  • Page 2 Preface Notebook Computer D400E/D410E Service Manual...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 4: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400E/ D410E series notebook PC.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, elec- tric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 7: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 8: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 9: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 10: Table Of Contents

    Preface Contents Introduction ..........1-1 Mainboard Overview - Bottom (Connectors) ....... 1-14 Disassembly ..........2-1 Overview ..................1-1 System Specifications ..............1-2 Overview ..................2-1 Processor ..................1-2 Maintenance Tools ................2-2 Core Logic ..................1-2 Connections ..................2-2 Security ....................1-2 Maintenance Precautions ..............2-3 Memory ...................1-2 Cleaning ..................
  • Page 11 Combo Drive (D400E) ..............A-9 USB Port ..................B-19 DVD-ROM Drive (D400E) ............A-10 PCMCIA ENE CB1410 ..............B-20 Floppy Disk Drive (D400E) ............A-11 PCMCIA Power ................B-21 Hard Disk Drive (D400E) ............A-12 1394 PHY TSB41LV01 ..............B-22 Top (D410E) ................A-13 LPC Super I/O ................B-23...
  • Page 12 Preface Charger ..................B-40 SW Board and HotKey ..............B-41 TouchPad and Switch Board ............B-42 Updating the FLASH ROM BIOS..C-1...
  • Page 13 Preface...

  • Page 14: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the D400E/D410E series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 15: System Specifications

    Introduction System Specifications Processor • Intel Pentium 4 Processor - (478-pin) FC-PGA2 package µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 2.0/ 2.2/ 2.4/ 2.5 /2.6 GHz µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 533MHz FSB - 2.26/ 2.4/ 2.53/ 2.66/ 2.8/ 3.06 GHz •...

  • Page 16: Display

    Introduction Display • ATI Mobility Radeon 9000 high performance chip • Support AGP™ 4X Video Memory • Integrated 128-bit 2D/3D Graphics Accelerator Advanced HW accelerator for DVD playback The system allocates Fully Direct X 8.0 compliant graphics engine or "shares" a portion of system memory •...

  • Page 17: Keyboard

    Introduction Keyboard • “Win Key” keyboard Interface • Built-in TouchPad (scrolling key functionality integrated) • Three USB 2.0/1.1 ports • One Mini-IEEE 1394 port • One S-Video jack for TV output • One serial port • One parallel port (LPT1), supporting ECP / EPP •...

  • Page 18: Power Management

    Introduction Power Management • Supports ACPI v1.0b • Supports Hibernate mode • Supports Standby mode • Supports battery low sleep • Supports resume from modem ring Power • Full range AC adapter • AC-Input 100~240V, 50~60Hz • DC Output 20V, 6A (120W) •...

  • Page 19: Optional

    Introduction Optional • DVD-ROM Drive • CD-RW Drive • Combination Drive • Software DVD player • Wireless LAN module • Bluetooth module • PC Video Camera Design Differences This manual refers to the two notebook designs pictured below. The designs vary slightly in external design. Photographs used throughout this manual are of Design I.

  • Page 20: External Locator - Top View

    Introduction External Locator - Top View Figure 2 Top View 1. Optional Built-in PC Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. AP-Key buttons 7. Close Cover/Lid Switch 8. Power Button 9.

  • Page 21: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 3 Front View 1. LCD Latches 2. Mini IEEE 1394 Port 3. S/P DIF Out Port 4. Microphone Jack 5. Headphone Jack 6. Infrared Transceiver 7. Wireless Device ON/OFF Switch 8.

  • Page 22: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 5 Right Side View 1. Security Lock Slot Figure 6 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB 2.0/1.1 Ports 4. External Monitor (CRT) Port 5.

  • Page 23: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 7 Bottom View 1. Vent/Fan Intake 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU, Heatsink, DDR, Wireless LAN Cover Note : The RAM and optional Wireless LAN module are lo- cated under the CPU Heatsink Cover 1 - 10 External Locator - Bottom View...

  • Page 24: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS M650 3. Southbridge - SiS 4. Flash BIOS ROM Mainboard Overview - Top (Key Parts) 1 - 11...

