settings
When an Avaya IP Deskphone KEM is installed on an Avaya 2002 IP Deskphone or Avaya 2004 IP Deskphone, the controls and settings of the IP Phone control both the IP Phone and the Avaya IP Deskphone KEM. Use the Telephone Options menu on the attached IP Phone to set the contrast and feature key labels of the Avaya IP Deskphone KEM. -
Page 9: Programming Memory Buttons
• Transfer (≤‡‚) • Priority Call (≤fl·) Make sure that features are programmed on your Avaya 2002 IP Deskphone or Avaya 2004 IP Deskphone or KEM by following the steps below for programming memory buttons. Internal autodial External autodial 1. Press ≤•¤. - Page 10 Telset administration interface. Administrators must have administrator privileges to access the Telset administration interface. For more information about how to log on to and use the Telset administration interface, administrators can see Avaya Telset Administration Guide (NN40170-604). For administrator-level procedures about how to program IP Phone memory buttons through the Business Element Manager and through the Telset administration interface, see Avaya Business Communications Manager 6.0 Configuration —...
-
Page 11: Moving Line Buttons
