INSTALLATION AND OPERATION INSTRUCTIONS
WHAT TO DO IF YOU SMELL GAS
*
*
*
*
WARNING: Improper installation, adjustment, alteration,
service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
Space-Ray Division, Gas Fired Products, Inc. P.O. Box 36485, Charlotte, NC 28236 (704) 372-3485
41357080
July 06
FLOOR MODELS
RFPA21A-N6, RFPA21A-L6
Do not try to light any appliance.
Do not touch any electrical switch; do not use any
phone in your building.
Immediately call your gas supplier from a neighbors phone. Follow
the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire
department.
SAVE FOR FUTURE REFERENCE