  • Page 25: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots (no memory installed) 3. SiS 302LV TV- Out Controller 4. LAN Controller RTL8100BL 5. CardBus ENE CB1410 6. ALC202 - Audio Codec 7.

  • Page 26: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD (and Inverter) Connector (JLCD1) 3. Video Camera Cable Connector (JCCD1) 4. Power Switch Board Cable Connector (JSW1) 5. TouchPad Cable Connector (JTP1) 6.

  • Page 27: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. Wireless LAN Connector (JWL1) 2. DDR Fan Cable Connector (JFAN2) 3. CD-ROM Device Connector (JCDROM1) 4. Hard Disk Cable Connector (JHDD1) 5. Bluetooth Module Connector (JBT1) 6. CMOS Battery Cable Connector (JBAT1) 7.

  • Page 28: Disassembly

    Disassembly 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D400E/D410E series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). Component Parts We suggest you completely review any procedure before you take the computer apart.

  • Page 29: Maintenance Tools

    Disassembly NOTE : All disassembly procedures assume that the system is turned OFF , and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 30: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 31: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 8 1.
  • Page 32 Disassembly To remove the TouchPad and Click Board: To remove the Modem: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 33 Disassembly To remove the Mainboard: To remove the Floppy Disk Drive Assembly: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 34 Disassembly To remove the LCD Front Panel Module: To remove the PC Video Camera Module: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.

  • Page 35: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws & (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 4.

  • Page 36: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual ) when setting up a new hard disk.

  • Page 37: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266 MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, 256Mb, and 512Mb.
  • Page 38 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.

  • Page 39: Removing The Cd Device

    Disassembly Removing the CD Device The easy changeable CD device may be upgraded or changed. 1. Turn off the computer, remove the battery ( page 2 - 8 ) and turn it over. 2. Remove screws (Figure 5a) from the memory socket cover 3.
  • Page 40 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.

  • Page 41: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws (Figure 7a) from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer.

  • Page 42: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it).

  • Page 43: Removing The Processor

    Disassembly Removing the Processor page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it).
  • Page 44 Disassembly 6. Unlock the processor by raising lever (Figure 10a). 7. Lift the CPU (Figure 10b) off the computer. Figure 10 Processor Removal (cont’d) a. Raise the lever to unlock the CPU. b. Lift the CPU off the sock- Caution The heat sink, and CPU area in general, contains parts which...

  • Page 45: Removing The Keyboard

    Disassembly Removing the Keyboard page 2 - 8 1. Turn off the computer, remove the battery ( 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). 3.

  • Page 46: Removing The Keyboard Shielding Plate

    Disassembly Removing the Keyboard Shielding Plate page 2 - 8 page 2 - 18 1. Turn off the computer, remove the battery ( ) and keyboard ( 2. Remove screws (Figure 12a) from the keyboard shielding plate and lift the plate off the computer.

  • Page 47: Removing The Lcd And Top Case

    Disassembly Removing the LCD and Top Case page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...
  • Page 48 Disassembly & 5. Slide the LCD hinge covers (Figure 14a) out of the computer. 6. Remove screws & (Figure 14b) then carefully (pay careful attention to the antenna cables) lift the LCD assembly (Figure 14c) off the computer. & & 7.

  • Page 49: Removing The Touchpad And Click Board

    Disassembly Removing the TouchPad and Click Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 50: Removing The Switch Board

    Disassembly Removing the Switch Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 51: Removing The Modem

    Disassembly Removing the Modem page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 52: Removing The Speakers

    Disassembly Removing the Speakers page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 53: Removing The Mainboard

    Disassembly Removing the Mainboard page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 54: Removing The Fan Unit

    Disassembly Removing the Fan Unit page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 55: Removing The Floppy Disk Drive Assembly

    Disassembly Removing the Floppy Disk Drive Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 56: Removing The Pc Card Assembly

    Disassembly Removing the PC Card Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 57: Removing The Lcd Front Panel Module

    Disassembly Removing the LCD Front Panel Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 58: Removing The Inverter

    Disassembly Removing the Inverter page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 59: Removing The Pc Video Camera Module

    Disassembly Removing the PC Video Camera Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 60: Removing The Lcd Module

    Disassembly Removing the LCD Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...
  • Page 61 Disassembly 2 - 34...

