Carefully uninstall drive (if still installed in carrier). Refer to section "INSTALLATION"

for further information.

Loosen and remove the four (4) #6-32 Phillips Flat Hd. screws securing the front

assembly to the carrier (Step 1 of Figure C-1). Carefully remove the front assembly.

Uninstall the faulty fan by removing the two (2) Philips Pan Hd. screws securing the

fan to the carrier (Step 2 of Figure C-1).

Carefully disconnect the fan power cable (Step 3 of Figure C-1).

To install the new fan, simply reverse above mentioned steps.

StorCase Technology, Inc.

Appendix C - Field-Replacing the Carrier Fan

Ultra320 DE110 User's Guide - Rev. A03
