Selecting The Unit Id Number - StorCase Technology Data Express DE110 User Manual

12
8. Reconnect any system or peripheral cables removed earlier.
9. Turn ON power to the computer. If the installation has been successful, and all the
cables have been properly attached, the system should boot normally. Although the
computer may not recognize the Ultra320 DE110 yet, the front panel display on the
Ultra320 DE110 receiving frame should illuminate.
10. The new drive may need to be formatted or initialized prior to use with the operating
system and applications software. Refer to the drive and/or computer manufacturer's
documentation for formatting information.

Selecting the Unit ID Number

1. Verify that power is turned ON to the Ultra320 DE110 receiving frame by turning on
your computer. A number will appear in the unit ID display window if the carrier is
locked in place.
2. Unlock the Ultra320 DE110 drive carrier and remove it from the receiving frame. A
"u" will be displayed initially when the unit is unlocked but will return to a number when
the carrier is removed from the receiving frame.
WARNING:
3. Use the alignment tool supplied with the Ultra320 DE110 to select the ID number of
the disk drive. Refer to Figure 9 for the location of the ID Select Switch inside the
receiving frame.
4. After you have selected an appropriate unit ID number, replace the Ultra320 DE110
carrier in the receiving frame, and LOCK IT IN PLACE.
NOTE:
5. Reboot the computer. The new disk is now ready for use, although it may have to
be formatted or initialized prior to use with your operating system and applications
software.
StorCase Technology, Inc.
Unlocking the carrier unit switches DC power OFF to the drive. Since
disk drives require a short amount of time to spin down, allow about
15 seconds before pulling the carrier unit out of the receiving frame
to avoid possible damage to the drive.
The lock on the Ultra320 DE110 carrier functions as a lock and a DC
power switch for the carrier unit. The lock must be engaged in order
to supply power to the carrier and installed drive.
Ultra320 DE110 User's Guide - Rev. A03
Installation