  • Page 62: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the D400E/D410E series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 63: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part D400E D410E Location page A - 3 page A - 13 page A - 4...

  • Page 64: Top (D400E

    Part Lists Top (D400E) Figure 1 Top (D400E) Top (D400E) A - 3...

  • Page 65: Bottom (D400E

    Part Lists Bottom (D400E) Figure 2 Bottom (D400E) A - 4 Bottom (D400E)

  • Page 66: Lcd 14" (D400E

    Part Lists LCD 14" (D400E) Figure 3 LCD 14" (D400E) LCD 14" (D400E) A - 5...

  • Page 67: Lcd 15" (D400E

    Part Lists LCD 15" (D400E) Figure 4 LCD 15" (D400E) A - 6 LCD 15" (D400E)

  • Page 68: Cd-Rom Drive (D400E

    Part Lists CD-ROM Drive (D400E) Figure 5 CD-ROM Drive (D400E) CD-ROM Drive (D400E) A - 7...

  • Page 69: Cd-Rw Drive (D400E

    Part Lists CD-RW Drive (D400E) Figure 6 CD-RW Drive (D400E) A - 8 CD-RW Drive (D400E)

  • Page 70: Combo Drive (D400E

    Part Lists Combo Drive (D400E) Figure 7 Combo Drive (D400E) Combo Drive (D400E) A - 9...

  • Page 71: Dvd-Rom Drive (D400E

    Part Lists DVD-ROM Drive (D400E) Figure 8 DVD-ROM Drive (D400E) A - 10 DVD-ROM Drive (D400E)

  • Page 72: Floppy Disk Drive (D400E

    Part Lists Floppy Disk Drive (D400E) Figure 9 Floppy Disk Drive (D400E) Floppy Disk Drive (D400E) A - 11...

  • Page 73: Hard Disk Drive (D400E

    Part Lists Hard Disk Drive (D400E) Figure 10 HDD Drive (D400E) A - 12 Hard Disk Drive (D400E)

  • Page 74: Top (D410E

    Part Lists Top (D410E) Figure 11 Top (D410E) Top (D410E) A - 13...

  • Page 75: Bottom (D410E

    Part Lists Bottom (D410E) Figure 12 Bottom (D410E) A - 14 Bottom (D410E)

  • Page 76: Lcd 14" (D410E

    Part Lists LCD 14" (D410E) Figure 13 LCD 14" (D410E) LCD 14" (D410E) A - 15...

  • Page 77: Lcd 15" (D410E

    Part Lists LCD 15" (D410E) Figure 14 LCD 15" (D410E) A - 16 LCD 15" (D410E)

  • Page 78: Cd-Rom Drive (D410E

    Part Lists CD-ROM Drive (D410E) Figure 15 CD-ROM Drive (D410E) CD-ROM Drive (D410E) A - 17...

  • Page 79: Cd-Rw Drive (D410E

    Part Lists CD-RW Drive (D410E) Figure 16 CD-RW Drive (D410E) A - 18 CD-RW Drive (D410E)

  • Page 80: Combo Drive (D410E

    Part Lists Combo Drive (D410E) Figure 17 Combo Drive (D410E) Combo Drive (D410E) A - 19...

  • Page 81: Dvd-Rom Drive (D410E

    Part Lists DVD-ROM Drive (D410E) Figure 18 DVD-ROM Drive (D410E) A - 20 DVD-ROM Drive (D410E)

  • Page 82: Floppy Disk Drive (D410E

    Part Lists Floppy Disk Drive (D410E) Figure 19 Floppy Disk Drive (D410E) Floppy Disk Drive (D410E) A - 21...

  • Page 83: Hard Disk Drive (D410E

    Part Lists Hard Disk Drive (D410E) Figure 20 HDD Drive (D410E) A - 22 Hard Disk Drive (D410E)
  • Page 84 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D400E/D410E notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...

