Part No. 102139 Rev. E
and Millennia
Epicure
®
Wall Mount Range Hoods
For use with models:
EH30, EH36, EH42, EH48, EH54,
MH30, MH36 and MH48
Approved for use with All dAcor
tested in AccordAnce with the lAtest edition of Ansi/ul 507
stAndArd for electric fAns And cAn/csA-c22.2 no. 113 stAndArd
for fAns And ventilAtors.
Installation Instructions
™
®
rAnges And cooktops.
Advertisement
Table of Contents
Related Manuals for Dacor Epicure EH30
Summary of Contents for Dacor Epicure EH30
-
Page 1: Installation Instructions
For use with models: EH30, EH36, EH42, EH48, EH54, MH30, MH36 and MH48 ® Approved for use with All dAcor rAnges And cooktops. tested in AccordAnce with the lAtest edition of Ansi/ul 507 stAndArd for electric fAns And cAn/csA-c22.2 no. 113 stAndArd for fAns And ventilAtors. -
Page 2: Table Of Contents
Monday — Friday 6:00 . to 5:00 Pacific Time Web site: www.Dacor.com All specifications subject to change without notice. dacor assumes no liability for changes to specifications. © 2008 Dacor, all rights reserved. -
Page 3: Important Safety Instructions
Hazards or unsafe practices that could result in severe • Always contact the Dacor Customer Service Team personal injury or death. about problems and conditions that you don’t under- stand. cAution Hazards or unsafe practices that could result in minor personal injury or property damage. -
Page 4: General Safety Precautions
The customer should not install, repair or replace any part of the range hood unless specifically recommended in the literature accompanying it. A qualified service technician should perform all other service. Contact the nearest Dacor authorized service representative at (800) 793-0093, or at www.Dacor.com for examination, repair or adjustment. -
Page 5: Product Specifications
Important Safety Instructions wArning to reduce the risk of inJurY to persons in the event of A rAnge top greAse fire: SMOTHER FLAMES with a close-fitting lid, cookie sheet or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT. -
Page 6: Dimensions
Product Specifications Dimensions Tolerances: +1/16”, -0 (1.6 mm, -0), unless otherwise stated. note: The exhaust duct(s) and electrical wiring can be connected from either the top or the back of the hood. Single exhaust models** Dual exhaust models* Standard 8” duct connection Standard 8”... -
Page 7: Product Specifications
Hood assembly with filters (size and style varies with model) • Blower mounting hardware (used only for installations requiring rear exhaust configuration • Light replacement tool • Literature • Light bulbs (quantity varies with model) • Dacor Stainless Steel Cleaner... -
Page 8: Planning The Installation
Planning the Installation wArning Observe all governing codes and ordinances during planning and installation. Contact your local building department for further information. Cabinet Layout iMportAnt See the diagram for minimum installed distance from wArning the hood to the cooktop surface. The minimum specified distance may be higher for the particular range or To reduce the risk of personal injury caused by reaching cooktop in use. - Page 9 • Make sure duct work does not interfere with floor joists or wall studs. • On dual exhaust models, the two 8” exhausts may be merged into one 10” duct using Dacor transition kit AHT10. See page 16 for details.
-
Page 10: Preparing For Installation
Preparing for Installation Verify the Package Contents Electrical Service Installation Unpack the parts box and verify that all parts have been wArning included according to the parts list on page 5. If any item is missing or damaged, please contact the dealer immedi- The electric service to the range hood should be installed ately. -
Page 11: Installation Instructions
Preparing for Installation Ceiling or Back wall cabinet bottom duct cut-out for top venting duct cut-out for rear venting Installation Instructions Blower Rotation Instructions wArning Model see pAge • Do not install the range hood unless the electrical service provided meets the range hood specifica- EH3012, MH3012, EH3612, MH3612, tions. -
Page 12: Rotating The Blower
Installation Instructions Rotating the Blower for Models: Disconnect the wiring harness connector from the blower motor. eh3012, Mh3012, eh3612, Mh3612 and While supporting the blower from below, remove the four (4) nuts that hold the blower and mounting plate in eh4212 (Models that are 12 inches high place. - Page 13 Installation Instructions Insert the opening on the blower motor assembly into Tip the hood back down so that the top of the hood the hole inside the back of the hood. The connector faces up. Using existing screws, attach the cover plate on the motor must be toward the bottom of the hood.
- Page 14 Installation Instructions Tip the hood back, so that it lays on its back with the Remove and discard Remove front pointing up. the mounting plates and discard attached to both blow- Remove the filters from the under side of the hood. er motors.
- Page 15 Installation Instructions Rotating the Blower for Models: Route the wiring harness as shown below. Secure the harness to the motor assemblies using the cable clamps supplied with the hood in the positions shown. eh3018, Mh3018, eh3618, Mh3618, eh4218 Attach the wiring harness to the brace inside the hood, (Models that are 18 inches high equipped with on the right side using two (2) supplied cable ties.
- Page 16 Installation Instructions Disconnect the wiring harness connector from the Route the wiring harness as shown. Secure the har- blower motor. ness to the motor assembly with the cable clamps sup- plied with the hood in the positions shown below. While supporting the blower from below, remove the four (4) nuts that hold the blower in place.
- Page 17 Installation Instructions Rotating the Blower for Models: Disconnect both wiring harness connectors from the blower motors. eh4818, Mh4818 and eh5418 (Models that are While supporting each blower from below, remove the four (4) nuts that hold each blower in place. Remove 18 inches high equipped with two blowers.
-
Page 18: Aht10 Transition Kit Installation
On dual exhaust models, the two 8” exhausts may be Attach the wiring harness to the brace inside the hood, merged into one 10” duct using Dacor transition kit AHT10. on the right side using two (2) supplied cable ties. -
Page 19: Mounting Bracket Installation
Installation Instructions 12” high models with rear exhaust: Find the temporary mounting bracket in the shipping box. Put the bracket against the wall and line up the Center the transition over the duct collars while resting the center hole with the intersection of the bracket center unmodified edge on the top of the hood. -
Page 20: Hanging The Range Hood
Installation Instructions Hanging the Range Hood Duct Work Installation wArning wArning Hanging the range hood requires two people. Do not During duct installation, make sure there are no attempt to lift the hood without assistance. obstructions that keep the damper flaps on the top of the hood from opening. -
Page 21: Final Electrical Installation
Installation Instructions Final Electrical Installation wArning • To avoid electric shock or fire hazard, prior to connecting the electrical wiring to the hood, make sure that power to the hood power supply line is turned off at the fuse box or circuit breaker panel. •... - Page 22 Installation Instructions wArning • Do not ground the circuit to a gas line. • Do not ground the circuit to a hot water pipe. • Water lines that are insulated must be jumped to assure continuity to ground. See below. To house circuit breaker Separate No.
-
Page 23: Verifying Proper Operation
Repeat the above test. • If the hood still does not work, contact an authorized Dacor service company at (800) 793-0093. Do not attempt to repair the appliance yourself. Dacor is not responsible for service required to correct a faulty installation. - Page 24 Dacor ● 1440 Bridge Gate Drive, Diamond Bar, CA 91765 ● Tel: (800) 793-0093 ● FAX: (626) 403-3130 ● www.Dacor.com...
