Placing the system
Installation image:
TV
BD Player
DVD player
Place the system as shown.
Remove the protective film covering the TX-BOX, sound
bar and subwoofer before using the system.
System connections
Make sure to unplug the AC power cord before making any connections.
Subwoofer
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Speaker connection
Connect the wire without insulation tube to the minus (–)
terminal, and the wire with red and white insulation tube to
the plus (+) terminal.
Caution:
●
Use speaker with an impedance of 3 ohms or more, as
lower impedance speaker can damage the unit.
2012 January 31
ACTIVE SUBWOOFER SYSTEM
HT-SL72
Right
R
Red
AC outlet
AC 120 V ~ 60 Hz
E-10
HT-SL72 / HT-SL77 ZBxxx
Notes:
●
As the sound from the system is omni-directional, you
can place the speaker anywhere you like. However, it is
recommended to place it as close to the TV as possible.
●
The front panel of the speaker is not removable.
●
If the TX-BOX is placed behind the TV, make sure it is
not place less than 20mm.
Caution:
Do not change the installation direction when the unit is
turned on.
Placing the stand
Place the stand as shown.
Subwoofer
SUBWOOFER SYSTEM
ACTIVE SUBWOOFER SYSTEM
HT-SL72
Stand
Left
L
White
TX-BOX
●
Do not make a mistake when
connecting
the
right
and
speakers. The right speaker is the
one on the right side when you face
the unit.
Do not let the bare speaker wires
●
touch each other.
●
Do not allow any objects to fall into or
to be placed in the bass reflex duct.
●
Do not stand or sit on the subwoofer/sound bar. You
may be injured.
TX-BOX
Stand
Sound Bar
AC outlet
AC 120 V ~ 60 Hz
left
INCORRECT