  • Page 85: Schematic Diagrams

    Schematic Diagrams System Block Diagram TV-OUT NORTHWOOD CLOCK ATI M9 GENERATOR SOCKET - 478 PANEL 2/16/32 2/16/32 DDRAM DDRAM Host Bus GTL+ & AGTL DDR INTERFACE TV-OUT SiS 302LV SiS M645DX VB-LINK 702 mBGA Sheet 1 of 41 PANEL CRT PORT System Block Diagram Ultra 66/100/133...
  • Page 86 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] 5 VCC_CORE JCPU1A HA#[3..31] HD#0 HA#[3..31] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 HD#7 HA#27 HD#8 HA#26 HD#9 HA#25 HD#10 HA#24 HD#11 HA#23 HD#12 HA#22 HD#13 HA#21 HD#14 HA#20 HD#15 HA#19...

  • Page 87: Socket 478 & Itp 2

    Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE CPUGTLVREFA R275 49.9_1% CPUGTLVREFB 49.9_1% C316 C313 C330 R276 C346 C349 C112 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R274 4.7uH_SMD_30% 62_1% IERR AE23...

  • Page 88: Clock Generator

    Schematic Diagrams Clock Generator Main Clock Generator Damping Resistors Place near to the +3VS Clock Outputs By-Pass Capacitors Place near to the Clock CLOCK GEN (650) FCM2012V121 Outputs CLK_VCC3 VDDREF CPU-1 49.9_1% RP44 HCLK-CPU HCLK-CPU VDDZ CPUCLK0 HCLK-CPU 3 C401 CPU-2 49.9_1% C102...

  • Page 89: M645Dx (Host/Agp) 1

    Schematic Diagrams M645DX (Host/AGP) 1 of 4 AAD18/AHSYNC 22(R) AAD30/BHSYNC 22(R) VAHSYNC 10 VBHSYNC 10 AAD18/AHSYNC AAD30/BHSYNC AAD17/AVSYNC 22(R) AAD31/BVSYNC AAD16/VADE 22(R) VAVSYNC 10 VBVSYNC 10 AAD17/AVSYNC AAD31/BVSYNC AAD16 10,30 AAD27/VBDE AAD27 10,30 R264 HNCOMP AAD28/VBCTL0 22(R) VBCLK AAD28 10,30 AAD29/VBCTL1 20_1% Rds-on(n) = 10 ohm...

  • Page 90: M645Dx (Memory For Ddr) 2

    Schematic Diagrams M645DX (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] 7,8 /RDQM[0..7] /RDQM[0..7] 7,8 /RDQS[0..7] /RDQS[0..7] 7,8 /RMA[0..14] /RMA[0..14] 7,8 /RCS#[0..5] /RCS#[0..5] 7,8 CKE[0..5] CKE[0..5] 7 Rs place close to DIMM1 BGA1B +2.5V RP46 /RMD4 AJ23 /RMD5 AG22 DQM0 /RDQM0 AH21 8P4R-10...

  • Page 91: M645Dx (& Crt Out) 3

    Schematic Diagrams M645DX (& CRT Out) 3 of 4 BGA1C NOTE: This page is for universal PCB design( suitable for both 645 or 650) SIS M650 ZCLK0 ZCLK0 ZCLK REFCLK0 NB Hardware Trap Table VOSCI REFCLK0 4 ZUREQ ZUREQ ZDREQ ZUREQ embedded pull-low ZDREQ...

  • Page 92: M645Dx (Power) 4

    Schematic Diagrams M645DX (Power) 4 of 4 +3VS +3VS +1.8VS +3VS C360 +1.8V 10UF/10V 0.1UF C412 C410 C374 BGA1D 10U(0805) 10UF/10V 0.1UF C427 C423 C381 +1.8V AUX1.8 AUX3.3 0.1UF C426 C395 C367 0.1UF 0.1UF 0.1UF +1.8VS C382 C681 0.1UF +3VS +1.8VS C363 0.1UF...

  • Page 93: Ddr Memory Dimm

    Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP20 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470 /RMA9 /RMD9 /RMA9...

  • Page 94: Ddr Sstl-2 Termination

    Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63]6,7 /RDQM[0..7] /RDQM[0..7]6,7 +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7]6,7 /RMA[0..14] /RMA[0..14] 6,7 /RCS#[0..5] /RCS#[0..5] 6,7 /RMD0 /RMA2 /RMD1 /RMA0 /RDQS0 /RMA12 /RMD2 /RSRAS# /RSRAS# RP63 8P4R-33 RP34 8P4R-33 /RMD3...

