for COIN COMPACT DRYER
The dryer must not be stored or installed where it will be exposed to water and/or weather.
WARNING: For your safety the information in this manual must be followed to
minimize the risk of fire or explosion or to prevent property damage, personal
injury or death.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS
-Do not try to light any appliance.
-Do not touch any electrical switch: do not use any telephone in your building.
-Clear the room, building or area of all occupants.
-Immediately call your gas supplier from a neighbor's telephone. Follow the
gas supplier's instructions.
-If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
You, the purchaser, must post in a prominent location instructions to be followed in the event the user smells
gas. Consult your local gas supplier for procedure to be followed if the odor of gas is present.
"For Your Safety"
Post the following
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
THIS MACHINE IS FOR DRYING ONLY FABRICS CLEANED IN WATER.
avoid possibility of fire, including spontaneous combustion, do not dry oiled floor mops, items
containing foam rubber or similarly textured rubberlike materials or any material on which you
have used a cleaning solvent or which contains flammable liquids or solids (such as gasoline,
kerosene, waxes, etc.)
It is important that you read this Manual and retain it for future reference.
For service or replacement parts, contact the distributor in your area or:
OPERATOR'S MANUAL
caution in a prominent location:
FOR YOUR SAFETY
FOR YOUR SAFETY
Dexter Laundry, Inc
2211 W. Grimes
Fairfield, Iowa 52556, USA
8514-046-001F
July 2013
To

Advertisement

loading
Need help?

Need help?

Do you have a question about the COIN COMPACT DRYER and is the answer not in the manual?

Questions and answers

Summary of Contents for Dexter Laundry COIN COMPACT DRYER

  • Page 1 8514-046-001F July 2013 OPERATOR’S MANUAL for COIN COMPACT DRYER The dryer must not be stored or installed where it will be exposed to water and/or weather. WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death.
  • Page 2 French Language Warnings AVERTISSEMENT. Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort. Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de tout autre appareil.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Page No. Warnings about use and operation ..................3 Installation Instructions ....................5, 6, 7 Dryer Shutdown .........................10 Operating Instructions......................11 Preventative Maintenance Instructions................16 ILLUSTRATIONS Figure 1 - Dryer Dimensions ....................4 Figure 2 - Vertical Clearance Dimensions ................6 Figure 3 - Dryer Exhausting ....................9 WARNINGS ABOUT USE AND OPERATION It is ABSOLUTELY ESSENTIAL that the dryer be grounded to a known earth (zero) ground.
  • Page 5 INSTALLATION AND OPERATING INSTRUCTIONS This dryer may have been supplied as part of a washer/dryer stacked appliance. If so, refer to the washer instructions for uncrating and hard mounting the stacked unit to a concrete floor and observe the dryer clearances listed below.
  • Page 6: Installation Instructions

    V. Top Refer to figure labeled “Vertical Clearance Dimensions”. AB. 0 clearance is allowable at the top; 4 in. (102 mm) back from the front. However 1/4 in. (6 mm) clearance should be allowed in case the dryer needs moving. C.
  • Page 7 3. MAKE-UP AIR. Adequate make-up air, 440 CFM (12.5 m /min.), must be supplied to replace air exhausted by dryers on all types of installations. Provide a minimum of 1 sq. ft. (.14 m ) make-up air opening to outside for each dryer. This is a net requirement of effective area. Screens, grills or louvers, which will restrict the flow of air, must be considered.
  • Page 8 CAUTION: The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psig (35 mbar). The dryer must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½...
  • Page 9 Installation of several dryers, where a main discharge duct is necessary, will need the following considerations for installation (see Figure 3). Individual 6 in. (152 mm) exhaust ducts from the each dryer should enter main discharge duct at a 45-degree angle in the direction of discharge airflow.
  • Page 10: Dryer Shutdown

    7. DRYER IGNITION (SOLID STATE IGNITION). The solid-state ignition system lights the main burner gas by spark. The gas is ignited and burns only when the gas-valve relay (in the electronic controller) calls for heat. The procedure for first-time starting of a dryer is as follows: A.
  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS 1. Deposit coins to satisfy vend price display of idle dryer. Each deposit decreases the vend price until the display changes to show the amount of time purchased. WARM or LOW light illuminates. 2. Select drying cycle. Other cycle selections may be made now or later by pressing the appropriate key (button).
  • Page 12 PROGRAMMING: All operating parameters (vend price, temperatures, cool-down times, etc.) are adjustable. There are also several displays of information available from the controller (money audits, hours run, and dryer temperature.) The dryer is shipped ready for operation with the following pre-programmed data: Temperature- HOT (or HIGH): 175°F/ 78°C Temperature- MEDIUM:...
  • Page 13 TO CHANGE PROGRAMMED VALUES OR ZERO REGISTERS 1. Open the loading door. 2. Unlock the control tray, carefully slide the control tray assembly forward about three inches. Press the program switch. (See Figure 4 “Top View of Controller”) Reinstall and lock the controller. The controller is now in the program mode at the “00"...
  • Page 14 ORDER OF PROGRAMMING STEPS CYCLE DISPLAY PROGRAMMING STEP DESCRIPTION OPTIONS/RANGE LIGHTS HOUR METER Displays hours of timer operation. May be reset to zero HOT or HIGH MEDIUM __ __ MONEY AUDIT Value of coins deposited. May be reset to zero. WARM or HOT or TEMPERATURE: HOT or...
  • Page 15 AVAILABLE OPTIONS The following two features are available in the dryer. Disconnect power from the machine for two minutes before modifying the machine for either option. Anti-Wrinkle Option The dryer is shipped with this feature defeated. As shipped, when the machine stops at the end of the cycle, the load will sit motionless in the machine until the user removes the load.
  • Page 16: Preventative Maintenance Instructions

    SERVICING THE DRYER Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper operation. Attention. Lors des opérations d’entrien des commandes, étiqueter tous les fils avant de les déconnecter. Toute erreur de câblage peut être une source de danger et de panne. PREVENTIVE MAINTENANCE INSTRUCTIONS Note: All procedures must be performed when dryer is not running.
  • Page 17 For service and parts information, contact your local Dexter agent. To find your local Dexter agent, use the Distributor Locator at the website shown below. If a Dexter agent is not available, contact Dexter Laundry, Inc. directly as listed below: Mailing Address:...