  • Page 95: Lvds Interface (Sis302Lv

    Schematic Diagrams LVDS Interface (SiS302LV) C248 33PF(R) +3VS COMPOSITE Z1301 R211 0(R) COMPOSITE LVDD1 FCM1608K121(R) R212 FCM1608K-121T07 JTV1 10U/10V(R) 0.1UF 0.1UF LGND 2.7UH DA204U(R) DA204U(R) R213 C250 33PF(R) R202 C261 C249 C262 C251 330PF 330PF +3VS 330PF 330PF LVDD2 SVIDEO CON PIN(GND1,GND2)=GND FCM1608K121(R) +3VS...

  • Page 96: Panel Con & Led Indicator

    Schematic Diagrams Panel Con & LED Indicator LCDVCC LCDVCC FCM2012V-121 FCM2012V-121 +3VS C322 C284 LCDVCC 4800 JLCD1 0.1UF 0.1UF +3VS TXOUT-LN0 TXOUT-UN0 C337 C338 TXOUT-LP0 TXOUT-UP0 R278 4.7U(0805) 0.1UF C285 C286 TXOUT-LN1 TXOUT-UN1 TXOUT-LP1 TXOUT-UP1 R301 0.1UF 4.7U(0805) Z245 TXOUT-LN2 TXOUT-UN2 VDD5 TXOUT-LP2...

  • Page 97: Pci/Ide/Hyperzip) 1 Of 4

    Schematic Diagrams 962 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] 19,20,25 AD[0..31] IDESAA[0..2] IDECS#A[0..1] IDECS#A[0..1] IDESAB[0..2] IDESAB[0..2] +1.8VS IDECS#B[0..1] IDECS#B[0..1] R118 BGA2A C150 C151 +3VS 0.01UF 0.1UF REQ4# IDEAVDD PREQ#4 IDEAVSS REQ3# PREQ#3 RP32 REQ2# ICHRDYA REQ2# ICHRDYA 14 PREQ#2 ICHRDYA FRAME# REQ1# IDEREQA...

  • Page 98: Misc Signals) 2 Of 4

    Schematic Diagrams 962 (Misc Signals) 2 of 4 BGA2B Programable on-die pull-high strength for CPU_S: ( Infinite, 150, 110, 56 Ohm) R102 4.7K NEED NOT to place OSC25MHI INIT# close to 96X +3VS INIT# INIT# OSC25MHO A20M# A20M# A20M# RN11 SMI# SMI# SMI#...
  • Page 99 Schematic Diagrams 962 (USB I/F) 3 of 4 BGA2C 1394_MA2/EESK UCLK48M UCLK48M4 EESK(GPI21) USBCLK48M 1394_MA1/EEDI EEDI(GPI22) 1394_MA0/EEDO UV3- -DATA3 -DATA3 EEDO(GPI23) 1394_EECS UV0+ UV0+ EECS(GPI24) UV0+ UV0- UV3+ +DATA3 UV0- +DATA3 UV0- UV1+ UV1+ UV1+ UV1- UV1- UV1- PHY_LPS UV2+ C465 C466 R239...

  • Page 100: Power & Rtc) 4 Of

    Schematic Diagrams 962 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C512 C511 C351 C406 C526 C489 C490 C505 C508 C469 C147 C482 C476 C501 C477 C127 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V BGA2D +1.8VS VDDZ...

  • Page 101: Hdd/Combo Connector

    Schematic Diagrams HDD/Combo Connector RP41 IDEDB7 /2IDB7 IDEDB7 IDEDB6 /2IDB6 /2IDB8 IDEDB8 IDEDB6 IDEDB8 13 IDEDB5 /2IDB5 /2IDB9 IDEDB9 IDEDB5 IDEDB9 13 +3VS IDEDB4 /2IDB4 /2IDB10 IDEDB10 IDEDB4 IDEDB1013 /2IDB11 IDEDB11 JCDROM1 IDEDB1113 R277 MICHRDYB CD-L CD-R 4.7K 8P4R-10 CD-L CD-R MIDEREQB CDGND...

  • Page 102: Usb Port

    Schematic Diagrams USB Port 560K 470K OC0# OC0# USBVCC0 +5VS C309 C308 FCM2012V121 1.1A F1AJ3 0.1UF L101 JCCD1 10UF/10V -DATA3 0.1UF -DATA3 FCM1608K121 L102 +DATA3 +DATA3 FCM1608K121 UV0- -DATA0 UV0- CCD CON UV0+ +DATA0 NEAR CCD CON. C848 UV0+ C847 47P(R) 47P(R) C101...

  • Page 103: Pcmcia Ene Cb1410

    Schematic Diagrams PCMCIA ENE CB1410 B_VCC C627 C619 C608 C602 C601 C644 C617 C632 C595 C646 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C618 C645 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 VPPD0 VPPD1 B_CD1 VPPD1 VCCD0# B_CD2 VCCD0# VCCD1# B_CD3...

  • Page 104: Pcmcia Power

    Schematic Diagrams PCMCIA Power +5VS C563 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE PHONE MONO_PHONE R431 AUXR BVCC B_VCC AUXL C588 10K(R) BVCC CDGND C590 C591 R423 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC AC_SYNC 15,26 AC_SDOUT 3.3V SYNC...

  • Page 105: Phy Tsb41Lv01

    Schematic Diagrams 1394 PHY TSB41LV01 +3VS L147 BLM21P221SGPTM00-03 PHY3V BLM21P221SGPTM00-03(R) C573 C582 C583 C581 C586 C580 C585 C572 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) Sheet 21 of 41 R170 6.34K_1% R176 1394 PHY PHY3V Z216 Z240 TSB41LV01 R422 1K(R) VDD5 PHYISO#...

  • Page 106: Lpc Super I/O

    Schematic Diagrams LPC Super I/O +3VS C530 C539 C529 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] 23 +5VS SA13 +5VS LPC_AD[0..3] R228 15,24 LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 LAD1 PD1/TRK0# FLASH# R227 LPC_AD2 LAD2 PD2/WP# BIOSCS# SA17 LPC_AD3...

  • Page 107: Lpt/Com Port

    Schematic Diagrams LPT/COM Port VDD5 VDD3 C260 0.1UF R223 100K PME# C247 PME# 19,22,24,25 0.1UF(K%) C268 C246 COM1RI 2N7002 C267 0.1UF(K%) 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R224 RN10 100K SOUTA SOUTA T1IN T1OUT RTSA# RTSA# T2IN T2OUT DTRA DTRA T3IN T3OUT COM1RI DSRA# R2OUTB...
  • Page 108 Schematic Diagrams LPC H8 VDD5 R508 0(0805)(R) 3VH8 3VH8 L135 R509 0(0805) VDD3 C212 4.7U(0805) 3VH8 C255 0.1UF +5VS C575 3VH8 1.1A F1AJ3 FH50ACB321611T C570 C571 0.1UF 0.1UF RP39 0.1UF 0.1UF C569 C562 C561 C202 JPS1 KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V KB-SI2 KB-SI4...

  • Page 109: Lan Rtl8100Bl

    Schematic Diagrams LAN RTL8100BL VCTRL LANVDD3 LANVCC25 LANVDD3 2SB1198K C431 C432 C404 C384 C403 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 0.1UF 10UF/10V DE-COUPLE CAPS PLEASE CLOSE CHIP POWER PIN *For RTL8100C application, all bead must be rated 300mA/100ohm@100Mhz The maximum voltage drop when on should be less than 0.3V LANVDD3 FCM2012V121 C362...

  • Page 110: Audio Codec Alc201A

    Schematic Diagrams Audio Codec ALC201A For some crystal, FCM1608K-121 VDDA +3VS U18 78L05(SO8)(R) the bias resistor is needed VDDA R486 C613 C616 C638 C637 1M(R) C672 0.1UF R482 10UF/10V 0.1UF 10UF/10V 0(R) C665 C664 0.1UF(R) 0.1UF 4.7U(0805) AGND C642 0 LOUT-L 24.576MHz LOUT-R...

  • Page 111: Audio Out & Off Board Connectors

    Schematic Diagrams Audio Out & Off Board Connectors VDDA JAUDIO1 SPDIF OUT INTMIC R192 AUDIO_JACK INTMIC 2.2K C225 SPDIF FCM1608K-121 SPDIF 0.1UF C234 C226 680P R191 10UF/10V 2.2K JAUDIO2 BK1608HS330 AUDIO_JACK AGND Vrefout R190 2.2K(R) MIC IN Vrefout MIC1 R196 FCM1608K-121 MIC1 C231...

  • Page 112: System Power Control

    Schematic Diagrams System Power Control U14B R462 U15B +12VS U14C S3AUXSW# SUSB# 74LVC14 SUSB# 13,24 PSON# 15,29 PSON# U14D R197 74(A)HC08 100K SI2301 SLP S3 74LVC14 C235 4.7UF/25V PSON 74LVC14 R654 PSON 100K U14E PSON U15C 2N7002 U14F 74LVC14 6,13 S3AUXSW# SUSC# 24 PSON#...

  • Page 113: Fan Control And Speedstep

    Schematic Diagrams Fan Control and SpeedStep FAN_VCC FCM2012V121 MAIN FAN C833 100U/16V DIP R410 JFAN1 24.9K H_DPSLP# H_DPSLP# 2,36 R409 F01J2E 4.7K FAN_SEN FAN_SEN R517 100K FI-S03P-HF 3904 CPUSTP# C522 CPUSTP# 4,15 FAN1-ON R367 1SS355 FAN1-ON 0.1UF 2SD1834 C515 0.1UF(R) R182 L125 4.7K...

  • Page 114: Mobility M9-P

    Schematic Diagrams Mobility M9-P 5,10 AAD[0..15] BGA3A AAD0 GPIO0 GPIO0 AAD28/VBCTL0 AAD1 Part 1 of 5 GPIO1 5,10 AAD28 GPIO1 AAD2 GPIO2 AAD29/VBCTL1 AAD3 GPIO2 +3VS GPIO3 5,10 AAD29 AAD4 GPIO3 GPIO4 GPIO4 T377 AAD5 GPIO5 GPIO5 T378 AAD[0..15] AAD6 GPIO6 5,10 AAD[0..15]...

  • Page 115: Mobility M9-P Mem A/B

    Schematic Diagrams Mobility M9-P MEM A/B OPTIONAL SERIES OPTIONAL SERIES TERMINATION MEMORY CHANNEL A TERMINATION MEMORY CHANNEL B FOR MEMORY FOR MEMORY ADDR & CNTRL ADDR & CNTRL INSTALL INSTALL RESISTORS RESISTORS CLOSER TO CLOSER TO DQMB#[7..0] DQMB#[0..7] DQMA#[7..0] DQMA#[0..7] MEM_MAB[13..0] MEM_MAB[0..13] MEM_MAA[13..0]...
  • Page 116 Schematic Diagrams VGA DRAM 1 of 2 CHANNEL +2.5V_MEM +2.5V_MEM MEM_MAA[0..13]31 MEM_MDA[0..63] MEM_MDA[0..63] 3 3 MEM_MDA0 MEM_MDA32 MEM_MDA1 MEM_MAA0 MEM_MAA0 MEM_MDA33 MEM_MDA2 MEM_MAA1 MEM_MAA1 MEM_MDA34 MEM_MDA3 MEM_MAA2 MEM_MAA2 MEM_MDA35 MEM_MDA4 MEM_MAA3 MEM_MAA3 MEM_MDA36 MEM_MDA5 MEM_MAA4 MEM_MAA4 MEM_MDA37 MEM_MDA6 MEM_MAA5 MEM_MAA5 MEM_MDA38 Sheet 32 of 41 MEM_MDA7...

  • Page 117: Vga Dram 1 Of 2 - Termination

    Schematic Diagrams VGA DRAM 1 of 2 - Termination Close to memory device MDB[0..63] MDA[0..63] Close to memory device MEM_MDB[0..63] 3 4 MEM_MDA[0..63] 3 2 MDB0 MEM_MDB0 MDA0 MEM_MDA0 MDB1 RN24 8P4R-22 MEM_MDB1 MDA1 RN25 8P4R-22 MEM_MDA1 MDB2 MEM_MDB2 MDA2 MEM_MDA2 MDB3 MEM_MDB3...
  • Page 118 Schematic Diagrams VGA DRAM 2 of 2 CHANNL B MEM_MDB[0..63] 3 3 MEM_MDB[0..63] 3 3 +2.5V_MEM +2.5V_MEM MEM_CSB0# MEM_RASB# MEM_MAB[0..13]31 MEM_CASB# MEM_MDB0 MEM_MDB32 MEM_MDB1 MEM_MAB0 MEM_MAB0 MEM_MDB33 MEM_MDB2 MEM_MAB1 MEM_MAB1 MEM_MDB34 MEM_MDB3 MEM_MAB2 MEM_MAB2 MEM_MDB35 MEM_WEB# MEM_MDB4 MEM_MAB3 MEM_MAB3 MEM_MDB36 MEM_MDB5 MEM_MAB4 MEM_MAB4...

  • Page 119: Mobility M9-P Pow

    Schematic Diagrams Mobility M9-P POW BGA3D BGA3E VDDC VDDC Part 4 of 5 VDDC VDDC Part 5 of 5 VDDC VDDC VDDC VDDC +1.5VS VDDC VDDC VDDC 4.0A 200mil VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC C758 C759 C760 C761 C762 C763...

  • Page 120: Vcore

    100K PQ60 100K SENSE3+ SYS5V 2N7002 PC87 1000PF PQ10 PQ61 SI4892 SI4892 2N7002 100K VID3 PR70 PR69 PQ39 2N7002 Only use on D400E PQ38 PWRGOOD_VID 2N7002 PR62 PQ36 PQ37 0.002 SI4362 SI4362 PD26 PQ62 F1J3FTP 38,39 TEST 2N7002 PR161 SYS5V+...

  • Page 121: Ddr Power

    Schematic Diagrams DDR Power VDDP SYS5V PR96 PR95 PC113 PC52 PD16 RB751V PD17 PC106 RB751V PC34 0.1uF/25V 10U_1210 PC132 1000P PGOOD1 PGOOD2 PC133 1000P VCCA1 PQ70 VDDP1 VCCA2 2.5V Si4800 PC49 PC107 PR93 PC33 ILIM1 TON1 0.1uF/25V PR103 20K 1% 10U_1210 PR105 750K...

  • Page 122: System Power

    Schematic Diagrams System Power PR108 VIN1 PC57 PC56 0.1A 12VR 0.1U 10U/25V PC62 PC58 PC123 PC55 0.1U 10U/25V 0.1U PD18 PC54 PC119 10U/16V PD22 PC63 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PD19 PC53 PQ43A 0.1U RB751V AO4900 PC122 BST3 0.1U VDD3 SYS3V PR86 PR109...

  • Page 123: Charger

    Schematic Diagrams Charger F1J3FTP PQ40 2.5A Si4435 2.5A PC25 PC89 PC24 PR72 PD30 0.1U 10U_1210 0.1U PQ15 Si4435 PQ18 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC94 PC96 PR24 PD28 PC99 PC95 PC32 PC97 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 100U/25V_DIP 0.1U(1206) 100U/25V_DIP PR75 PR73 PQ17...

  • Page 124: Sw Board And Hotkey

    Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 Sheet 40 of 41 GND_L GND_L CON8 SW Board and HotKey GND_L Hot keys,Power switch,key,Lid VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U...

  • Page 125: Touchpad And Switch Board

    Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCC5_T VCN3 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R 120P Sheet 41 of 41 120P 120P 0(R) TouchPad and plan GND_A GND_A Switch Board C178D83N C178D83N GND_A GND_A GND_A...

  • Page 126: Updating The Flash Rom Bios

    1. Using your web browser go to www.clevo.com.tw 2. Choose Download from the menu bar at the top of the page. 3. In the Driver section select the model of your computer ( D400E/D410E Series ) and the driver type ( BIOS ). 4. Select GO .

This manual is also suitable for:

D410e

Table of Contents
